Cutout Information - GE Monogram ZEW145 Installation Instructions Manual

Cutout
Information
(Continued)
Cutout
Information:
Multiple
Components
Example
8
If your configuration is not shown in the previous
charts, use the following chart to calculate your cutout
Component/Connector
A = 14-1/2" +
*Endcaps Do Not
Add to Cutout
Cabinetry
size. For each of the following components, add the
dimensions given.
Model/Name
ZEW145 Radiant Cooktop
Component
ZGW124
ZGW125 Gas Component
ZEW166 Downdraft Grill
Component
ZEW155 Updraft Grill
Component
Downdraft Vent
ZEW176 Component
Connection between
two cooktops (including
updraft grill and non-vent
Joiner Strip side of downdraft grill)
Connection between
cooktop and
Downdraft downdraft vent or vent
Joiner Strip side of downdraft grill
Provide finished look to
Cooktop and component cooktop
Downdraft arrangement. Do not
Vent End count as part of
Caps cutout width.
3/4" + 14-1/2" + 1/4" + 5-1/8" + 1/4" +
A
Component Cooktop System
Width Quantity Sub Total Width
14-1/2"
14-1/2"
20-3/4"
15 -3/8"
5-1/8"
3/4"
1/4"
0" 0"
Total Cutout Width
14-1/2" = 49-7/8" Total
*
