Korenix JetNet 5008G-P Series
Industrial Managed Ethernet Switch
User's Manual
Version V1.0, Sep. 2007
www.korenix.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JetNet 5008G-P Series and is the answer not in the manual?

Questions and answers

Related Manuals for Korenix JetNet 5008G-P Series

Summary of Contents for Korenix JetNet 5008G-P Series

  • Page 1 Korenix JetNet 5008G-P Series Industrial Managed Ethernet Switch User’s Manual Version V1.0, Sep. 2007 www.korenix.com...
  • Page 2 Korenix JetNet 5008G-P Series Industrial Managed Ethernet Switch User’s Manual Copyright Notice Copyright © 2006 Korenix Technology Co., Ltd. All rights reserved. Reproduction in any form or by any means without permission is prohibited.

  • Page 3: Table Of Contents

    VLAN ......................49 Traffic Prioritization.................56 Multicast Filtering..................61 SNMP.......................64 Security ....................68 4.10 Warning....................74 4.11 Monitor and Diag..................79 4.12 Save to Flash ....................85 4.13 Logout ......................86 Appendix......................87 Product Specification................87 Korenix SFP family .................89 Korenix Private MIB................91 Revision History ..................92 About Korenix ..................93...

  • Page 4: Introduction

    300ms to 5ms for 10/100TX RJ-45 ports, 100FX and Gigabit Fiber. This is Korenix patented ring technology, which is registered in most countries. For interoperability with your existed network, JetNet 5008G-P series also come with an advanced redundant network solution, Ring Coupling and Dual Homing II technology.

  • Page 5: Package List

    Complies with IP31 Note: The detail spec is listed in Appendix 5.1. Package List Korenix JetNet 5008G-P Series products are shipped with following items: One industrial Managed Ethernet switch Documentation and Software CD If any of the above items are missing or damaged, please contact your local sales...

  • Page 6: Hardware Installation

    2 Hardware Installation This chapter includes hardware introduction, installation and configuration information. Following topics are covered in this chapter: 2.1 Hardware Introduction Dimension Structure View 2.2 Wiring Power Inputs 2.3 Wiring Ethernet Ports 2.4 Wiring Combo Ports Hardware Introduction Dimension JetNet 5008G-P Industrial Gigabit Switch dimension (W x H x D) is 140mm x 30mm x200mm...

  • Page 7: Wiring Power Inputs

    Structure View Industrial Gigabit Managed Switch The Structure view of JetNet 5008G-P consists 6 Fast Ethernet port, 1 10/100/1000Base-T RJ45 port and 2 10/100/1000Base-T / SFP combo Port. There are Reset Pin, Mounting Hole, LEDs for 3 Gigabit port and Power Input 1/2. Wiring Power Inputs Follow below steps to wire JetNet 5008G-P redundant DC power inputs.

  • Page 8: Wiring Fast Ethernet Ports

    2 gigabit SFP ports combo with gigabit Ethernet ports (port 7th and 8th). The speed of the SFP port supports 100Base-FX and 1000Base-SX/LX. The SFP ports accept standard MINI GBIC SFP transceiver. But, to ensure system reliability, Korenix recommends using the Korenix certificated Gigabit SFP Transceiver. The certificated SFP transceiver includes 100Base-FX single/multi mode, 1000Base-SX/LX single/multi mode ranger from 550m to 80KM.

  • Page 9: Preparation For Management

    3.1.1 Web Interface Korenix web management page is developed by JAVA. It allows you to use a standard web-browser such as Microsoft Internet Explorer, or Mozila, to configure and interrogate the switch from anywhere on the network. Before you attempt to use the embedded web interface to manage switch operation,...
  • Page 10 3.1.2 Secured Web Interface Korenix web management page also provides secured management HTTPS login. All the configuration commands will be secured and will be hard for the hackers to sniff the login password and configuration commands.

  • Page 11: Preparation For Telnet Console

    3.2.1 Telnet Korenix JetNet 5008G-P supports Telnet console. You can connect to the switch by Telnet and the command lines are the same as what you see by RS232 console port. Below are the steps to open Telnet connection to the switch.
  • Page 12 3.2.2 SSH (Secure Shell) Korenix JetNet 5008G-P also support SSH console. You can remotely connect to the switch by command line interface. The SSH connection can secure all the configuration commands you sent to the switch. SSH is a client/server architecture while JetNet 5008G-P is the SSH server. When you want to make SSH connection with the switch, you should download the SSH client tool first.
  • Page 13 and Port number (default = 22). Choose the “SSH” protocol. Then click on “Open” to start the SSH session console. 2. After click on Open, then you can see the cipher information in the popup screen. Press Yes to accept the Security Alert. 3.

  • Page 14: Feature Configuration

    IP address. Then you can remotely connect to its embedded HTML web pages or Telnet console. Korenix web management page is developed by JAVA. It allows you to use a standard web-browser such as Microsoft Internet Explorer, or Mozila, to configure and interrogate the switch from anywhere on the network.

  • Page 15: Command Line Interface Introduction

    Command Line Interface Introduction The Command Line Interface (CLI) is the user interface to the switch’s embedded software system. You can view the system information, show the status, configure the switch and receive a response back from the system by keying in a command. There are some different command modes.
  • Page 16 Global Configuration Mode: Press configure terminal in privileged EXEC mode. You can then enter global configuration mode. In global configuration mode, you can configure all the features that the system provides you. Type interface IFNAME/VLAN to enter interface configuration mode, exit to leave. ? to see the command list.
  • Page 17 Available command lists of the global configuration mode. Switch(config)# interface fa1 Switch(config-if)# acceptable Configure 802.1Q acceptable frame types of a port. auto-negotiation Enable auto-negotiation state of a given port description Interface specific description duplex Specify duplex mode of operation for a port End current mode and change to enable mode exit Exit current mode and down to previous mode...
  • Page 18 Summary of the 5 command modes. Command Main Function Enter and Exit Method Prompt Mode Enter: Login successfully User EXEC This is the first level of access. Switch> Exit: exit to logout. User can ping, telnet remote Next mode: Type enable to device, and show some basic information enter privileged EXEC mode.
  • Page 19 Here are some useful commands for you to see these available commands. Save your time in typing and avoid typing error. ? To see all the available commands in this mode. It helps you to see the next command you can/should type as well. Switch(config)# interface (?) IFNAME Interface's name vlan...

  • Page 20: Basic Setting

    Basic Setting The Basic Setting group provides you to configure switch information, IP address, User name/Password of the system. It also allows you to do firmware upgrade, backup and restore configuration, reload factory default, and reboot the system. Following commands are included in this group: 4.2.1 Switch Setting 4.2.2 Admin Password 4.2.3 IP Configuration...
  • Page 21 System Name: You can assign a name to the device. The available characters you can input is 64. After you configure the name, CLI system will select the first 12 characters as the name in CLI system. System Location: You can specify the switch’s physical location here. The available characters you can input is 64.
  • Page 22 User name: You can key in new user name here. The default setting is admin. Password: You can key in new password here. The default setting is admin. Confirm Password: You need to type the new password again to confirm it. Once you finish configuring the settings, click on Apply to apply your configuration.
  • Page 23 Subnet Mask: You can assign the subnet mask for the IP address here. If DHCP Client function is enabled, you don’t need to assign the subnet mask. The default Subnet Mask is 255.255.255.0. Note: In the CLI, we use the enabled bit of the subnet mask to represent the number displayed in web UI.
  • Page 24 Time-zone: Select the time zone where the switch is located. Following table lists the time zones for different locations for your reference. The default time zone is GMP Greenwich Mean Time. Switch(config)# clock timezone 01 (GMT-12:00) Eniwetok, Kwajalein 02 (GMT-11:00) Midway Island, Samoa 03 (GMT-10:00) Hawaii 04 (GMT-09:00) Alaska 05 (GMT-08:00) Pacific Time (US &...
  • Page 25 53 (GMT+06:30) Rangoon 54 (GMT+07:00) Bangkok, Hanoi, Jakarta 55 (GMT+07:00) Krasnoyarsk 56 (GMT+08:00) Beijing, Chongqing, Hong Kong, Urumqi 57 (GMT+08:00) Irkutsk, Ulaan Bataar 58 (GMT+08:00) Kuala Lumpur, Singapore 59 (GMT+08:00) Perth 60 (GMT+08:00) Taipei 61 (GMT+09:00) Osaka, Sapporo, Tokyo 62 (GMT+09:00) Seoul 63 (GMT+09:00) Yakutsk 64 (GMT+09:30) Adelaide 65 (GMT+09:30) Darwin...
  • Page 26 You can type a specific address into the IP Address field for the DHCP server reserved IP address. The IP address that is listed in the Excluded Address List Table will not be assigned to the network device. Add or remove an IP address from the Excluded Address List by clicking Add or Remove.
  • Page 27 4.2.6 Backup and Restore With Backup command, you can save current configuration file saved in the switch’s flash to admin PC or TFTP server. This will allow you to go to Restore command later to restore the configuration file back to the switch. Before you restore the configuration file, you must place the backup configuration file in the PC or TFTP server.
  • Page 28 4.2.7 Firmware Upgrade In this section, you can update the latest firmware for your switch. Korenix provides the latest firmware in Korenix Web site. The new firmware may include new features, bug fixes or other software changes. We’ll also provide the release notes for the update as well. For technical viewpoint, we suggest you use the latest firmware before installing the switch to the customer site.
  • Page 29 new firmware. Please remind the attached users before you do this. Figure 4.2.5.1 Main UI of Firmware Upgrade There are 2 modes for users to backup/restore the configuration file, Local File mode and TFTP Server mode. Local File mode: In this mode, the switch acts as the file server. Users can browse the target folder and then type the file name to backup the configuration.
  • Page 30 Click on Folder icon to select the target file you want to backup/restore. Figure 4.2.6.3 Firmware Upgrade – TFTP Server mode. Type the IP address of TFTP Server and Firmware File Name. Then click on Upgrade to start the process. After finishing transmitting the firmware, the system will copy the firmware file and replace the firmware in the flash.
  • Page 31 Figure 4.2.7.2 Popup alert screen to confirm the command. Click on Yes to start it. Figure 4.2.7.2 Popup message screen to show you that have done the command. Click on OK to close the screen. Then please go to Reboot page to reboot the switch. Click on OK.
  • Page 32 Figure 4.2.8.2 Popup alert screen to request confirmation. Click on Yes. Then the switch will be rebooted immediately. Figure 4.2.8.3 Popup message screen appears when rebooting the switch.. 4.2.10 CLI Commands for Basic Setting Feature Command Line Switch Setting Switch(config)# hostname System Name WORD Network name of this system Switch(config)# hostname JN5008G-P...
  • Page 33 JN5008G-P(config)# snmp-server contact System Contact korecare@korenix.com JN5008G-P# show snmp-server name Display JN5008G-P JN5008G-P# show snmp-server location Taipei JN5008G-P# show snmp-server contact korecare@korenix.com JN5008G-P> show version 0.31-20061218 Switch# show hardware mac MAC Address : 00:12:77:FF:01:B0 Admin Password JN5008G-P(config)# administrator User Name and...
  • Page 34 select. JN5008G-P# sh ntp associations Display 192.168.10.100 192.168.10.101 JN5008G-P# show clock Sun Jan 1 04:14:19 2006 (GMT) Greenwich Mean Time: Dublin, Edinburgh, Lisbon, London JN5008G-P# show clock timezone clock timezone (26) (GMT) Greenwich Mean Time: Dublin, Edinburgh, Lisbon, London Backup and Restore Switch# copy startup-config tftp: 192.168.10.33 Backup Startup Writing Configuration [OK]...

  • Page 35: Port Configuration

    Port Configuration Port Configuration group enables you to enable/disable port state, or configure port auto-negotiation, speed, duplex, flow control, rate limit control and port aggregation settings. It also allows you to view port status and aggregation information. Following commands are included in this group: 4.3.1 Port Control 4.3.2 Port Status 4.3.3 Rate Control...
  • Page 36 Duplex(10 Half), 100M Full Duplex(100 Full), 100M Half Duplex(100 Half), 1000M Full Duplex(1000 Full), 1000M Half Duplex(1000 Half). The default mode is Auto Negotiation mode. In Flow Control column, “Enable” means that you need to activate the flow control function of the remote network device in order to let the flow control of that corresponding port on the switch to work.
  • Page 37 Note: Most of the SFP transceivers provide vendor information which allows your switch to read it. Korenix can display vendor name, wave length and distance of all Korenix SFP transceiver family. If you see Unknown info, it may mean that the vendor doesn’t provide their information or that the information of their transceiver can’t be read.
  • Page 38 The aggregated ports can interconnect to the other switch which also supports Port Trunking. Korenix Supports 2 types of port trunking. One is Static Trunk, the other is 802.3ad. When the other end uses 802.3ad LACP, you should assign 802.3ad LACP to the trunk.
  • Page 39 Trunk Size: The switch can support up to 5 trunk groups. Each trunk group can support up to 8 member ports. Since the member ports should use same speed/duplex, max groups for 100M ports would be 4, and 1 for gigabit ports. Group ID: Group ID is the ID for the port trunking group.
  • Page 40 4.3.5 Command Lines for Port Configuration Feature Command Line Port Control Switch(config-if)# shutdown -> Disable port state Port Control – State Port1 Link Change to DOWN interface fastethernet1 is shutdown now. Switch(config-if)# no shutdown -> Enable port state Port1 Link Change to DOWN Port1 Link Change to UP interface fastethernet1 is up now.
  • Page 41 Rate Control JetNet 5008G-P(config-if)# rate-limit Rate Control – egress Outgoing packets Ingress or Egress ingress Incoming packets Note: To enable rate control, you should select the Ingress or Egress rule first; then assign the packet type and bandwidth. JetNet 5008G-P(config-if)# rate-limit ingress mode Rate Control –...

  • Page 42: Network Redundancy

    Rapid Super Ring technology is Korenix 2 generation Ring redundancy technology. This is Korenix patent and protected in countries all over the world. RSR meets the fastest failover time, 5 milliseconds, up to twenty units connected in a Gigabit Fiber Ring topology.
  • Page 43 RSTP Mode: You must first enable STP/RSTP mode, before configuring any related parameters. Parameter settings required for both STP and RSTP are the same. Note that 802.1d refers to STP mode, while 802.1w refers to faster RSTP mode. Bridge Configuration Priority (0-61440): RSTP uses bridge ID to determine the root bridge, the bridge with the highest bridge ID becomes the root bridge.
  • Page 44 Hello Time (1-10): Enter a value from 1 to 10 seconds here. This is a periodic timer that drives the switch to send out BPDU (Bridge Protocol Data Unit) packet to check current STP status. The root bridge of the spanning tree topology periodically sends out a “hello” message to other devices on the network to check if the topology is “healthy”.
  • Page 45 Rapid Super Ring is Korenix 2 generation Ring redundancy technology. This is Korenix pattern and protected in countries all over the world. The Rapid Super Ring has enhanced Ring Master selection and shorted recovery time. This page allows you to enable the settings for Rapid Super Ring and Dual Homing II.
  • Page 46 Rapid Super Ring The checkbox is for you to enable the Rapid Super Ring. Enable this and then configure Priority and Hello Time for Ring Master selecting. Select Ring Ports (for both Rapid Super Ring or Super Ring) and Version. Ring Master (R.M.) In Rapid Super Ring environment, you should have one Ring Master.
  • Page 47 Version 2: Version 2 is Rapid Super Ring mode. Version 2 is the default setting when you selected the checkbox of Rapid Super Ring. Dual Homing II Dual Homing II is the important feature of Korenix 2 generation Ring redundancy technology. When you want to connect multiple RSR or form...
  • Page 48 Auto Ring Coupling In JetNet 4000/4500, we released Ring Couple for users to couple 2 Super Rings. In JetNet 5008G-P, we use the Dual Homing II to meet up same requirements. JetNet 5008G-P rings are protected by Rapid Super Ring with RSTP&RSR enabled in intermediate switches.
  • Page 49 4.4.5 Command Lines: Feature Command Line RSTP Enable JetNet 5008G-P(config)# spanning-tree enable Disable JetNet 5008G-P(config)# spanning-tree disable Warning: STP disable will cause Dual Homing II not working. RSTP mode JetNet 5008G-P(config)# spanning-tree mode rapid-stp SpanningTree Mode change to be RST(802.1w) . STP mode JetNet 5008G-P(config)# spanning-tree mode stp SpanningTree Mode change to be STP(802.1d) .
  • Page 50 RSTP Summary JetNet 5008G-P# show spanning-tree summary Switch is in rapid-stp mode. BPDU skewing detection disabled for the bridge. Backbonefast disabled for bridge. Summary of connected spanning tree ports : #Port-State Summary Blocking Listening Learning Forwarding Disabled -------- --------- -------- ---------- -------- #Port Link-Type Summary AutoDetected PointToPoint...
  • Page 51 Ring Info JetNet 5008G-P# show super-ring summary Super-Ring protocol status: Enable Ring state : Abnormal state Role type : Redundancy Manager Protocol Version : 2 Ring Port : fa1, fa2 Switch Priority : 100 Hello time : 1000 msec , Operate hello time : 1000 msec Dual Homing II status: Enable Super-Ring Statistics of Switch WPDU: sent 0 , received 0...

  • Page 52: Vlan

    Layer 2 switch, without actually disconnecting these devices from their original switches. JetNet 5008G-P Series Industrial Ethernet Switch supports 802.1Q VLAN. 802.1Q VLAN is also known as Tag-Based VLAN. This Tag-Based VLAN allows VLAN to be created across different switches (see Figure 1).
  • Page 53 PVID: The abbreviation of the Port VLAN ID. Enter port VLAN ID here. PVID allows the switches to identify which port belongs to which VLAN. To keep things simple, it is recommended that PVID is equivalent to VLAN IDs. The values of PVIDs are from 0 to 4095. But, 0 and 4095 are reserved. You can’t input these 2 PVIDs.
  • Page 54 Management VLAN ID: The switch supports management VLAN. The management VLAN ID is the VLAN ID of the CPU interface so that only member ports of the management VLAN can ping and access the switch. The default management VLAN ID is Static VLAN: You can assign a VLAN ID and VLAN Name for new VLAN here.
  • Page 55 Static VLAN Configuration You can see the created VLANs and specify the egress (outgoing) port rule to be Untagged, Tagged here. Figure 4.5.2.3 Static VLAN Configuration table. You can see that new VLAN 3 is created. VLAN name is test. Egress rules of the ports are not configured now. Figure 4.5.2.4 Configure Egress rule of the ports.
  • Page 56 4.5.3 VLAN Table This table shows you current settings of your VLAN table, including VLAN ID, Name, Status, and Egress rule of the ports. VLAN ID: ID of the VLAN. Name: Name of the VLAN. Status: Static shows this is a manually configured static VLAN. Unused means this VLAN is created by UI/CLI and has no member ports.
  • Page 57 (for VLAN 2) Display – Port Ingress Switch# show interface fa1 Rule (PVID, Ingress Interface fastethernet1 Filtering, Acceptable Administrative Status : Enable Frame Type) Operating Status : Not Connected Duplex : Auto Speed : Auto Flow Control :off Default Port VLAN ID: 2 Ingress Filtering : Disabled Acceptable Frame Type : All Port Security : Disabled...
  • Page 58 Switch(config-if)# description this is the VLAN 2 Switch(config-if)# no description ->Delete the description. IP address of the VLAN Switch(config)# interface vlan 2 Switch(config-if)# Switch(config-if)# ip address 192.168.10.18/24 Switch(config-if)# no ip address 192.168.10.8/24 ->Delete the IP address Create multiple VLANs Switch(config)# interface vlan 5-10 (VLAN 5-10) Shut down VLAN Switch(config)# interface vlan 2...

  • Page 59: Traffic Prioritization

    Traffic Prioritization Quality of Service (QoS) provides traffic prioritization mechanism which allows users to deliver better service to certain flows. QoS can also help to alleviate congestion problems and ensure high-priority traffic is delivered first. This section allows you to configure Traffic Prioritization settings for each port with regard to setting priorities.
  • Page 60 In JetNet, users can freely assign the mapping table or follow the suggestion of the 802.1p standard. Korenix uses 802.p suggestion as default values. You can find CoS values 1 and 2 are mapped to physical Queue 0, the lowest queue. CoS values 0 and 3 are mapped to physical Queue 1, the low/normal physical queue.
  • Page 61 4.6.3 DSCP-Queue Mapping This page is to change DSCP values to Physical Queue mapping table. Since the switch fabric of JetNet only supports 4 physical queues, Lowest, Low, Middle and High. Users should therefore assign how to map DSCP value to the level of the physical queue. In JetNet, users can freely change the mapping table to follow the upper layer 3 switch or routers’...
  • Page 62 Port Setting – Trust JetNet 5008G-P(config)# interface fa1 Mode- CoS Only JetNet 5008G-P(config-if)# qos trust cos The port trust is set CoS only ok. Port Setting – Trust JetNet 5008G-P(config)# interface fa1 Mode- CoS Frist JetNet 5008G-P(config-if)# qos trust cos-first The port trust is set CoS first ok.
  • Page 63 Map CoS 3 to Queue 1 JetNet 5008G-P(config)# qos cos-map 3 1 The CoS to queue mapping is set ok. Map CoS 4 to Queue 2 JetNet 5008G-P(config)# qos cos-map 4 2 The CoS to queue mapping is set ok. Map CoS 5 to Queue 2 JetNet 5008G-P(config)# qos cos-map 5 2 The CoS to queue mapping is set ok.

  • Page 64: Multicast Filtering

    Multicast Filtering For multicast filtering, JetNet 5008G-P uses IGMP Snooping technology. IGMP (Internet Group Management Protocol) is an Internet Protocol that provides a way for internet device to report its multicast group membership to adjacent routers. Multicasting allows one computer on the internet to send data to a multitude of other computers that have identified themselves as being interested in receiving the originating computers data.
  • Page 65 IGMP Snooping Table: In the table, you can see multicast group IP address, VLAN ID it belongs to, and member ports of the multicast group. JetNet 5008G-P supports 256 multicast groups. Click on Reload to refresh the table. 4.7.2 IGMP Query This page allows users to configure IGMP Query feature.
  • Page 66 4.7.3 CLI Commands of the Multicast Filtering Command Lines of the multicast filtering configuration Feature Command Line IGMP Snooping IGMP Snooping - JetNet 5008G-P(config)# ip igmp snooping Global IGMP snooping is enabled globally. Please specify on which vlans IGMP snooping enables IGMP Snooping - VLAN JetNet 5008G-P(config)# ip igmp snooping vlan VLANLIST allowed vlan list all existed vlan...

  • Page 67: Snmp

    SNMP Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. JetNet 5008G-P series support SNMP v1 and v2c. An SNMP managed network consists of two main components: agents and a manager.
  • Page 68 4.8.2 SNMPv3 Profile SNMP v3 can provide more security functions when the user performs remote management through SNMP protocol. It delivers SNMP information to the administrator with user authentication; all of data between JetNet 5008G-P and the administrator are encrypted to ensure secure communication. Security Level: Here the user can select the following levels of security: None, User Authentication, and Authentication with privacy.
  • Page 69 This page allows users to Enable SNMP Trap, configure the SNMP Trap server IP, Community name, and trap Version V1 or V2. After configuration, you can see the change of the SNMP pre-defined standard traps and Korenix pre-defined traps. The pre-defined traps can be found in Korenix private MIB.
  • Page 70 SNMP Trap Server IP JetNet 5008G-P(config)# snmp-server host 192.168.10.33 without specific SNMP trap host add OK. community name SNMP Trap Server IP JetNet 5008G-P(config)# snmp-server host 192.168.10.33 with version 1 and version 1 private community SNMP trap host add OK. Note: private is the community name, version 1 is the SNMP version SNMP Trap Server IP...

  • Page 71: Security

    Security JetNet 5008G-P provides several security features for you to secure your connection. The features include Port Security and IP Security. Following commands are included in this group: 4.9.1 Port Security 4.9.2 IP Security 4.9.3 802.1x 4.9.1 Port Security Port Security feature allows you to stop the MAC address learning for specific port. After stopping MAC learning, only the MAC address listed in Port Security List can access the switch and transmit/receive traffic.
  • Page 72 4.9.2 IP Security In IP Security section, you can set up specific IP addresses to grant authorization for management access to this JetNet via a web browser or Telnet. IP Security: Select Enable and Apply to enable IP security function. Add Security IP: You can assign specific IP addresses, and then press Add.
  • Page 73 IEEE 802.1X is the protocol that performing authentication to obtain access to IEEE 802 LANs. It is port-base network access control. With the function, user can control which connection is available or not. 802.1X Protocol: Here user can enable or disable the 802.1X Authentication Method: Radius is a authentication server that provide key for authentication, with this method, user must connect switch to server.
  • Page 74 802.1x Port Configuration Port control: Force Authenorized means this port is Authenorized, the data is free to in/out. Forece unauthenorized just opposite, the port is blocked. If user wants to control this port with Radius Server, please select Auto for port control. Reauthentication: If enable this field, switch will ask client to reauthenticate.
  • Page 75 802.1X Port Staus Here user can observe the port status for Port control status and Authorize Status each port. 4.9.4 CLI Commands of the Security Command Lines of the Security configuration Feature Command Line Port Security Add MAC JetNet 5008G-P(config)# mac-address-table static 0012.7701.0101 vlan 1 interface fa1 mac-address-table ucast static set ok! Port Security...
  • Page 76 ------------------- --------------- ------- ------------------------ 0012.7701.0101 Static IP Security IP Security JetNet 5008G-P(config)# ip security Set ip security enable ok. JetNet 5008G-P(config)# ip security host 192.168.10.33 Add ip security host 192.168.10.33 ok. Display JetNet 5008G-P# show ip security ip security is enabled ip security host: 192.168.10.33...

  • Page 77: Warning

    4.10 Warning JetNet 5008G-P provides several types of Warning features for you to remote monitor the status of end devices or the change of your network. The features include Fault Relay, System Log and SMTP E-mail Alert. Following commands are included in this group: 4.10.1 Event Selection 4.10.2 Syslog Configuration 4.10.3 SMTP Configuration...
  • Page 78 Once you finish configuring the settings, click on Apply to apply your configuration. 4.10.2 SysLog Configuration System Log is useful to provide system administrator locally or remotely monitor switch events history. There are 2 System Log modes provided by JetNet 5008G-P, local mode and remote mode.
  • Page 79 Once you finish configuring the settings, click on Apply to apply your configuration. Note: When enabling Local or Both mode, you can monitor the system logs in [Monitor and Diag] / [Event Log] page. 4.10.3 SMTP Configuration JetNet 5008G-P supports E-mail Warning feature. The switch will send the occurred events to remote E-mail server.
  • Page 80 Field Description SMTP Server IP Address Enter the IP address of the email Server Authentication Click on check box to enable password User Name Enter email Account name (Max.40 characters) Password Enter the password of the email account Confirm Password Re-type the password of the email account You can set up to 4 email addresses to receive email alarm from JetNet Rcpt E-mail Address 1...

  • Page 81: Syslog Configuration

    SMTP Email Alert set Server: 192.168.10.100, Account: admin@korenix.com ok. Receiver mail JetNet 5008G-P(config)# smtp-server receipt 1 korecare@korenix.com SMTP Email Alert set receipt 1: korecare@korenix.com ok. Authentication with JetNet 5008G-P(config)# smtp-server authentication username username and admin password admin password SMTP Email Alert set authentication Username: admin, Password: admin Note: You can assign string to username and password.

  • Page 82: Monitor And Diag

    4.11 Monitor and Diag JetNet 5008G-P provides several types of features for you to monitor the status of the switch or diagnostic for you to check the problem when encountering problems related to the switch. The features include MAC Address Table, Port Statistics, Port Mirror, Event Log and Ping.
  • Page 83 4.11.2 Port Statistics In this page, you can view operation statistics for each port. The statistics that can be viewed include Link Type, Link State, Rx Good, Rx Bad, Rx Abort, Tx Good, Tx Bad and Collision. Rx means the received packet while Tx means the transmitted packets. Note: If you see many Bad, Abort or Collision counts increased, that may mean your network cable is not connected well, the network performance of the port is poor…etc.
  • Page 84 4.11.3 Port Mirroring Port mirroring (also called port spanning) is a tool that allows you to mirror the traffic from one or more ports onto another port, without disrupting the flow of traffic on the original port. Any traffic that goes into or out of the Source Port(s) will be duplicated at the Destination Port.
  • Page 85 4.11.4 Event Log In the 4.10.3, we have introduced System Log feature. When System Log Local mode is selected, JetNet 5008G-P will record occurred events in local log table. This page shows this log table. The entry includes the index, occurred data and time and content of the events.
  • Page 86 4.11.6 CLI Commands of the Monitor and Diag Command Lines of the Monitor and Diag configuration Feature Command Line MAC Address Table Ageing Time JetNet 5008G-P(config)# mac-address-table aging-time 350 mac-address-table aging-time set ok! Note: 350 is the new ageing timeout value. Add Static Unicast MAC JetNet 5008G-P(config)# mac-address-table static address...

  • Page 87: Port Mirroring

    Port Statistics Port Statistics JetNet 5008G-P# show rmon statistics fa4 (select interface) Interface fastethernet4 is enable connected, which has Inbound: Good Octets: 178792, Bad Octets: 0 Unicast: 598, Broadcast: 1764, Multicast: 160 Pause: 0, Undersize: 0, Fragments: 0 Oversize: 0, Jabbers: 0, Disacrds: 0 Filtered: 0, RxError: 0, FCSError: 0 Outbound: Good Octets: 330500...

  • Page 88: Save To Flash

    4.12 Save to Flash Save Configuration allows you to save any configuration you just made to the Flash. Powering off the switch without clicking on Save Configuration will cause loss of new settings. After selecting Save Configuration, click on Save to Flash to save your new configuration.

  • Page 89: Logout

    4.13 Logout The switch provides 2 logout methods. The web connection will be logged out if you don’t input any command after 30 seconds. The Logout command allows you to manually logout the web connection. Click on Yes to logout, No to go back the configuration page. Command Lines: Feature Command Line...

  • Page 90: Appendix

    5 Appendix Product Specification. Technology Standard IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-TX IEEE 802.3z Gigabit Ethernet Fiber IEEE 802.3x Flow Control and Back-pressure IEEE 802.1p class of service IEEE 802.1Q VLAN IEEE 802.1D-2004 Rapid Spanning Tree Protocol (RSTP) IEEE802.3ad LACP Performance...
  • Page 91 Network Redundancy Rapid Spanning Tree IEEE802.1D-2004 Rapid Spanning Tree Protocol. Compatible with Legacy Spanning Tree and 802.1w. Rapid Super generation Korenix Ring Redundancy Technology. Failure Ring(RSR) recovery within 5ms. Dual Homing II RSR over RSTP. Allows users to enable RSR and RSTP at the same device.

  • Page 92: Korenix Sfp Family

    Korenix certificated SFP transceivers when you constructing your network. Korenix will keep on certificating and updating the certificated SFP transceivers in Korenix web site and purchase list. You can refer to the web site to get the latest information about SFP transceivers.
  • Page 93 Model Name Spec SFPGSX 1000Base-SX multi-mode SFP transceiver,550m, -10~70℃ 1000Base-SX multi-mode SFP transceiver,550m, wide operating SFPGSX-w temperature, -40~85℃ SFPGSX2 1000Base-SX plus multi-mode SFP transceiver,2Km, -10~70℃ 1000Base-SX plus multi-mode SFP transceiver, 2Km,wide operating SFPGSX2-w temperature, -10~70℃ SFPGLX10 1000Base-LX single-mode SFP transceiver 10Km, -10~70℃ 1000Base-LX single-mode SFP transceiver, 10Km, wide operating SFPGLX10-w temperature, -40~85℃...

  • Page 94: Korenix Private Mib

    SNMP. But, since some commands can’t be found in standard MIB, Korenix provides Private MIB to meet up the need. Compile the private MIB file by your SNMP tool. You can then use it. Private MIB can be found in product CD or downloaded from Korenix Web site.

  • Page 95: Revision History

    Revision History Edition Date Modifications V 1.0 Sep. 11, 2007 The first version...

  • Page 96: About Korenix

    Less Time At Work! Fewer Budget on applications! The Korenix business idea is to let you spend less time at work and fewer budget on your applications. Do you really want to go through all the troubles but still end up with low quality products and lousy services? Definitely not! This is why you need Korenix.
