MODEL MR-720
SELF-POWERED AM/FM WEATHER BAND CLOCK RADIO
Please read this Instruction Manual carefully before
using the unit and retain it for future reference
FUNCTIONS AND CONTROLS
1.
BAND SELECT SWITCH
2.
LIGHT SWITCH
3.
CHARGING INDICATOR
4.
LCD DISPLAY with BACK LIGHT
5.
RADIO POWER INDICATOR
6.
SIREN ON-OFF SWITCH
7.
Power Source SWITCH
8.
DYNAMO CRANK HANDLE
9.
TUNING KNOB
10. VOLUME KNOB
11. LAMP HEAD
12. SPEAKER
13. 360° TELESCOPIC ANTENNA
14. BACK LIGHT BUTTON
15. MINIUTE SET BUTTON
16. HOUR SET BUTTON
17. ALARM ON-OFF BUTTON
18. TIME SET BUTTON
19. ALARM SET BUTTON
20. SWAP RADIO/CLOCK DISPLAY
BUTTON
21. PRESET WHEATHER CHANNEL
SWITCH
22. HANDLE
23. AUX-IN JACK
24. DC 6V IN JACK
25. BATTERY COMPARTMENT
1
Advertisement
Table of Contents
Related Manuals for Jensen MR-720
Summary of Contents for Jensen MR-720
- Page 1 MODEL MR-720 SELF-POWERED AM/FM WEATHER BAND CLOCK RADIO Please read this Instruction Manual carefully before using the unit and retain it for future reference FUNCTIONS AND CONTROLS BAND SELECT SWITCH LIGHT SWITCH CHARGING INDICATOR LCD DISPLAY with BACK LIGHT RADIO POWER INDICATOR...
- Page 2 (not included). The specification of the AC adaptor is: 6V DC 200mA with center positive “+” plug. A. “DYNAMO” POWER OPERATION 1. A DC 3.6V rechargeable battery is included with MR-720. When first time using the unit, open the battery compartment and plug the rechargeable battery into the socket as shown.
- Page 3 1. Plug the rechargeable battery into the socket as describe above if required 2. Set the POWER SOURCE Switch to the “PWR OFF” position. 3. Plug the AC adaptor into a standard 120VAC household outlet. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
- Page 4 4. Slowly adjust both the volume controls on your MR-720 and the external device. 5. Turn off your iPod, MP3 player etc. when finish listening. Turn MR-720 off and unplug the AUX IN jack. Remark: Once the AUX IN Jack is plugged, MR-720 will enter the AUX mode automatically no matter what position the BAND Selector Switch (# 1) is in AM, FM, WB or WEATHER ALERT mode.
- Page 5 COMPLIANCE WITH FCC REGULATIONS This equipment has been tested and found to comply with the limits for a Class B digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
