JL Audio Stealthbox SB-GM-CLDRO/10W3v3 Installation Manual page 3

Cont.
From
Previous
Page
STEP 11: With the shoulder belt through the bot-
tom crease. Snap the belt back into the latch.
Specifications:
Enclosure Type: Sealed
Driver Type: 10W3v3-4
Nominal Impedance: 4
Cont. Power Handling: 300Watts
JL Audio recommends using a high quality amplifier such as the JL Audio 250/1. The diagram below shows the recommended
crossover, infrasonic filter and equalizer settings for the 250/1 when being used to power your Stealthbox®.
+12VDC Ground Remote Preamp Output Section
Output Mode
Full-Range/Low-Pass/High-Pass
JL AUDIO 250/1
monoblock subwoofer amplifier
Left Ch. Right Ch.
The JL Audio 250/1 is a very versatile audio component. Please consult the owner's manual for detailed information
about installing and tuning this amplifier.
w w w . j l a u d i o . c o m
Bass Control Amp LP Filter Amplifier Input Section
Infrasonic Filter Mode/Slope Input Voltage Input Sens. Signal Sensing
Off/30Hz Off/12dB/24dB Low/High Off/On
+7
+3 +10
+1 +13
LF Boost (dB) Filter Freq. (Hz) Left Ch. Right Ch.
10369 N. Commerce Pkwy, Miramar, Florida 33025-392
S B - G M - C L D RO / 1 0 W 3 v 3 , J L AU D I O, I n c 2 0 0 6
STEP 12: Flip the rear seat back into the up-right
position.
Mid/High Frequency Driver Information:
Front Location Driver Size:
6.5" separates
Applicable JL Audio Products:
VR, XR,VR & TR 650-CSi
*with 1/2" spacer
Rear Location Driver Size:
6.5"
Applicable JL Audio Products:
XR,VR & TR 650-CXi
*with 1.0" spacer
Phone: 954.443.1100
Pa g e 3
CONGRATULATIONS!
INSTALL COMPLETE.
Included Hardware:
(1) Wax Square
(1) 2-14"Socket Cup Set Screw
(1) Fender Washer
(1) Flat Washer
(1) Lock Washer
(1) Hex Nut
Difficulty Of Installation:
XR650-CSi
VR650-CXi
Fax: 954.443.1111
S h e e t S K U # 0 1 1 1 8 9 R ev i s i o n 3 / 8 / 2 0 0 6
