- Page 1 1.800.423.0698 www.cookshack.com info@cookshack.com Cookshack, Inc. OPERATOR'S MANUAL Models 075 & 076 ® SmartSmoker Oven Version: 10.1 Model: 075 / 076 Serial No.: ____________...
- Page 2 Dear Cookshack Customer: Your model 075 or 076 Cookshack SmartSmoker® oven will produce great barbecue and smoked foods. It is easy to operate, clean, and maintain. Use this Operator's Manual to familiarize yourself with the smoker and its operation. If you have a question or problem not covered in the book, call us (800)423-0698 Monday through Friday, 9am to 4 pm or e-mail us at info@cookshack.com.
-
Page 3: Table Of Contents
Setting the Cooking Temperature Holding SHUTDOWN PROCEDURE Cleanup MAINTENANCE TROUBLESHOOTER'S GUIDE, OPERATION13 TROUBLESHOOTER'S GUIDE, COOKING 14 APPENDIX A Limited Warranty Policy APPENDIX B Replacement of defective merchandise 16-17 APPENDIX C Wiring Diagram Smoker Oven Illustration Cookshack Model 075/076 SmartSmoker Oven... -
Page 4: Setting Up
NEMA codes, and any other applicable electrical codes. Cookshack Models 075 and 076 have a single burner system using 120V AC power. Connect these ovens to the power supply by plugging the power cord into a 120V receptacle which is protected by a breaker or fuse rated at 15 amperes. -
Page 5: Cooking
Use local woods only if logs are selected and sized properly and if you are satisfied with their flavoring abilities. CAUTION The maximum amount of wood to be used in your Cookshack Model 075 and 076 smoker oven is 6 ounces. Do not overload the Wood Box. Use only wood. -
Page 6: Loading The Oven With Meat
Do not overload your smoker. Use the Smoker Oven Maximum Load Capacity chart below to determine the maximum capacity of your smoker. The following chart shows maximum cooking capacities, per load, of various Cookshack smoker ovens. Capacities are based on 3 lb. ribs, 8 - 10 lbs. heavy cuts, and 3 lb. chickens. Capacities are specifically limited by the amount of heat available. -
Page 7: Setting The Cooking Temperature
Setting the Cooking Temperature Your Cookshack Model 075/076 has the new Cookshack IQ4 control system. This controller has the same great cook & hold features as previous models of the IQ controller, but with an additional feature that allows you to cook with a meat probe. This optional probe plugs into the unit and allows you to set the internal temperature to which you want the product cooked. - Page 8 Cook Temp 225° F Hold Temp 140° F Cook Time 3:00 hours Briskets Pressing the button marked will make the following settings: Cook Temp 225 F Hold Temp 140° F Cook Time 12 hours Cookshack Model 075/076 SmartSmoker Oven...
- Page 9 The IQ controller is also equipped with a . If the oven door is open, the oven heating elements are disabled and a door open alarm will sound. Please contact your Cookshack Service Representative for assistance if you experience this problem. The door position sensor is a safety feature and must be kept in working order.
-
Page 10: Holding
Remember, these are basic guidelines only and are not intended to replace laws, regulations, or restrictions concerning the handling and processing of food products. For further information, use your local health department guidelines to determine the best method for holding product, hot or cold. Cookshack Model 075/076 SmartSmoker Oven... -
Page 11: Shutdown Procedure
Always disconnect the oven from its electrical supply before cleaning or servicing. clean Your Cookshack smoker must be kept . Loose grease and scale should be removed regularly to prevent buildup, which may cause strong fumes. It is desirable to allow seasoned coating, such as that found on a well-seasoned cast iron skillet, to remain on the oven walls. -
Page 12: Maintenance
Periodically check electrical plug and wire for any type of wear or damage. Twice annually put two drops of lightweight oil on the hinge pins to prevent binding. Check casters for free movement. Cookshack Model 075/076 SmartSmoker Oven... -
Page 13: Troubleshooter's Guide, Operation13
Actual oven This is normal! temperature reads 5 to You do not need 20° higher or lower to monitor the than set temperature temperature! Cookshack Model 075/076 SmartSmoker Oven... -
Page 14: Troubleshooter's Guide, Cooking
Dry product Oven humidity Use Cookshack Water too low Magazine to increase humidity Purchase product with fat on Load cooks Improper loading Follow smoker oven loading unevenly instructions in this manual; Cookshack Model 075/076 SmartSmoker Oven... - Page 15 Do not use sheet pans in the smoker, they block even circulation of heat and smoke Brisket on Improper loading Load bottom grill with fewer bottom cooks briskets, and load with fat side too fast down Cookshack Model 075/076 SmartSmoker Oven...
-
Page 16: Appendix A
90 days. Following the 90 day period, the two (2) year limited warranty is for parts only. Cookshack, Inc.’s obligation under this warranty shall be to repair or replace at its option any part deemed defective upon examination by Cookshack, Inc. or its authorized service agent, for a period of two (2) years from the date of sale. - Page 17 Credit for merchandise under warranty deemed to be defective by Cookshack, Inc. will be issued upon return of the defective merchandise. Credit may be denied if the returned merchandise is not found to be defective by Cookshack, Inc.; if return number it is not under warranty;...
-
Page 18: Appendix C
1.800.423.0698 www.cookshack.com info@cookshack.com APPENDIX C Wiring Diagram Cookshack Model 075/076 SmartSmoker Oven... - Page 19 Power Cord PV461 Probe Jack Cover PV536 Door Switch PV366 Vent Assy. PV148 Latch PV169 Grill PV011 Probe PV718 Side Rack PM023 Limit Switch PV551 Woodbox PM305 Element PV324 Drain Pan PV701 Casters Front PV171 Back PV170 Cookshack Model 075/076 SmartSmoker Oven...
