SB-H-DELSOL/8W6 Stealthbox™
Fits Honda Del Sol
Installation Guide:
This Stealthbox™ is a product which requires professional installation skills and tools. Please read this
installation guide thoroughly before beginning the project. It will guide you step by step through the
installation. Some steps in this process may require two people to accomplish.
This enclosure is designed to mount behind the seats of the Honda Del Sol, replacing the factory-
installed storage compartments. It is absolutely vital that the enclosure be properly mounted to the
vehicle according to these instructions. Failure to mount the enclosure properly presents two prob-
lems: 1) the sub-bass performance will suffer due to the movement of the enclosure caused by the
force exerted by the woofers and 2) A loose enclosure could cause injury in the event of a collision or
sudden jolt.
STEP 1: Remove center console.
STEP 2: Remove rear storage compartments.
STEP 3: Remove back wall trim panel.
STEP 4: Remove rear side trim panels.
STEP 5: Unbolt and
remove seat belt
retractors from both
sides of the car (two
bolts per retractor).
Sheet SKU#011127 Revision 8/8/00
SB-H-DELSOL/8W6, JL AUDIO, Inc 1996 • Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB-H-DELSOL/8W3v3 and is the answer not in the manual?

Questions and answers

Summary of Contents for JL Audio SB-H-DELSOL/8W3v3

  • Page 1 STEP 3: Remove back wall trim panel. STEP 4: Remove rear side trim panels. STEP 5: Unbolt and remove seat belt retractors from both sides of the car (two bolts per retractor). Sheet SKU#011127 Revision 8/8/00 SB-H-DELSOL/8W6, JL AUDIO, Inc 1996 • Page 1...
  • Page 2 STEP 12: Remove the enclosure and open holes up with 1/2” bit. STEP 13: Place “U- nuts” (supplied)through the stamped factory holes and over the holes you have just drilled. SB-H-DELSOL/8W6, JL AUDIO, Inc 1996 • Page 2 Sheet SKU#011127 Revision 8/8/00...
  • Page 3 STEP 19: Glue carpet into place over mounting holes. (Contact cement works best.) STEP 20: Re-install center console. 10369 N. Commerce Pkwy, Miramar, Florida 33025-3921 Voice: (954) 443-1100 Fax: (954) 443-1111 SB-H-DELSOL/8W6, JL AUDIO, Inc 1996 • Page 3 Sheet SKU#011127 Revision 8/8/00...
