Cookshack, Inc.
Model FEC120
Fast Eddy Oven
Operator's Manual
Please read this entire manual installation and use of this pellet fired smoker oven. Failure to follow these
instructions could result in property damage, bodily injury or even death.
Contact local building or fire officials about restrictions and installation inspection requirements in your area.
SAVE THESE INSTRUCTIONS
Version 12.1
05/16/11
