Thank you for purchasing your Nexus Eazy™ filter. We are sure you will be
delighted with its performance. The Nexus System is supplied gravity fed, though
is easily adapted to become a pump fed unit. For pump fed installations refer to
the relevant pages of this brochure and read thoroughly before installation.
The Nexus Eazy filtration unit has been designed on the principles of minimum
maintenance, high performance and a compact foot print. This design delivers
optimum water quality by using the Kaldnes Moving Bed™ process.
Your Nexus Pack should contain:
Figure Part No
1.1 NPC.125
1.2 NAC.1004
1.3 825-50-50
1.4 1200-400/100-400
1.5 5000-707
1.6 MEDIA30L / 45L
1.7 MEDIA50L
1.8 5000-329
Description
4"-4" (110-125mm) rubber boot
4"-2" (122-68mm) rubber boot
1.5"(50mm) single union ball valve
inlet slide plate (200/300)
safety outlet grill
bag Kaldnes K1 for Eazy (30L - 200/ 45L - 300)
50L bag Kaldnes K1 (1x Nexus 200, 2x for Nexus 300)
Eazy isolation pipe
Fig 1.1
Fig 1.4
Fig 1.7
Fig 1.2.
Fig 1.5
Fig 1.8
-1-

INTRODUCTION

Fig 1.3
Fig 1.6
