Korenix 5-port 10/100 Specifications

JetNet 2005
Industrial 5-port Compact Fast Ethernet Switch
95
Overview
K o r e n i x J e t N e t 2 0 0 5 i s a n I n d u s t r i a l 5 - p o r t
10/100Base-TX Ethernet switch. JetNet 2005 adopts
slim industrial design to save rail space for compact
system. In order to survive under harsh environment,
JetNet 2005 chooses industrial-grade aluminum case
Plug-and-Play Switch & High-Speed Transmission
JetNet 2000 series require no user setup and
immediately start operating as soon as you power
them up.
Compact Size & Fault Relay Output
The slim-line design makes it an ideal model that
would physically fit in a network environment with
limited space.
One relay output is an important feature to let you
95
5-port 10/100 TX Compact Fast Ethernet switch
3.2Gbps Switch Fabric with excellent data exchange
performance
Support 1.5KV Hi-Pot isolation protection
Dual mode for power input, AC18-27V/DC18-32V
Fault relay alarm
Aluminum case with IP-31 grade protection
-20~70
environment application
RoHS
o
C operating temperature for hazardous
with IP31 grade protection ability with dust and drop-
water proof. JetNet 2005 provides one relay output
for port link down events, which is enabled/ disabled
by the DIP switch. JetNet 2005 is powered by
18~27VAC or 18~32VDC from a 4-pin terminal block.
E x c e l l e n t d a t a t r a n s m i s s i o n p e r f o r m a n c e i s
provided for you. No works will be delayed with the
transmission rate up to 3.2Gbps.
know when there is any event of port link down. Just
move up the DIP switch, the fault relay alarm will be
functioning!
