Headlight Adjustment

Each headlight can be adjusted by means of
vertical and horizontal adjustment screws
located on the rear of each headlight. In
addition, the headlight is equipped with an
easily accessible adjuster to allow the vertical
adjustment to be corrected when the
motorcycle is fully loaded.
3
1
cgim
1. Horizontal adjustment screw
2. Vertical adjustment screw
3. Headlight adjuster lever for loaded
conditions
Switch the headlight dipped beam on.
Turn the vertical adjustment screw on the
headlight clockwise to raise the beam or
anti-clockwise to lower the beam.
Turn
the
horizontal
adjustment
clockwise to move the beam to the right or
anti-clockwise to move the beam to the left.
Switch the headlights off when the beam
settings are satisfactory.
Maintenance and Adjustment
Headlight adjustment lever for loaded
conditions
1
cgin
1. Headlight adjuster lever (unloaded
position)
2
2. Headlight adjuster lever (loaded
position)
For
normal
(unloaded)
headlight adjuster lever should be set in the
horizontal position (1).
For loaded conditions rotate the headlight
adjuster downwards until it stops (2). This will
lower
the
headlight
approximately 2°.
screw
2
conditions
the
beams
by
109
