Gas Supply Location; Electrical Supply - GE Monogram ZEW145 Installation Instructions Manual

• Gas components are designed to operate on
Gas
Supply
Location
• Gas components cannot be converted to LP
• Make gas connection through the rear wall,
• For rigid connection, locate pipe stub:
For flexible connection, locate pipe stub on
floor or back wall in a convenient location.
• Install a manual shut-off valve in the gas line
Electrical
Supply
natural gas at 4" water column pressure.
These cooktops are supplied with 1/2" NPT
male gas connections. The connection for
models with right hand controls is on the
bottom right corner, and left hand control
models on the left corner.
gas operation.
or on the cabinet floor at the rear.
–4-7/16" from center line of appliance,
–on the back wall, at least 12" below
countertop,
–on the floor, 2-1/2" forward of the back of
the countertop cutout.
in an easily accessible location.
The radiant component operates on 240/208
volt, 60 Hz. Updraft grill and downdraft grill
components operate on 240 volt, 60 Hz. Gas
and downdraft vent components operate on
120 volt, 60 Hz. from a separate junction box.
A dedicated circuit, protected by a time delay
fuse or circuit breaker is required for
cooktops. The downdraft vent requires an
appliance circuit with a time delay fuse of
circuit breaker.
• If local codes permit, more than one cooktop
can be used on the same branch circuit. See
local codes or the National Electrical Code
for circuit demand loads.
WARNING: DO NOT USE AN EXTENSION
CORD WITH THESE APPLIANCES.
ZGW124/ZGW125
Gas and Electrical Supply
Component Cooktop System
4-7/16"
L.H. Gas Unit
R.H. Gas Unit
Gas Supply Options
Important: 12" min. is specified to allow space for shut-off valve
if supply is opted to enter from rear.
Note: Both left and right-controlled gas components are
illustrated together in order to compare their supply rough-in
locations.
ZEW145
ZEW155
ZEW176
2-1/2"
4-7/16" from Rear Edge
of Cutout
12"
Min.
ZGW124
ZGW125
ZEW166
13
