GE JP950 Installation Instructions Manual

30" electric cooktop
Hide thumbs

Advertisement

Quick Links

Installation
Instructions
"If you have questions, call 800.GE.CARES or visit our website at:
www.GEAppliances.com"
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
IMPORTANT
instructions for local inspector's use.
IMPORTANT
governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these
instructions for future reference.
• Product failure due to improper installation
is not covered under the Warranty.
WARNING
be properly grounded.
ATTENTION INSTALLER
ALL COOKTOPS MUST BE HARD WIRED
(DIRECT WIRED) INTO AN APPROVED
JUNCTION BOX. A "PLUG AND
RECEPTACLE" IS NOT PERMITTED ON
THESE PRODUCTS.
• Proper installation is the responsibility
of the installer and product failure due to
improper installation is NOT covered under
warranty.
PARTS INCLUDED
4 Screws
Foam Tape
31-10603
(12-04 JR)
30" Electric Cooktop
JP340, JP355, JP910, JP930, JP940, JP950
— Save these
— Observe all
— This appliance must
2 Hold Down
Brackets
MATERIALS YOU WILL NEED
Junction Box
TOOLS YOU WILL NEED
Pencil
Phillips Head
Screwdriver
Ruler or Straightedge
Safety Glasses
1
Wire Nuts
Saber Saw
1/8" Drill Bit & Electric
or Hand Drill

Advertisement

loading

  Also See for GE JP950

  Related Manuals for GE JP950

  Summary of Contents for GE JP950

  • Page 1: Installation Instructions

    Installation 30″ Electric Cooktop Instructions JP340, JP355, JP910, JP930, JP940, JP950 “If you have questions, call 800.GE.CARES or visit our website at: www.GEAppliances.com” BEFORE YOU BEGIN MATERIALS YOU WILL NEED Read these instructions completely and carefully. IMPORTANT • — Save these instructions for local inspector’s use.
  • Page 2: Important Safety Instructions

    Installation Instructions IMPORTANT SAFETY INSTRUCTIONS FOR YOUR SAFETY ELECTRICAL REQUIREMENTS • For Personal Safety, remove house fuse This appliance must be supplied with the or open circuit breaker before beginning proper voltage and frequency, and connected installation. Failure to do so could result to an individual, properly grounded branch in serious injury or death.
  • Page 3: Pre-Installation Checklist

    Installation Instructions PRE-INSTALLATION CHECKLIST WARNING – Remove Installation Instructions from The electrical power literature pack and read them carefully to the cooktop supply line must be shut off before you begin. while connections are being made. Failure to do so could result in serious injury or death. Be sure to place all literature, Owner’s Manual, Installations, etc.
  • Page 4: Preparing The Opening

    This cooktop must be protected with not less kit may be ordered from your GE Dealer. than 1/4″ insulating millboard covered with sheet metal not less than 0.0122″ thick.
  • Page 5: Installing The Cooktop

    Installation Instructions INSTALLING THE COOKTOP INSTALLING THE ATTACH FOAM TAPE JUNCTION BOX Apply the foam tape around the outer edge of the glass. Do not overlap the foam tape. Install an approved junction box where it will be easily reached through the front of the Bottom of Cooktop cabinet where the cooktop will be located.
  • Page 6: Insert Cooktop Into Cutout

    Installation Instructions INSTALLING THE COOKTOP (CONT.) INSERT COOKTOP ATTACH HOLD DOWN INTO CUTOUT BRACKETS TO CABINET Insert the cooktop centered into the cutout Open the cabinet door and screw the hold opening. Make sure the front edge of the down brackets to the cabinet sides with the countertop is parallel to the cooktop.
  • Page 7: Installation-Electrical Connections

    Installation Instructions INSTALLATION—ELECTRICAL CONNECTIONS When making the wire connections, use Once the connections are made, secure the entire length of conduit provided. wires together using wire nuts. The conduit must not be shortened. With the cooktop in place, open the front of the cabinet door.
  • Page 8: Pre-Test Checklist

    Installation Instructions CHECKLISTS PRE-TEST CHECKLIST OPERATION CHECKLIST Remove all protective film, if present, Remove all items from the top and any stickers. of the cooktop surface. Check to be sure that all wiring is secure Turn on the power to the cooktop. and not pinched or in contact with (Refer to your Owner’s Manual.) Verify moving parts.
