I N S T A L L A T I O N G U I D E
for the
SB-Y-YXZ1SPKR/MX650
SKU# 94643
2016 & Up Yamaha YXZ1000R
Enclosure Type: Sealed
Driver Type: MX650-CCX-SG-TLD-B
Nominal Impedance: 4 ohms
Continuous Power Handling: 60 watts (RMS method)
If you choose to perform the installation yourself, it is absolutely
vital that the Stealthbox
be properly mounted to the vehicle
®
according to these instructions. Failure to mount the enclosure
properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a
collision or sudden deceleration.
Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox® installed by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vehicle properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
SB-Y-YXZ1SPKR/MX650 INSTR_SKU# 011488
INSTALLATION
DIFFICULTY:
1
5
OUT
OF
ESTIMATED TIME:
1 HOUR
Continued on Next Page
Advertisement
Related Manuals for JL Audio 94643
Summary of Contents for JL Audio 94643
- Page 1 1 HOUR Thank you for choosing a JL Audio Stealthbox® for your automotive sound system. With proper installation, your new vehicle-specific enclosed subwoofer system I N S T A L L A T I O N G U I D E will deliver years of listening pleasure.
- Page 2 Fuse Blue Blue Yellow Yellow Note: For optimum performance, JL Audio recommends applying the included Foam Strips (or sound damping material) to surrounding plastic panels to reduce unwanted vibrations. Page 2 • JL Audio, Inc., 2017 Continued on Next Page...
- Page 3 Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your Stealthbox® amplifier. Other kits are available should you be using more than one amplifier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for both channels of the amplifier.
- Page 4 Align the threaded inserts in the back of the enclosure with the two factory Remove the factory bolt, and remove the holes. Template. Page 4 • JL Audio, Inc., 2017 Continued on Next Page...
- Page 5 . j l a u d i o . c o m All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox®” and the Stealthbox logo, and “How we play®” are registered trademarks of JL Audio, Inc.
- Page 6 SB-Y-YXZ1SPKR/MX650 INSTR_SKU# 011488 This page is intentionally left blank. Page 6 • JL Audio, Inc., 2017...
- Page 7 SB-Y-YXZ1SPKR/MX650 INSTR_SKU# 011488 T E M P L AT E S Carefully cut out the templates along the indicated lines. DRIVER SIDE TEMPLATE PASSENGER SIDE TEMPLATE Page 7 • JL Audio, Inc., 2017...
