- Page 1 1.800.423.0698 www.cookshack.com info@cookshack.com Cookshack Operators Manual Model FEC750 Fast Eddy’s Oven Version 05.1 Model:FEC750 Serial No: Fast Eddy’s Model FEC750...
- Page 2 Cookshack, Inc. assumes no responsibility for results of careless and dangerous operation of Cookshack smokers or other products. All warranties are null and void if the practices described in the Operator's Manual are not observed.
-
Page 3: Table Of Contents
Version 05.1 May 2005 GENERAL INSTRUCTIONS ....................4 INSTALLATION INSTRUCTIONS..................4 EXHAUST SYSTEMS......................5 OPERATING INSTRUCTIONS ....................6 LOADING INSTRUCTIONS ....................6 SAFETY TIPS ...........................6 ELECTRICAL SPECIFICATIONS ..................7 MAINTENANCE ........................7 TWO YEAR LIMITED WARRANTY ..................8 ELECTRICAL WIRING DIAGRAM ..................9 NATIONAL SERVICE POLICY....................10 Fast Eddy’s Model FEC750... -
Page 4: General Instructions
A 4 foot flue extension is required for all units used outdoors. Your flue extension rests inside the flue collar. • Flues should be inspected and cleaned every six months. Fast Eddy’s Model FEC750... -
Page 5: Exhaust Systems
EXHAUST SYSTEM(S) • All FEC750’s come with a standard system which vents smoke out of the oven through a 5 inch pipe. It is the customer’s responsibility to provide a method to move smoke from this exhaust to the outside, following applicable local codes. -
Page 6: Operating Instructions
• Always use a grounded 3 prong plug and plug-in. • Always unplug the unit before any maintenance is performed. • Never leave firebox door open while the oven is running. • Never use a high pressure washer around electrical components. Fast Eddy’s Model FEC750... -
Page 7: Electrical Specifications
• If the grill is stored outdoors care should be taken to insure that water does not get into the hopper. Wood pellets expand greatly when wet and may jam the auger system. A vinyl cover for the hopper is highly recommended. Fast Eddy’s Model FEC750... -
Page 8: Two Year Limited Warranty
Fast Eddy by Cookshack Ovens limited warranty includes parts for two (2) years and labor for the first 90 days of this period Cookshack, Inc.’s obligation under this warranty shall be to repair and replace at its option any part deemed defective upon examination by Cookshack, Inc. -
Page 9: Electrical Wiring Diagram
1 2 3 4 5 6 7 8 Fuse Hi Temp Switch Left 450° Switch Common Hopper Rotisserie Convection Louver Right Dr Switch Btm Dr Top Dr Motor Motors Switch Switch Switch Foot Switch Connector Auger Combustion Igniters Motors Fans Fast Eddy’s Model FEC750... -
Page 10: National Service Policy
Cookshack, Inc.’s National Service Policy is to build quality equipment with easy serviceability. Because of the ease in serviceability, Cookshack does not have National Service Companies to repair their equipment. This allows each restaurant to use the service company of their choice.
