  • Page 1 Spectralink 87-Series Wireless Telephone Deployment Guide Spectralink Software Version 1.0.x 721-0010-000 Rev. B February 2014...
  • Page 2 The drawings and specifications contained herein are the property of Spectralink and shall be neither reproduced in whole or in part without the prior written approval of Spectralink, nor be implied to grant any license to make, use, or sell equipment manufactured in accordance herewith.

  • Page 3: Table Of Contents

    Network Components ......................11 Quality of Service......................11 WLAN Security .........................12 System Requirements .....................12 System Diagram .......................13 System Components .......................14 Spectralink 87-Series handsets..................14 CMS Server ........................14 Servers ...........................14 Access points .........................15 Ethernet switch .......................16 Chapter 3: Installing the CMS ..........17 CMS Server Requirements ....................17...
  • Page 4 Spectralink 87-Series Wireless Telephones Deployment Guide Upload .csv to CMS ......................24 Configure Enterprise Settings ..................25 Chapter 5: Configure Wireless Settings with SLIC ..... 26 Chapter 6: Advanced Configuration ........27 Advanced Configuration ....................27 Appendix A: Open Source Information ........28 OFFER for Source for GPL and LGPL Software ............28...

  • Page 5: About This Guide

    Product Support Spectralink wants you to have a successful installation. If you have questions please contact the Customer Support Hotline at 1-800-775-5330. The hotline is open Monday through Friday, 6 a.m. to 6 p.m. Mountain time.

  • Page 6: Spectralink References

    Specific Documents AP Configuration Guides show you how to correctly configure access points and WLAN controllers (if applicable) and identify the optimal settings that support Spectralink 87-Series handsets. The guides can be found at the View Certified page. Spectralink 87-Series Installation and Configuration Tool Administration Guide The SLIC tool provides step-by-step instructions for configuring wireless settings required for the handsets to associate with the wireless LAN.

  • Page 7: Conventions Used In This Document

    Spectralink 87-Series Wireless Telephone User Guide The User Guide provides detailed information about using the features of the 87-Series handsets. For information on IP PBX and softswitch vendors, see PIVOT by Spectralink Call Server Interoperability Guide. Conventions Used In This Document Icons Icons indicate extra information about nearby text.

  • Page 8: Typography

    Italics Used to emphasize text, to show example values or inputs, and to show titles of reference documents available from the Spectralink Support Web site and other reference sites. Underlined blue Used for URL links to external Web pages or documents. If you click on text in this style, you will be linked to an external document or Web page.

  • Page 9: Chapter 1: Installation Sequence

    Configure APs per VIEW requirements. See the VIEW guide that details the required configuration for the APs deployed in the facility. Create the .csv file per CMS Batch configure extensions. See the Spectralink 87-Series Wireless Telephone Administration Guide for details on configuring this file.

  • Page 10: Sequence Diagram

    Spectralink 87-Series Wireless Telephones Deployment Guide Sequence Diagram 721-0010-000_B.docx February 2014...

  • Page 11: Chapter 2: Infrastructure

    This chapter covers the basic elements in a relatively simple system. Recommendations for your specific requirements are part of the service Spectralink includes with the installation of Spectralink wireless telephones. The following information will give you an overview of what each component does and how it is used by the wireless telephones.

  • Page 12: Wlan Security

    Internet connection Web: How is the Internet connection used by the handsets? Spectralink 87-Series handsets do not yet support a LAN provided NTP server, but instead rely on Internet access for the time. If there is no Internet connection, the handsets will not display the correct time.

  • Page 13: System Diagram

    Spectralink 87-Series Wireless Telephones Deployment Guide System Diagram 721-0010-000_B.docx February 2014...

  • Page 14: System Components

    Spectralink 87-Series Wireless Telephones Deployment Guide System Components Spectralink 87-Series handsets. Available in two models, the 87-Series handsets provide essential communication resources for facility wide implementation. Each model has a unique hardware ID that is printed on the label. 8741 The basic model that includes basic and advanced wireless telephone features.

  • Page 15: Access Points

    Cisco® Secure Access Control Server (ACS), v5.2, 4.1 • FreeRADIUS v2.1.10, 2.0.1 and 1.1.7 Other RADIUS servers may work properly with Spectralink handsets, but have not been tested. Inquiries on untested servers will receive limited, “Best Effort”, support. DHCP Server...

  • Page 16: Ethernet Switch

    Spectralink 87-Series Wireless Telephones. Ensure the WLAN and network infrastructure provides connectivity from the wireless telephone to all its required network resources (SIP Server, etc.) once the 87-Series handset connects to the network and obtains an IP address.

  • Page 17: Chapter 3: Installing The Cms

    Chapter 3: Installing the CMS Settings: Not using CMS? If you are not deploying a CMS, please go directly to Appendix B: Manual Configuration. CMS Server Requirements • VMWare® ESXi™ server 5.0 (or later) host machine capable of running 64-bit guest OS Virtual Machines (VM) (see this knowledge base article on VMWare's site: http://kb.vmware.com/selfservice/microsites/microsite.do?cmd=displayKC&docTy pe=kc&externalId=1003945&sliceId=1&docTypeID=DT_KB_1_1...
  • Page 18 Click Finish. Close the "Datastore Browser". Before you power on the new VM, select it (e.g. "Spectralink CMS") from the inventory on your server, right-click it and select "Edit Settings..." Click Network adapter 1 and then choose which network to connect it to under "Network Connection".

  • Page 19: Logging Into Cms

    The customer receives the APK (Authorization Product Key) and CMS serial number via an email which also includes a URL. Click the URL to generate the license key and register with Spectralink. Copy the license key. Open CMS and enter the serial number and paste the license key into the appropriate fields.

  • Page 20: What Is The Cms Certificate

    Loading the certificate into the handset with SLIC Configure Wireless Settings with SLIC and Spectralink 87-Series Installation and Configuration Tool Administration Guide. In SLIC, start the 87-Series Wizard. When you get to the CMS page, enter the CMS URL. 721-0010-000_B.docx February 2014...
  • Page 21 In SLIC, paste the certificate in the SSL certificate field. Ensure there are no extra white spaces or carriage returns after you paste the public key. Configure the rest of the SLIC settings and load the configuration onto the handset per the instructions in Spectralink 87-Series Installation and Configuration Tool Administration Guide. 721-0010-000_B.docx...

  • Page 22: Chapter 4: Configure Telephony Settings

    If you are not deploying a CMS, please go directly to Appendix B: Manual Configuration. The .csv template available online in the Spectralink 87-Series support site can be used by the CMS to bulk provision SIP service requirements for your handsets. Configure this file and upload it to the CMS.

  • Page 23: Device Mac

    Spectralink 87-Series Wireless Telephones Deployment Guide Device MAC List the MAC address of each Spectralink 87-Series handset you will be deploying. Extension Number The user part of the SIP Address of Record (for example, 1002) or the user and the host part of the registration SIP URI.

  • Page 24: Upload .Csv To Cms

    Spectralink 87-Series Wireless Telephones Deployment Guide Upload .csv to CMS Once you upload the .csv file to the CMS, when the handset first associates with the wireless LAN and finds the CMS, the CMS will identify it by its MAC address and list it in the Device list, see Device Management>...

  • Page 25: Configure Enterprise Settings

    At the enterprise level you would typically set everything except for the device specific SIP settings ext number/username/password which we just set with the .csv batch configuration file. Refer to Spectralink 87-Series Wireless Telephone Administration Guide for complete information on enterprise settings.

  • Page 26: Chapter 5: Configure Wireless Settings With Slic

    Appendix B: Manual Configuration. Use the Spectralink Installation and Configuration (SLIC) tool for a simple and speedy two-step setup process. Detailed information about this tool is provided in the Spectralink 87-Series Installation and Configuration Tool Administration Guide available online. You can procure the tool from your service representative.

  • Page 27: Chapter 6: Advanced Configuration

    Advanced Configuration How you approach the rest of the configuration for features you want to deploy depends on your facility and its needs. Refer to Spectralink 87-Series Wireless Telephone Administration Guide for information about each option. Spectralink recommends: Configure one advanced option at a time and test it before moving onto another one.

  • Page 28: Appendix A: Open Source Information

    Handset, as well as related license and copyright information, is available at http://support.spectralink.com. You may also obtain the same information by contacting Spectralink by regular mail or email at the addresses listed at the bottom of this notice. For at least three (3) years from the date of distribution of the applicable product or software, we will give to anyone who contacts us at the contact information provided below, for a charge of no more than our cost of physically distributing, the items listed in “Spectralink OFFER of Source...

  • Page 29: Appendix B: Manual Configuration

    If you do not install a CMS server, you will need to manually configure many settings using the Admin menu on the handset. CMS settings parallel the settings found on the Admin menu in the handset and these are explained in Spectralink 87-Series Wireless Telephone Administration Guide.

  • Page 30: Step 2: Network

    Spectralink 87-Series Wireless Telephones Deployment Guide Tip: Charging the Battery Pack The Battery Pack requires a certain amount of current to charge. Use the wall-wart and plug the handset into a wall socket to charge it most efficiently. Do not charge it by connecting it to a computer as many USB ports do not supply enough current to efficiently and quickly charge a battery.
  • Page 31 Spectralink 87-Series Wireless Telephones Deployment Guide Tap the applications icon (circle with small squares), at the bottom of the screen. You should then see the all apps screen (below). Tap the Settings icon and you should see the Settings menu: Tap “Admin settings”...
  • Page 32 Spectralink 87-Series Wireless Telephones Deployment Guide Tap Wi-Fi and use the on/off slider to turn it on. You should be presented with a dynamic list of access points broadcasting their SSID. See below for example. … 721-0010-000_B.docx February 2014...
  • Page 33 Spectralink 87-Series Wireless Telephones Deployment Guide If the SSID you desire is not presented tap the “+” icon and follow the steps to enter the wireless network parameters. The exact fields presented are dependent on the Wi-Fi security detected. If using DHCP, and the network is not presented, choose the “+” icon and enter the appropriate network information.

  • Page 34: Step 3: Spectralink Sip Service

    Spectralink 87-Series Wireless Telephones Deployment Guide Step 3: Spectralink SIP Service After getting the handset on the wireless network, configure the integrated Spectralink SIP service. Follow steps 1-5 of the previous section to get to the Admin Settings section Scroll down and select the “SIP Phone” field.
  • Page 35 Spectralink 87-Series Wireless Telephones Deployment Guide After completing the fields select “OK”.The SIP Status application presents rudimentary SIP registration status information. Try making or receiving a phone call to determine if the handset is correctly communicating with the SIP service. Tap the Dialer icon on the home screen to open the Dialer.
  • Page 36 Spectralink 87-Series Wireless Telephones Deployment Guide 721-0010-000_B.docx February 2014...

  • Page 37: Step 4: Enabling Syslog And Web Api

    Spectralink 87-Series Wireless Telephones Deployment Guide Step 4: Enabling Syslog and Web API Although not absolutely necessary, it might be helpful to enable syslog to a syslog server if you have one available. This may be useful if any problems are found during your deployment.

  • Page 38: Step 5: Updating 87-Series Firmware

    Spectralink 87-Series Wireless Telephones Deployment Guide Step 5: Updating 87-Series Firmware New software can be installed into the 87-Series handset by having the 87-Series handset download new images from a web-server. In the Admin Settings section, scroll down to the “System Update” field that allows an administrator to setup the System Update information, e.g.
  • Page 39 Spectralink 87-Series Wireless Telephones Deployment Guide To have a handset immediately examine the system update web server, go into Settings, then “About Phone” and tap “System Update”. This will force the handset to check the server and proceed to download the new firmware.

  • Page 40: Miscellaneous - Phone Recovery

    After completion, pull down the notification bar, and select the software update. The handset will present a dialog asking to “reboot and apply” or “apply later”. The new 87-Series firmware must retain the filename “ota-update.bin” on the web server. Miscellaneous – Phone Recovery If the handset appears to be in a non-working state, reset the handset by removing &...

  • Page 41: Appendix C: Products Mentioned In This Document

    Appendix C: Products Mentioned in this Document Chrome browser is a trademark owned by Google, Inc. Cisco is a registered trademark[s] of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries. Juniper Networks, Steel-Belted Radius, are registered trademarks of Juniper Networks, Inc. in the United States and other countries.
