JL Audio Stealthbox SB-GM-C6CONV/8W3v3 Installation Manual

I N S T A L L A T I O N G U I D E
for the
SB-GM-C6CONV/8W3v3 SB-GM-C6CONV/8W3v3
2005 - Up Chevrolet C6 Corvette Convertible 2005 - Up Chevrolet C6 Corvette Convertible
Thank you for choosing a JL Audio Stealthbox
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 1 year if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
® for your automotive sound system. With proper
® installed by your authorized JL Audio
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-GM-C6CONV/8W3v3_INSTR_SKU#011225 SB-GM-C6CONV/8W3v3_INSTR_SKU#011225
INSTALLATION
D I F F I C U L T Y :
2
S T E P 1
Place the convertible top in the down position, keeping the
protective lid open.
Position the seats all the way forward.
Remove the pair of rear speakers.
S T E P 2
Pull out the pair of plastic push-in retainers. These hold the
painted interior trim piece to the rear bulkhead.
S T E P 3
Remove the pair of Allen head screws from the top side of
the painted interior trim piece.
Remove the painted interior trim piece out of the vehicle.
Continued on Next Page
OUT
OF 5
