Page 3: Table Of Contents
INTRODUCTION 4 SYSTEMS Your Regal Owner’s Manual Electrical General Information Fuel 4-10 Regal Warranty Water 4-14 Waste 4-15 1 SAFETY ON BOARD Safety Labels 5 VESSEL OPERATION General Boating Safety Required Safety Equipment Getting Underway Fire Extinguishers 1-10 Fueling Visual Distress Signals 1-12 Starting &...
Page 4 Table Of Contents 6 EQUIPMENT OPERATION 7 COSMETIC CARE & MAINTENANCE Anchor Windlass Automatic Fire Ext. System Cosmetic Care Battery Maintenance 7-11 Battery Charger Battery Management Center 6-10 8 TROUBLESHOOTING Bilge Pump 6-12 Bow Filler Cushions 6-13 Diagnostic Charts Bow Scuff Plate 6-14 Bow Walk-Through Doors 6-15...
Page 5 Introduction Dear Regal Owner, I know I speak for everyone at Regal when I wel- come you to the ever-growing family of Regal boat owners. You’ve chosen a craft that is recognized worldwide for its standard of excellence. Each step...
Page 6 Mission Statement With God’s help and a steadfast commitment to integrity, we will develop a team of exceptional people and relationships to provide exceptional customer satisfaction. INT-6...
Page 7 Introduction THIS PAGE IS LEFT INTENTIONALLY BLANK INT-7...
Page 8 Also, your Regal dealer carries a line of factory approved parts and accessories. Your Regal dealer can provide information regarding national training organizations such as the U.S.
Page 9: Owner's Information Packet
Introduction YOUR REGAL OWNER’S MANUAL Your Regal owner’s manual has been developed to assist you in operating your vessel with safety and pleasure. Be sure to read and become familiar with the contents before operating your craft. Your owner’s manual has been divided into general chapters to assist you in becoming more knowledgable with your Regal boat.
Page 10 It is recommended that you locate and write down the HIN for future reference. It can be especially useful when ordering parts from your Regal dealer. A second HIN number is found in a hidden location. This second HIN is useful to authorities if for example the boat is stolen and the original transom HIN is modiﬁ...
Page 11 Introduction VESSEL INFORMATION SHEET Owner: _______________________________________________ Address: ______________________________________________ City & State: ___________________________________________ Home Phone: Business Phone: _______________ In Case Of Emergency Notify: ___________________________ Address: ______________________________________________ City:__________________________________State: ___________ Phone: _______________________________________________ Insurance Agent’s Name: _________________________________ Policy#: _____________________________________________ USCG Phone: ___________ Local Police: ______________________________________ Marina Phone: _________________ Slip (Dock#): ____________ Hull Serial #: RGM __ __ __ __ __ __ __ __ __...
Page 12: Float Plan
FLOAT PLAN Owner: Safety Equipment Aboard: Address: Life Jackets City & State: First Aid Kit Telephone#: Flares Cell Phone#: Flashlight VHF Radio Person Filing Report: Anchor Name: Compass Home Telephone#: Food Cell Phone #: Water Make Of Boat: Destination: Registration#: Leave From: Length: Time Left:...
Page 13: Launch & Cruise Checklist
Introduction LAUNCH & CRUISE CHECKLIST Obtain a current weather report. Inspect the hull and propeller for damage. Check all electrical system switches for proper operation. If your boat has been in the water, run the bilge pump until the ﬂ ow of water stops. If your boat has been out of the water, check to see that all bilge water has drained out.
Page 14: Electrical
SUGGESTED TOOLS, PARTS & GEAR SUGGESTED TOOLS SPARE PARTS Allen Wrenches Fuel Filter Jack Knife Spark Plugs Phillips Screwdriver Set Water Pump Belt Slotted Screwdriver Set Propellers (Set) Regular Pliers Alternator Belt Combination Wrench Set Anti-Siphon Set Ratchet & Socket Set Propeller Nut &...
Page 15 Introduction Yacht Plate At the helm area on Regal boats 26’ and longer is located an ABYC yacht plate as shown below. This plate represents manufacturers who participate in the National Marine Manufacturer’s Association yacht certiﬁ cation program. This program goes beyond the minimum USCG standards to ensure adherence to the American Boat &...
Page 16 Your boat has undergone rigid quality assurance inspections before leaving the factory. However, your dealer has been trained to perform ﬁ nal pre-delivery checks and to service your Regal boat prior to your pick-up. Your dealer’s responsibilities include: ♦ A complete orientation in the operation of your Regal boat, including matters relating to the safe operation of your craft.
Page 17 Introduction Owner’s Responsibility You are entitled to all the beneﬁ ts and services outlined in your Regal boat warranty. However, you have certain responsibilities to ensure warranty satisfaction. These are: ♦ To read the warranty materials and understand them fully.
Page 18 INT-18...
Page 19 Industries, Inc. warrants to the original retail purchaser of this boat if purchased from an authorized Regal dealer that the selling dealer or Regal will repair or replace the ﬁ berglass hull if it is found to be structurally defective in material or workmanship for as long as the original retail purchaser owns the boat.
Page 20: Registration Information
In addition to above hull warranties, Regal warrants to the original purchaser of this boat if purchased from an authorized dealer that the dealer or Regal will repair or replace any parts found to be defective in materials or workmanship for a period of one (1) year from the date of delivery, subject to all limitations and conditions contained herein.
Page 21: Fuel
(b) Gelcoat surfaces including, but not limited to, cracking, crazing, discoloration or blistering except as noted above; (c) Accessories and items which were not part of the boat when shipped from the Regal factory, and/or any damage caused thereby; (d) Damage caused by misuse, accident, galvanic corrosion, negligence, lack of proper maintenance, or improper trailering;...
Page 22 Regal reserves the right to change or improve the design of its boats without obligation to modify any boat previously manufactured. This limited warranty gives you speciﬁ c legal rights, and you may also have other rights which may vary from state to state. Regal shall in no way be responsible for any PRE-AUTHORIZED...
Page 23: Safety Labels
Safety On Board Safety awareness can’t be over emphasized. Safety on board needs to be the skipper’s number one priority. In this manual you will ﬁ nd many safety precautions and symbols to identify safety related items. Heed all safety precaution information. Remember, the skipper is responsible for the safety of his passengers and crew.
Page 24 Precautionary Labels Read and understand all safety labels afﬁ xed to your Regal boat. Most of the safety labels are found close to the helm, aft cockpit and or swim platform. The location of the labels may vary by model and the label list does not cover everything! Use common sense to analyze the result of an action on board your vessel.
Page 25: General Boating Safety
Safety On Board GENERAL BOATING SAFETY We understand that you are eager to get your Regal boat on the water. However, we strongly suggest that you thoroughly familiarize yourself and friends or members of your family with safe boating practices before setting out.
Page 26 CHAPTER 1 You must provide a Coast Guard approved personal ﬂ otation device (PFD) for every person on board. These PFD’s should be in good condition and easily accessible. Insist that non-swimmers and children on board wear a PFD at all times.
Page 27 Safety On Board Never drink and drive! As captain, you are responsible for the safety of your passengers and yourself. Alcohol and boating can be a dangerous combination. DO NOT mix them. Alcohol impairs the boat operators ability to make conscious decisions and react to emergency situations quickly.
Page 28: Waste
ﬁ re extinguishers, and personal ﬂ otation devices. Encourage a periodic maintenance check on all safety equipment. Contact your Regal dealer or marine professional for more information. Again, remember that the captain is responsible for his passengers and vessel.
Page 29: Required Safety Equipment
Safety On Board REQUIRED SAFETY EQUIPMENT Personal Flotation Devices All personal ﬂ otation devices (PFD’s) must be Coast Guard approved, in good working condition, and must be the correct size for the wearer. All PFD’s must be readily accessible. This means being able to wear them in a reasonable amount of time in case of an emergency (ﬁ...
Page 30 CHAPTER 1 • TYPE I- Also known as an offshore jacket, it provides the most buoyancy. It is a PFD for all waters and is especially useful in rough waters where rescue may encompass additional time. It is designed to turn most unconscious users in the water to a face-up position.
Page 31 Safety On Board • TYPE V- This is the least bulky of all PFD’s. It contains a small amount of inherent buoyancy, and an inﬂ atable chamber. It is rated even to a Type I, II, or III PFD (as noted on the jacket label) when inﬂ...
Page 32: Fire Extinguishers
CHAPTER 1 FIRE EXTINGUISHERS General Information Fire extinguishers are classiﬁ ed by a letter and numeric symbol. The letter references the type of ﬁ re the unit is designed to extinguish. For example, type B extinguishers commonly used on boats are designed to put out ﬂ...
Page 33 Safety On Board U. S. Coast Guard approved ﬁ re extinguishers are required on all Regal boats. Besides the minimum Coast Guard requirements always check state and local agencies for additional requirements and equipment. Coast Guard approved extinguishers are hand-portable, either B-I or B-II classiﬁ...
Page 34: Visual Distress Signals
CHAPTER 1 Another type of liquefied gas is used today in automatic fire extinguishing systems which is used on select models. The canister gas is colorless and odorless, heavier than air and sinks to the lower bilge to extinguish ﬁ res. Since the year 2000 ingredients for ﬁ re extinguishers have changed to a more environmental friendly formula.
Page 35 Safety On Board All in all, each distress signal has certain pros and cons. There is no distress signal that is best under all situations. Pyrotechnics are recognized worldwide as superior distress signals. A downfall is they emit a very hot ﬂ ame that can cause burns and or ignite ﬂ ammable materials.
Page 36: International Distress Signals
CHAPTER 1 INTERNATIONAL DISTRESS SIGNALS POSITION DYE MARKER HAND-HELD INDICATING (ANY COLOR) FLARE RADIO BEACON 1-14...
Page 37: Navigation Lights
Safety On Board SOUND PRODUCING DEVICES According to both Inland and International Rules, all boats must carry some way of producing an efﬁ cient sound signal. If your vessel is 12 meters (39’ 4”) or longer, a power whistle, power horn or bell must be carried.
Page 38 CHAPTER 1 NAVIGATION LIGHT RULES 1-16...
Page 39: Pollution Regulations
Safety On Board MARINE SANITATION DEVICES Recreational vessels under 65’ with installed toilet facilities must have an operable marine sanitation device (MSD) on board. Vessels 65’ and under may use Type I, II, or III MSD. All installed MSD’s must be U.S. Coast Guard certiﬁ...
Page 40 CHAPTER 1 You must immediately notify the U. S. Coast Guard if your vessel discharges oil or hazardous substances in the water. Call toll free 800- 424-8802. Report the following information: location, source, size, color, substances and time observed. Garbage The Act to Prevent Pollution from Ships places limitations on the discharge of garbage from vessels.
Page 41 Safety On Board 1-19...
Page 42 CHAPTER 1 Communications EPIRB It is a good idea to carry communication gear such as a VHF-FM and/or HF transceivers set up for your operating area. Also, cell phones are useful in many coastal areas. Be sure to carry extra batteries. Also, mainly for offshore vessels, EPIRB’s are designed to quickly and accurately alert rescue forces, indicate an accurate distress position, and guide units to the distress scene.
Page 43: Exhaust & Carbon Monoxide
2. Do not disable the carbon monoxide alarms that come with your Regal boat. Test the unit in accordance with the alarm manufacturers instructions. 3. Do not operate the engine for extended periods of time while in a conﬁ...
Page 44 CHAPTER 1 Blockage of exhaust outlets can cause carbon monoxide to accumulate in the cabin and cockpit area even when the hatches, windows, portholes and doors are open. Exhaust from another vessel alongside your boat, while docked or anchored, can emit poisonous CO gas inside the cabin and cockpit areas of your boat.
Page 45 Thoroughly ventilate cabin and cockpit areas. Determine the probable source of the carbon monoxide and correct the condition immediately. Regal has installed CO detectors on your boat. Have these detectors professionally calibrated at regular intervals. To help prevent carbon monoxide accumulation, ventilate your cabin and cockpit while underway.
Page 46 CHAPTER 1 Each Trip Make sure all exhaust clamps are in place and secure. Look for exhaust leaking from the exhaust system components, indicated by rust and or black streaking, water leaks, or corroded or cracked ﬁ ttings. Inspect all rubber exhaust hoses for burned or cracked areas. All rubber hoses should feel soft and be free of kinks.
Page 47: Boating Under The Influence
Safety On Board BOATING UNDER THE INFLUENCE WARNING FEDERAL LAWS PROHIBIT OPERATING A VESSEL UNDER THE INFLUENCE OF ALCOHOL OR DRUGS. THESE LAWS ARE VIGOROUSLY ENFORCED BY ALL ENFORCEMENT AGENCIES. Operating a vessel while intoxicated became a speciﬁ c federal offense effective in 1988.
Page 48 CHAPTER 1 Alcohol Myths And Facts Myth: Beer is less intoxicating than other alcoholic beverages. Fact: One 12 oz. can of beer has about the same amount of alcohol as a 5oz. glass of wine or a shot of liquor. Myth: Black coffee, fresh air, and a shower will sober the effects of alcohol.
Page 49: Boating Accidents
Safety On Board BOATING ACCIDENTS The following is a list of common causes of boating accidents. Be aware of them and take the necessary steps to ensure that your crew and yourself are educated and prepared to act in an emergency.
Page 50 CHAPTER 1 Passengers, especially children that are not wearing the proper life saving devices. Skipper or passengers not seated in the boat. Running a craft that is mechanically marginal. Reporting Boating Accidents According to the Federal Boat Safety Act of 1971 involving collision, accident or other casualty, the operator must make a formal report within 48 hours to the nearest state boating authority when the incident involves:...
Page 51: Water Sports
Safety On Board WATER SPORTS Besides learning the safety precautions for safe boating, as well as understanding and knowing required rules and regulations, you are obligated to be particularly careful around other water sportsman, such as scuba divers, water skiers, wake boarders, and ﬁ sherman. Skin &...
Page 52 CHAPTER 1 General safety procedures for towing skiers and wake boarders include the following: Know your hand signals and make sure all your passengers know them. See the illustration. Do not allow non-swimmers to ski or wake board. You’re asking for trouble! Always have an observer on board whose sole job is to watch the skier/wakeboarder and communicate with the driver.
Page 53 Safety On Board If the skier falls, return promptly to retrieve him, circling wide from the starboard side, to bring his rope within easy grasp. WARNING AVOID SERIOUS INJURY OR DEATH! DO NOT USE SKI TOW FITTING FOR LIFTING OR PARASAILING. THE FITTING COULD PULL OUT OF DECK.
Page 54 CHAPTER 1 WATER SKI & WAKEBOARD SIGNALS FASTER SLOWER CAUTION OR FALLEN SKIER; PICK ME UP SKIER OK AFTER FALL STOP SHUT ENGINE SPEED OK RETURN TO DROP OFF AREA STARBOARD TURN PORT TURN 1-32...
Page 55 Safety On Board WARNING AVOID SERIOUS INJURY OR DEATH! DO NOT OPERATE THE BOAT WITH PEOPLE IN THE WATER OR ON TOP OR HOLDING ON TO THE SWIM PLATFORM STRUCTURE OR HARDWARE. Fishing Most boaters ﬁ sh from time to time. With the propulsion systems of today it is possible to ﬁ...
Page 56: Weather & Water Conditions
CHAPTER 1 WEATHER & WATER CONDITIONS Before a boating outing check the weather conditions. As we all know the weather can change rapidly in many parts of the country. It does so sometimes without being predicted. NOAA weather radio reports are continuously available on designated frequencies installed on VHF radios and various handheld devices.
Page 57 Safety On Board Waves & Fog As the wind blows across water waves are created. The stronger the wind and increased distance across the water enlarges the wave action. Other factors that can cause problem situations for vessels are fog, currents, and tidal changes. Fog can develop inland on clear, calm mornings.
Page 58 CHAPTER 1 Marine Weather Symbols Although the National Weather Service has discontinued the use of the day ﬂ ags and night lights, many marinas and ports of call still display them. 1-36...
Page 59: Rules Of The Road
Rules Of The Road NAVIGATION RULES DEFINED The Navigation Rules set forth actions to be followed by boats to avoid collision. They are referred to as the “Rules of the Road”. There are two main parts referred to as the inland and international rules. The inland rules apply to vessels operating inside the boundaries of the United States.
Page 60: Navigation Rules
CHAPTER 2 NAVIGATION RULES Right Of Way 1. Cross waves at right angles. 2. When caught in heavy water or squalls, head either directly into the waves or at a slight angle. Reduce speed, but maintain enough power to maneuver your boat safely. 3.
Page 61 Rules Of The Road • Sailboats; they have the right-of-way over power boats. However, if a sailboat is using a prop to move forward, it is considered a powerboat even if the sails are up. • Remember the unwritten “rule of tonnage”. Basically a smaller tonnage vessel should take every effort to avoid close quarters with a larger tonnage vessel.
Page 62 CHAPTER 2 NAVIGATION RULES The Navigation Rules set forth 3 types of crossing situations- crossing, meeting, and overtaking. In each case, both boats are governed by special procedures. In a head-on meeting, both vessels must sound a single blast to give way toward starboard and pass to port.
Page 63 Rules Of The Road NAVIGATION RULES An overtaking boat is burdened, and is not the privileged craft, even though it approaches the danger zone of the overtaken boat. The overtaking boat ﬁ rst signals with a single blast if that boat desires to pass on the starboard side of the boat ahead, or a double blast if passing to port.
Page 64: Navigation Aids
CHAPTER 2 NAVIGATION AIDS Navigation aids are placed along coasts and navigable waters as a guide for mariners in determining their position in reference to land and hidden danger. Each aid provides speciﬁ c information. They form a continuous system of charted markers for accurate piloting on paper and on the water.
Page 65 Rules Of The Road LATERAL AIDS Port Side Starboard Side Odd Numbers Even Numbers Chart Symbol Chart Symbol Lighted Buoy Lighted Buoy (Green Light Only) (Red Light Only) Chart Symbol Chart Symbol Can Buoy Nun Buoy (Unlighted) (Unlighted) Chart Symbol Chart Symbol Daymark Daymark...
Page 66 CHAPTER 2 MID-CHANNEL MARKERS Chart Symbol Chart Symbol Chart Symbol REGULATORY MARKERS Diamond Shape Diamond Shape With Cross- Danger Warning Boats Keep Out Circle Marks Area Controlled For showing information such As Indicated as locations, distances and directions...
Page 67: Night Running
Rules Of The Road NIGHT RUNNING Boats operating between sunset and sunrise ( hours vary by state), or in conditions of reduced visibility, must use navigation lights. Nighttime operation, especially during bad weather and fog, can be dangerous. All Rules of the Road apply at night, but it is best to slow down and stay clear of all boats regardless of who has the right-of-way.
Page 68: Bridge Clearance
CHAPTER 2 BRIDGE CLEARANCE Be aware that your vessel requires a speciﬁ ed bridge clearance height. This height is a measured estimate from the waterline to the top of the highest object usually the power tower, radar or the masthead light depending on what tower equipment is installed.
Page 69: Engines
Pay careful attention to the sections on winterization if you live in freezing climates. Extensive damage can result if proper winter storage is not followed. Your Regal dealer has been factory trained on Regal boat systems. Consult your Regal dealer for further information regarding technical issues and parts.
Page 70: Engine Removal
It should be checked after each 50 hours of operation or if the vessel has run aground or hit a submerged object. Alignment should be checked by a Regal dealer or marine professional since special tools and procedures are required.
Page 71 Engines & Controls Catalyst Engines Due to federal and state regulations many newer marine engines are retroﬁ tted from the engine manufacturer with a catalytic converter system for a cleaner environment. The sheer numbers of these engines will ﬁ ll the marine propulsion market over the next few years. Simply stated, a catalytic converter utilizes extreme heat to reduce the engine’s output of hydrocarbons and carbon monoxide thus reducing pollutants.
Page 72: Propulsion
Refer to the engine manual for proper procedures since each stern drive application is unique. Call a marine professional or your Regal dealer for further information.
Page 73 Aluminum prop with paint coming off near blade tip (ventilation symptom). Check the propeller pressed in rubber hubfor slippage. Contact a propeller shop or your closest Regal dealer if any of the above symptoms exist. They have special equipment to refurbish both stainless steel and aluminum propellers. After making any blade alternations the propellers are “re-pitched”...
Page 74: Controls
CHAPTER 3 CONTROLS Instrumentation IGNITION BREAKERS The helm station is equipped with a complete set of instruments that allows you to monitor the condition of the engines.Close observation of the gauges may save the engines from damage. The dash instrument panel is powered and protected by 2 main 20 amp ignition breakers one for each engine circuit located at the dash and connected through the key switch.
Page 75 Engines & Controls Typical Helm Controls Dual Binnacle Control Instrumentation Switch Panel Switch Panel Breaker Panel Stereo Depth Gauge Ignition Switch Blower/Warning Sport Grip Wheel Label Note: Standard helm shown above.
Page 76 CHAPTER 3 Typical Gauge Operation Following is a general description of typical gauge operations. An alert skipper monitors his gauges constantly for any system malfunctions. The gauges are lighted for night operation. Gauges are an early warning system for marine engines just as for automobiles. For more information on speciﬁ...
Page 77 Engines & Controls Fuel Gauge: The fuel gauge indicates the level of gasoline inside the fuel tank. It is a good idea to keep the fuel tanks “topped off ” when possible to reduce fuel vapors inside the tank. Also, do not run the fuel level close to empty to ensure an adequate “safety”...
Page 78 CHAPTER 3 Depth Gauge: The depth g auge is standard equipment on selected models. The depth gauge indicates the water depth under the keel of the boat. It features a shallow water alarm. By monitoring the water depth closely, damage to props and underwater hardware can be avoided.
Page 79 Engines & Controls Other Gauges & Indicators The optional gas vapor detector determines if there is a level of gasoline vapors that is unsafe in the engine room of the boat. If installed, turn on the unit and wait about one minute for it to do its safety test.
Page 80 CHAPTER 3 Located at the helm is another indicator device called a high water alarm. This component warns the skipper of a possible bilge emergency. There is an automatic ﬂ oat device installed at a predetermined bilge level. If water rises over this level the bilge switch sends a signal to the helm mounted alarm.
Page 81: Audible Alarms
Engines & Controls Audible Alarms Most Volvo and Mercruiser engines use audible alarms. They are designed to use sensors which pick up deviations from the normal operating parameters. Oil pressure and temperature sensors send a signal to a buzzer under the dash which sounds a high pitched alarm indicating a possible problem.
Page 82: Ignition Switch
CHAPTER 3 Ignition Switch Each ignition switch features 3 positions. In a clockwise direction they are off, run, and start. The start position is spring loaded and the key should be held in this position to engage the starter. Once the engine has started release the key from the start position.
Page 83 Engines & Controls REMOTE CONTROL OVERVIEW Your vessel uses dual single Forward Reverse NEUTRAL lever binnacle mounted INTERLOCK controls.To help visualize BUTTON the operating principals we have used a clock mode. The levers in the straight-up or 12 o’clock (neutral) position are detented and feature a push button (see illustration) which allows advancing...
Page 84 CHAPTER 3 Typical Binnacle Control You will hear a distinct sound and will “feel” the remote control in the neutral position. If you turn the key to the “start” position and the engine starter doesn’t crank over the engine make sure the remote control is in the neutral position.
Page 85 Systems ELECTRICAL The standard electrical system on board uses a low voltage system called direct current (DC for short). It is referred to as DC because current ﬂ ows one-way in the circuit. Direct Current (12 volt DC) Storage batteries (sometimes called wet-lead cell batteries) furnish 12 volt DC electricity to boat components.
Page 86 CHAPTER 4 WIRE COLOR CODES (solid color/stripe) Color Gauge Function Battery Cable To Engine Black 16 to 4 All Grounds Black/White 16 Halon Fire Extinguisher Brown Water Pressure Pump Brown Aft Bilge Pump/Manual Brown Fwd. Bilge Pump/Manual Brown/Black 10 Overboard Discharge Pump Brown/White 16 Aft Auto Bilge Pump Brown/Red...
Page 87 Systems WIRE COLOR CODES (CON’T.) Color Gauge Function Blue Cabin Light Main Feed Blue/White Transom Courtesy Lights Gray Bow, Navigation Lights Gray/White Mast Light (Fwd. Running) Gray/Black Mast Light (Anchor Light) Red/Black Windlass Up Red/White Windlass Down Gas Vapor Detector, Stereo Remote, Breaker To Dash Feed Leads Main DC Panel Feed...
Page 88 CHAPTER 4 Wire, color, gauge and function shown is used throughout the marine industry. The charts shown on the previous pages are helpful in identifying wire circuitry during troubleshooting or the adding of marine accessories. Never replace a wire with a size other than shown in the chart as a ﬁ...
Page 89 Systems DC Switches Following is a summary of direct current switches used on your Regal boat. Your boat may not use some of the switches mentioned because they represent optional equipment not installed on your vessel. Also, electrical components and speciﬁ cations can change at any time. These switches are illuminated for night operation.
Page 90 CHAPTER 4 (Acc.) Accessory This switch normally is unused at the factory and it may be utilized for any after market equipment installed on the boat. Make sure any added components are matched to the over current protection (fuse). Aft Bilge Pump This switch controls the bilge pump normally located in the aft cockpit under the front of the engine.
Page 91 Systems Exhaust This switch controls the optional Corsa exhaust system available on select engines. When activated exhaust is evacuated through the hull side verses the stern drive. Check with local and state authorities before using the system as various restrictions may be mandated. Fwd.
Page 92 CHAPTER 4 Horn This switch controls the audible electric horn signal. The horn is located at the starboard forward hull. It is protected by a stainless grille cover. Be sure to test the horn before each outing and learn the horn and bridge signals.
Page 93: Battery Switch
If they “blow” due to an overload, they can be replaced at the panel under the helm. Replace with the same amperage and type. Carry extra fuses which are available at marine supply stores or the closest Regal dealer parts department. See the fuse and breaker listing on the next page.
Page 94 Gasoline in the United States and other areas is blended with 10% ethanol and is known as E-10 at the pumps. Marine engines used in your Regal boat may be operated with gasoline blended with no more than 10% ethanol and that meets the minimum octane speciﬁ cation.
Page 95: Fuel System
Systems Fuel System The fuel system consists of a fuel tank, fuel ﬁ ll ﬁ ttings, fuel hoses, fuel vents, anti-siphon valve, internal tank valving, fuel ﬁ lter, fuel gauge and sender. Each one of these components plays an important role in providing an uninterrupted ﬂ...
Page 96 CHAPTER 4 Fuel Vents Currently, domestic EPA compliant fuel tanks vent fumes back into the fuel tank system. While the tank is ﬁ lled, air displaced by the incoming fuel is vented through the fuel system charcoal canister. Your vessel uses a combo type (internal vented) fuel ﬁ...
Page 97: Fuel Filters
Systems Clean or replace a clogged or stuck anti-siphon valve. Contact your closest Regal dealer or marine professional for more information. Fuel Gauge & Sender The dash fuel gauge is only an indication of the on board fuel supply. They are not exact reading instruments. Therefore, use the one third rule discussed earlier for monitoring your fuel supply.
Page 98: Fresh Water
CHAPTER 4 FRESH WATER Your vessel may be equipped with a fresh water supply system. It consists of a water tank, ﬁ ll/ vent ﬁ tting, sink, drain hose, faucet and possibly a washdown or transom shower. Water is supplied by a fresh water pressure pump.
Page 99: Chemical Toilet
Systems WASTE Chemical Toilet Installed as standard equipment on your vessel is a self-contained sanitation device known as a chemical toilet featuring an upper fresh water tank and a lower deodorized tank. These two components can be separated for waste disposal, cleaning and reﬁ lling. The lower tank contains a capacity gauge.
Page 100 CHAPTER 4 TYPICAL CHEMICAL TOILET FLUSHING BELLOWS FRESH WATER TANK DEODORIZED WASTE TANK HOLD DOWN LIFT & PULL FORWARD BRACKET TO REMOVE HEAD UNIT 4-16...
Page 101: Getting Underway
Vessel Operation This chapter explores the many phases of running your vessel from casting off to docking and handling emergencies. We cover the basics but suggest you read other information on the chapter topics. Also, become familiar with your engine owner’s manual since many of the items discussed here are found there in more detail.
Page 102 CHAPTER 5 Is the operator sober, alert and ready to skipper the vessel? Have all passengers been ﬁ tted for life jackets? Has a ﬂ oat plan been ﬁ led and left with a component person? Has the bilge been sniffed and the fuel system leak checked? Are the seacocks open (if applicable)? Is all communication equipment in good operating condition? Has a second person been briefed on operational procedures...
Page 103: Fueling
Vessel Operation Disembarking Questionnaire Have you removed the keys from the ignition and secured them? Have all systems been checked for leaks? Has the battery switch been turned to the “off ” position? Are all seacocks closed? Has the fuel tank been ﬁ lled enough to prevent condensation? Is the vessel properly tied and covered with equipment stored? FUELING DANGER...
Page 104: Before Fueling
CHAPTER 5 NOTICE SINCE GASOLINE IS AVAILABLE IN SEVERAL GRADES INCLUDING ETHENOL & VARIOUS OCTANE LEVELS, REFER TO THE ENGINE MANUFACTURER’S OWNER’S MANUAL FOR THE CORRECT ONE FOR YOUR ENGINE. USING IMPROPER OCTANE FUEL CAN CAUSE ENGINE DAMAGE AND VOID THE WARRANTY. Before Fueling Make sure a working ﬁ...
Page 105: During Fueling
Vessel Operation During Fueling Keep the fuel nozzle in contact with the fuel ﬁ ll to guard against static sparks. The fuel ﬁ ll pipe is grounded through the fuel system wiring to protect against static electricity. Avoid overﬁ lling the fuel tank. Leave room for expansion. Also, if fuel exits the fuel vent indicating the tank is full, this situation is dangerous and unfriendly to the environment.
Page 106: Starting & Stopping
CHAPTER 5 STARTING & STOPPING The following general information covers starting and stopping your engine. Read and understand all previous information on remote controls, fueling and operational procedures. Pay particular attention to all labels. Refer to the engine owner’s manual for in depth propulsion system information.
Page 107 Vessel Operation WARNING GASOLINE VAPORS CAN EXPLODE. BEFORE STARTING ENGINE, OPERATE BLOWER 4 MINUTES AND CHECK ENGINE COMPARTMENT FOR GASOLINE LEAKS OR VAPORS. RUN BLOWER BELOW CRUSING SPEED. CAUTION TO AVOID ENGINE DAMAGE! CHECK THE OIL GAUGE IMMEDIATELY AFTER STARTING. IF LOW OR NO READING SHUT DOWN ENGINE IMMEDIATELY AND INVESTIGATE THE PROBLEM.
Page 108: Steering
Above all, use common sense. STEERING Your Regal uses a rotary or rack style steering system. These systems transfer helm mechanical motion to the engine. There is a hydraulic steering cylinder which with the assistance of a steering pump sends ﬂ...
Page 109 Vessel Operation...
Page 110: Fenders
CHAPTER 5 FENDERS Fender Usage Fenders are normally made of a rubberized plastic and are usually ﬁ lled with air. Most have a ﬁ tting like a basketball so they can be inﬂ ated or deﬂ ated. Fenders are available in a wide range of sizes and shapes to ﬁ...
Page 111: Dock Line Basics
Vessel Operation DOCK LINE BASICS Most skippers use dock line terminology fairly loose but there is more to the basics than just bow or stern lines. There are several lines that can be secured to the bow and stern and depending on their direction and use, can be called other names.
Page 112 CHAPTER 5 Bow springs are secured at the vessels bow area. Forward spring lines lead forward from the boat to the dock and control movement toward the stern. After springs stem aft from the vessel, and stop movement ahead. Spring lines are used to prevent movement in a berth, ahead or astern.
Page 113 Vessel Operation The bow and stern lines should be relatively at a 45 degree angle with the dock. The stern line can be attached to the near-shore quarter cleat, but will work more efﬁ ciently to the offshore quarter cleat. The longer line will allow the boat ﬂ...
Page 114 CHAPTER 5 reverse the process. Secure a little slack in the other dock line, then slip your eye up through its loop and over the top of the pile. Your line can be dropped through the other eye. When debarking from a dock, it is easier to release the line from a cleat or piling, from on board the boat, as soon as you leave the dock.
Page 115: Twin Stern Drive Systems
Vessel Operation STERN DRIVE DOCKING Twin Stern Drive Systems As a general rule, inboard/outboard twin powered boats are fairly easy to back up and maneuver with a little knowledge and docking practice. One of the most important aspects of the docking and/or maneuvering process is to keep your calm in the wake of a busy marina.
Page 116: Twin Stern Drive Maneuvering
CHAPTER 5 Twin Stern Drive Maneuvering Twin stern drive vessel propellers are counter-rotating which will bal- ance steering torque. On most twin stern drive vessels the port pro- peller is left-handed and the starboard propeller is right-handed. Mark the propellers in case they ever to be changed or repaired at some point as they could be mismatched on reinstallation since they both ﬁ...
Page 117: Gathering Headway
Vessel Operation Gathering Headway As opposed to a boat with a single propeller, when a twin stern drive vessel’s engines are put in gear together, the vessel will make headway without the tendency to pull to the port or starboard. Of course the throttles must be in the same rpm range as read on the tachometers.
Page 118 CHAPTER 5 Turning When maneuvering at slow speeds the steering wheel is not normally used; the skipper uses the shift and throttle handles to control the vessels actions. A vessel’s stern may be pushed to one side or the other by mov- ing ahead or reversing with just one propeller.
Page 119 Vessel Operation Backing Down The twin stern drive vessel can use the throttles to slow down one or both engines as a help to steering when maintaining sternway. As an option, the skipper is able to stop one set of propellers for a higher control factor in reverse.
Page 120: Trim Angle
CHAPTER 5 TRIM ANGLE Stern drive boats have the ability to angle in or out their drive unit in relationship to the transom. This is accomplished by hydraulic shocks located on the stern drive along with an electrical sender unit that reads the drive angle and sends information to the dash trim gauge showing a reading.
Page 121 Vessel Operation Use Of Power Trim The power trim is normally used prior to accelerating onto a plane, after reaching the desired RPM or boat speed and when there is a change in water or boating conditions. Position passengers and equipment in the boat so that the weight is balanced correctly fore and aft as well as side to side.
Page 122 CHAPTER 5 Operation In “Bow Up” Position The “Bow Up” or out position is normally used for cruising, running with a choppy wave condition, or running at full speed. Excessive “bow up” trim will cause propeller ventilation resulting in propeller slippage. Use caution when operating in rough water or crossing another boat’s wake.
Page 123: Shallow Water Operation
AND STEERING TORQUE CAN ALSO VARY DUE TO CHANGING WATER CONDITIONS. IF YOU EXPERIENCE BOAT INSTABILITY AND/OR HIGH STEERING TORQUE, SEE YOUR AUTHORIZED REGAL DEALER. Shallow Water Operation Operating your vessel in shallow water presents various hazards. You are more apt to hit a...
Page 124 CHAPTER 5 TRIMMED “TO FAR IN” POSITION TRIM TRIMMED “TOO FAR OUT” POSITION TRIM WELL TRIMMED “LEVEL” POSITION TRIM CAUTION DO NOT RUN ENGINE ABOVE 1000 RPM WITH THE STERN DRIVE TRIMMED FOR SHALLOW WATER MANEUVERING SINCE THE STERN DRIVE IS OUT BEYOND THE GIMBAL RING SIDE SUPPORT BRACKETS.
Page 125: Anchoring
Selecting the correct anchor is an important decision. The anchor style in part depends on the usage and boat type. Regal boats designate an anchor type and or model. Some models incorporate chain, line with an optional windlass. Contact an authorized Regal dealer for more information.
Page 126: Towing
CHAPTER 5 If two anchors are used ahead of a boat, make sure to set the rodes at an angle than in a straight line to reduce the chances of tangeling as the boat moves in wind and current. See the above illustration. TOWING In case you ﬁ...
Page 127: Law Of Salvage
Vessel Operation Law Of Salvage The Admiralty law sometimes referred to as the salvage law was founded primarily on English law fundamentals and basically says that a vessel distressed, in danger of ﬂ ounder, if rendered assistance from a towing company or private agency, can be forced to relinquish a portion of the vessels’...
Page 128 CHAPTER 5 DANGER AVOID DEATH OR SERIOUS BODILY INJURY! DO NOT USE DECK HARDWARE INCLUDING CLEATS FOR TOWING. Knots Knots are useful in docking, towing and other emergency situations. Learning to tie knots requires practice. As they say “ Practice makes perfect”.
Page 129: Emergencies
Vessel Operation EMERGENCIES Always be ready to help others on the water if possible, but do not take any unnecessary risks. Use equipment to save a life, but do not risk a life to save equipment. Consult earlier information in this manual concerning accidents, etc.
Page 130: First Aid
CHAPTER 5 FIRST AID Knowing ﬁ rst aid can save lives. A ﬁ rst aid kit and the ability to use it are important ingredients for the safety of a skippers’ passengers, crew and vessel. Having conﬁ dence and competence in handling medical emergencies on board is a must for the skipper.
Page 131: Hypothermia
Vessel Operation HYPOTHERMIA Hypothermia is a condition where the body temperature decreases because the body can’t generate enough heat to maintain its normal temperature. It can be serious and usually occurs where victims have been immersed in water (under 68 degrees) for extended periods of time.
Page 132: Environmental Awareness
CHAPTER 5 ENVIRONMENTAL AWARENESS There are numerous vessels operating on our waterways on a daily basis. Each boat has as impact on our environment. Boat operation habits, marine sanitation, and maintenance all play a role in a delicate battle to keep the ecosystem clean.
Page 133: Equipment Operation
A portion of the equipment described may not be installed on your boat or the pictorials may not exactly match your components. A portion of the Regal boat illustrations in this owner’s manual may represent typical examples.
Page 134: Anchor Windlass
CHAPTER 6 Anchor Windlass If installed the optional windlass featrues a stainless s t e e l a n c h o r c o m p l e t e w i t h swivel. A 50 amp breaker for windlass o v e r c u r r e n t protection is located a t t h e b a t t e r y...
Page 135: Automatic Fire Extinguisher
Equipment Operation Automatic Fire Extinguisher T h e a u t o m a t i c f i r e extinguishing system is located in the bilge. See the illustration. The system uses an environmentally friendly agent FE-241 which has been approved by the EPA to replace the old Halon agent.
Page 136 CHAPTER 6 The system will show actuation whenever the ignition key is ON and the indicator light is OFF. The actual actuation time when a ﬁ re occurs is dependent on the severity of the ﬁ re. When the automatic ﬁ re extinguisher activates IMMEDIATELY SHUT DOWN ALL ENGINES, POWERED VENTILATION (BLOWER), ELECTRICAL SYSTEMS AND EXTINGUISH...
Page 137 Equipment Operation Operation-Manual If a fire has started in “FIRE” the engine compartment HANDLE where the automatic fire extinguisher system is located, do not wait for automatic activation. Release the system manually. Close any opened hatches leading to the engine compartment, shut down all forced ventilation devices, e n g i n e s, a n d e l e c t r i c a l...
Page 138 CHAPTER 6 Premature opening of the compartment could cause a reﬂ ash. When opening the engine compartment for inspection have hand held portable extinguishers ready. Inspect the pressure gauge and system before and after each outing. Refer to the maintenance chapter for caring for your ﬁ re extinguisher system.
Page 139: Battery
Trickle charge as needed placing battery on wood in a well ventilated area free from any gas or propane appliances. Contact your closest Regal dealer for further battery information and service schedules.
Page 140: Battery Charger
CHAPTER 6 Battery Charger As an option, a battery charger features a 15 amp fe- male plug mounted in the cockpit (see illustration). When outﬁ tted with an approved extension cord the system assists in charging the house and cranking sys- tem batteries through the battery management panel.
Page 141 Equipment Operation 5. Note: Make sure the extension cord does not lay in the water, is not frayed and features a working ground prong. 30 AMP BATTERY CHARGER Read and understand the following warning before using the battery charger system. WARNING AVOID SERIOUS INJURY OR DEATH FROM FIRE, EXPLOSION OR ELECTRICAL SHOCK!
Page 142: Battery Management Panel
CHAPTER 6 Battery Management Panel Your vessel features a battery management panel located at the starboard cockpit area. This battery management panel includes twin battery switches. The port on/off style battery switch controls the house battery functions. The circuit is protected by a 150 amp circuit breaker located close to the sump battery bank.
Page 143 Equipment Operation Voltage Sensitive Relay Module (VSR) Located next to the battery switches on either side of the battery management panel are 2 voltage sensitive relay modules. The purpose of the VSR is to protect the battery circuit from being discharged. Also, when the engine batteries are fully charged it can send current to the house battery.
Page 144: Bilge Pump
CHAPTER 6 Bilge Pump/Automatic Float Switch AUTOMATIC FLOAT SWITCH Before each outing check the operation of the bilge pump and automatic switch. CHECK With the dash switch in the FOR DEBRIS automatic position manually pick up the automatic switch or you can activate the switch BILGE by throwing a bucket of water PUMP...
Page 145: Bow Filler Cushions
Equipment Operation Bow Filler Cushions Simply place the optional port and starboard filler cushions and the forward center cushion between the seat sections to form twin bow sunpad. Be sure to store the cushions when not in use in the starboard ﬂ...
Page 146: Bow Scuff Plate
CHAPTER 6 Bow Scuff Plate Your vessel features a stain- less steel bow scuff plate. This stainless steel plate protects the ﬁ berglass bow area from scuff- ing. The innovative design helps protect the boat bow when us- ing the anchor especially in foul weather conditions.
Page 147: Bow Walk-Through Doors
Equipment Operation Bow Walk-Through Doors Walk-through bow doors are great in foul weather. With the tonneau cover in place, simply open the doors and pull across the bow opening. Secure shut. If installed, close the ton- neau cover. To store, fold against the walk-thru and secure in place.
Page 148: Breaker Panels
CHAPTER 6 Breaker Panels Your vessel features 2 main breaker panels. One of these panels is lo- cated at the helm area. Become familiar with the components that this panel protects. Should a breaker “pop” ﬁ nd the cause of the problem before resetting the breaker.
Page 149 Equipment Operation An auxiliary breaker panel is located in the head. Below is an explana- tion of selected breakers on this 12 volt panel. Compartment Lights- This breaker protects the head light and the light beneath the helm area. Head- This breaker protects the toilet. Vent- This breaker protects the head fan.
Page 150: Canvas
CHAPTER 6 Canvas Typical PowerTower In “Up Position w/Sunshades 6-18...
Page 151 Equipment Operation Canvas-Sunshades w/PowerTower TYPICAL INSTALLATION Note that on typical canvas installation the canvas boot zipper does not unzip completely to the center. This allows you to hold the forward sunshade and make it easier to install. 6-19...
Page 152 CHAPTER 6 Canvas Notes: While cruising all sunshades and bimini tops should be zipped in the boot to avoid damage due to wind or sea conditions as well as from possible higher cruising and/or highway speeds. On typical canvas installations, canvas straps are at times noisy when underway.
Page 153 Equipment Operation Cockpit Cover The optional cockpit cover installs over the windshield and snaps to the deck.To i n s t a l l t h e cockpit cover, start at the bow TYPICAL COCKPIT COVER area. Complete snapping the canvas to the outside and then down each gunnel to admidships.
Page 154 ﬁ t the pole. If equipped, select poles are adjustable. You may want to purchase an optional storage (mooring) cover. They can be ordered from your authorized Regal dealer. 6-22...
Page 155 Equipment Operation Canvas- Typical Storage (Mooring) Cover 6-23...
Page 156 CHAPTER 6 TYPICAL STORAGE COVER RATCHET STRAP If installed, ensure the ratchet strap is tight and tie cover securely. In colder climates check periodically for proper ﬁ t in off season storage. 6-24...
Page 157: Cockpit Carpet
Equipment Operation Cockpit Carpet Cockpit carpet features a forty ounce weight with an “aqua tread” slip resistant backing. As required, snaps are installed. W h e n s t o r i n g t h e carpet, roll it up verses folding it.
Page 158: Cockpit Table
CHAPTER 6 Cockpit Table Optional cockpit tables may be installed. When using a table ensure the table pedestal leg is installed in the receiver securely. Pull the latch pin and hold until the table pedestal leg slides in the receiver sleeve.
Page 159: Cockpit Refreshment Center
Equipment Operation Cockpit Refreshment Center The cockpit refreshment center features a Corian countertop with stainless steel sink, strainer, and under counter portable cooler. Other components of the system include a fresh water tank, pressurized 1 2 vo l t p u m p c o l d water sink and cockpit washdown.
Page 160: Cockpit Refrigerator
CHAPTER 6 Cockpit Refrigerator If installed, the cockpit refrigerator is located at the helm area walk through. The unit operates from 12 volts and features a ice tray and brushed stainless steel door. To regulate the temperature there is a control knob positioned near the refrigerator rear wall .
Page 161: Drain Plug
Equipment Operation Drain Plug CAUTION TO PREVENT VESSEL FROM SINKING, INSTALL DRAIN PLUG! Your boat is equipped with a garboard TIGHTEN-CLOCKWISE style drain plug. Make sure it is tightly installed before launching. Tighten with a wrench. Do not use your ﬁ ngers alone.
Page 162: Depth Finder
CHAPTER 6 Depth Finder/Sounder In theory the depth ﬁ nder picks up a bottom signal sent through a transducer to the helm gauge unit which is converted to readings in feet, meters, or fathoms and displayed on the gauge. The unit features shallow or deep water alarms, both of the audio and visual type, and keel offset.
Page 163 Equipment Operation Operation Power On. When the helm is powered up by the key switch 12 volt DC energy is available at the depth gauge along with the remainder of the instrument cluster. You do not need to press the “ON/OFF MODE”...
Page 164 CHAPTER 6 Keel Offset. By pressing the “ON/OFF MODE” keypad again displays the “KL” keel offset setting. It can be set so the depth ﬁ nder shows the depth below the transducer or the depth under the keel. Press the “UP”...
Page 165: Docking Lights
Equipment Operation Docking Lights If equipped, docking lights are integrated into the hull. They are very useful for night docking and maneuvering. To operate turn on the helm switch marked “docking lights”. Typical Docking Lights 6-33...
Page 166: Engine Hatch
CHAPTER 6 Engine Hatch The engine hatch is controlled by a cockpit switch which when energized uses dual actuators synchronized to lift the hatch. Under the port aft cockpit lounge seat is an access hatch. This permits the hatch pin to be pulled in the event of a “dead”...
Page 167: Fresh Water System
Equipment Operation Fresh Water System (Pressurized) Feed Hose Sender Hold Down Strap Typical Water Tank The fresh water tank level is located under the cockpit ﬂ oor. The ca- pacity is approximately 29 gallons. A feed hose connects the system to the fresh water pump/stainer for distribution purposes.
Page 168 7. Clean the pressure water ﬁ lter periodically by disassembling the ﬁ lter element and rinsing in fresh water. Ensure the pump switch is off. Replace and check for leaks. For parts, contact an authorized Regal dealer. CAUTION...
Page 169: Gas Vapor Detector
Equipment Operation Gas Vapor Detector If equipped, a gas vapor detector is a state of the art fume montoring and alarm system. It ia highly effective detector of engine compartment gasoline fumes from unburned hydrocarbons wmitted from faulty exhaust systems and hydrogen battery vapors. The unit operates with a head unit at the helm, a sensor located in the bilge installed just above the normal accumulation of oily bilge water.
Page 170 CHAPTER 6 Immediately have all passengers and crew exit the passenger compartment. If an explosion or ﬁ re should occur, the probability of injury will be greatly reduced if no one is in a conﬁ ned area of the vessel. IN THE EVENT OF AN ALARM: NOTE: IT IS IMPORTANT TO UNDERSTAND THAT AN ALARM WOULD NOT OCCUR UNLESS A PROBLEM EXISTED.
Page 171 Equipment Operation WARNING AVOID INJURY AND DEATH! GASOLINE VAPORS CAN EXPLODE! OPERATE BLOWER FOR AT LEAST 4 MINUTES AND CHECK THE ENGINE COMPARTMENT AND BILGE FOR GASOLINE VAPORS. RUN BLOWER BELOW CRUISING SPEEDS. 6-39...
Page 172 CHAPTER 6 Gray Water System The gray water system option consists of a holding tank along with a deck mounted waste pump-out ﬁ tting. Water from a cockpit refreshment center or head sink normally exits the boat at a through hull ﬁ tting. With the gray water system any used potable water is stored via the drain system to a holding tank through the use of a sump type pump and container..
Page 173: Grill
Equipment Operation Grill If installed the marine gas grill uses small bottles of propane as a fuel source. Grill receivers are located on the AFT swim platform area and this is the only approved location for grilling. Read and understand all instructions before using the grill.
Page 174 CHAPTER 6 13. When installing a propane bottle make sure it is screwed into the receptacle tightly. Use a spray bottle with soapy water to check for leaks. See the information on gas leaks. 14. Never tr y to adjust the regulator.
Page 175 Equipment Operation Typical Gas Grill-Operating Instructions • A universal mount is required to attach the grill to the deck ﬁ tting. • Fit the grill-mount assembly to the grill and into the deck ﬁ tting. Make sure the grill is positioned securely. •...
Page 176 CHAPTER 6 • Turn the grill on high. Make sure there is heat coming from the unit. If after 10 seconds the burner has not ignited or your ﬂ ame has gone out turn the unit off and wait 1 minute for the propane to dissipate. •...
Page 177 Equipment Operation Gas Leaks 1. Extinguish all ﬂ ames, smoking materials and turn engines off. 2. Turn off the grill knob. To determine the source of the gas leak: 1. Screw on the propane tank until secured. 2. With the grille in a well ventilated area and the burner turned off do the following.
Page 178: Ladders
CHAPTER 6 Ladder-Transom Your vessel is equipped with a stainless steel transom boarding ladder. Be sure all body parts are clear of the ladder when folding the ladder up or down and repositioning it under the swim platform. Be sure to read and understand any written warnings posted Typical Aft Ladder...
Page 179: Lighting
Equipment Operation Lighting-Stern/All Around Power Towers use an all-around light which is mounted at the center of the tower top. It is controlled by the navigation-anchor helm switch. It must be used between dusk and dawn and must be lighted when the vessel is stopped or anchored at night and shall be visible 360 degrees.
Page 180: Powertower
CHAPTER 6 PowerTower As part of the innovative design the tower hinges forward for tight overhead clearances such as bridges and restricted storage situations. The tower features an aluminum framework and a multi-layered ﬁ nishing process. Typical Power Tower- Sunshades In “Up Position The power tower hinges forward for tight overhead clearances such as bridges and restricted storage situations.
Page 181 Equipment Operation Sunshades Zipped In Boots Typical Power Tower Shown In Booted Cruise Position Typical Power Tower Shown In Full Forward Tilted Position 6-49...
Page 182 CHAPTER 6 Typical Hing ed Power Tower Hydraulic Actuator Typical Power Tower 6-50...
Page 183 Equipment Operation The power tower can be hinged forward for clearance purposes. Normally one of the switches at the helm area is designated as arch or tower. It connects to a lift motor and a set of hydraulic rams that raise or lower the wakesport tower through the switch.
Page 184: Seating
CHAPTER 6 Seating-Double Helm w/Flip-Up Bolster T he double wide helm seat can be moved forward or aft with a lever located under the seat. Lift up on the lever while pushing the seat aft or forward.Also, located at the forward end of the seat is a ﬂ...
Page 185 Equipment Operation Seating/Typical Bow-Arm Rests Your vessel features bow seating arm rests. To use the arm rest simply push down on the top of the arm rest until it falls in place. To fold away pull up on the arm rest until it rests against the bulkhead.
Page 186 CHAPTER 6 Seating w/Multi-Position Back Rests Your vessel feaures 6 position aft seat/sun lounger. Using the handle on the port forward lower section of the seat you can push or pull on the lever which will change seat positions from a seat to a lounger with one additional back rest in between position each way.
Page 187 Equipment Operation T he backrest can be positioned as to form a sun lounge head support or the headrest can be angled up for aft viewing as shown in the lower photo. There is also one backrest in AFT FACING SUN LOUNGE WITH between position.
Page 188: Sirius Satellite Radio
CHAPTER 6 Sirius Satellite Radio If installled, Sirius satellite radio features over 120 channels of music entertainment completely commercial-free along with sports and news channels. Sirius emphasizes the music and entertainment you want. Channels use the most updated digital ﬁ ltering available for the clearest sound.
Page 189: Ski Tow Pylon
Equipment Operation Ski Tow/Pylon As an option, a water sports ski pylon is located center line at the stern platform. Double loop the line ﬁ rst through the hole and then around the ski pylon and cinch it tightly. This procedure helps to keep the line intact when there is no strain on it.
Page 190: Stereo
CHAPTER 6 Stereo/CD Player- Fusion Regal boats feature Fusion® marine stereo audio systems. Fusion stereo systems are designed and engineered to perform to the highest stan- dards in the harsh marine en- vironment. The head units use easy to read displays, oversized...
Page 191 Equipment Operation 6-59...
Page 192 CHAPTER 6 6-60...
Page 193 Equipment Operation 6-61...
Page 194 CHAPTER 6 6-62...
Page 195 Equipment Operation 6-63...
Page 196 CHAPTER 6 6-64...
Page 197 Equipment Operation 6-65...
Page 198 CHAPTER 6 Stereo Remote Control If equipped, the Fusion stereo remote control is normally mounted at the transom area which makes it easier to use during water activities. It is a plug and play device and uses the same function buttons and rotary encoder as the helm head unit.
Page 199 Equipment Operation 6-67...
Page 200 CHAPTER 6 6-68...
Page 201 The circuit is protected by a 30 amp breaker. The ampliﬁ er does not require any type of maintenance other than periodic checking of the wiring connectors for tightness. Refer to your Fusion owner’s manual or contact your closest Regal dealer for additional information. 6-69...
Page 202 CHAPTER 6 Stereo iPod An iPod adapter is located inside the face of the FUSION stereo as standard equipment. Using a set of top and bottom sleeves it is able to ﬁ t most iPod versions. Refer to the FUSION stereo instruction manual for further informa- tion on sleeve speciﬁ...
Page 203: Swim Platform
Equipment Operation Swim Platform Periodically inspect the swim ladder and platform support hardware to insure that all connections and ﬁ ttings are tight and in a non-corrosive state. Never dive off the swim platform. Do not store or add objects to the swim platform since additional weight will affect steering and maneuvering characteristics of the vessel.
Page 204 CHAPTER 6 Swim Platform-Flexiteek Flexiteek decking available on selected models features signiﬁ cant advantages over similar wood products. It is Typical Flexiteek Platform made from synthetics. Color is as natural as timber and uniform through the entire thickness adding to its appeal. It sands like wood resulting in a natural wood look and feel.
Page 205 Equipment Operation Toilet-Chemical Before each outing make sure Fill Bellows the chemical toilet is ﬁ lled with the proper chemicals, paper is available, and the holding tank is empty. To fill the toilet read and follow all the manufacturer’s recommendations for mixing the solution.
Page 206: Toilet
CHAPTER 6 Toilet-(Vacuum)Suction Style Flush A suction style ﬂ ush electric toilet is available on your vessel as optional equipment. This toilet operates in a different way from other marine toilets. The system uses around 16 ounces per liquid or solid ﬂ ush which is a substantial water savings over other systems.
Page 207 Equipment Operation The system uses a combination of suction and water ﬂ ow from the fresh water tank to clear the head of waste. The system components including the hose are formulated for the transfer of sanitary waste only. Do not allow the following items in the system: Strong acid or caustics such as drain openers, petroleum solvents or fuels, alcohol based products such as antifreeze and pine oil products along with sanitary napkins and baby diapers.
Page 208 CHAPTER 6 Pull fresh water pressure pump switch to activate unit. The fresh water pressure pump is protected by a 10 amp breaker. Note 2: Additional equipment on the 12 volt panel is protected by individual breakers. If component fails to operate check breaker for “open”...
Page 209 Equipment Operation The holding tank level needs to be monitored periodically for content fullness. Do not operate the waste system when the holding tank is full. Before venturing out on a cruise it is a good idea to have the holding tank pumped out.
Page 210 CHAPTER 6 Toilet-Electric w/Overboard Discharge Pump Federal regulations pro- SEACOCK hibit pumping waste overboard within territorial limits of the United States. Check with authorities regarding spe- HANDLE IN CLOSED POSITION ciﬁ c laws and regulations before attempting pump waste overboard. 1.
Page 211 Equipment Operation Toilet-Electric w/Pump Out Fittings As an option electric toilets feature a deck ﬁ tting that permits a marina or waste station to pump out the vessel waste or holding tank. A hose attachment screws into the deck fitting and removes the waste in the vessel toilet holding tank by activating a land pump.
Page 212: Through-Hull Exhaust
CHAPTER 6 Through-Hull Exhaust Select optional engine packages permit the exhaust to exit above the waterline at the hull side verses the normal stern drive underwater passageways. There is a helm switch which activates the device. When the switch is off the exhaust exits through the stern drive. Refer to the appropriate engine operator’s manual for further information.
Page 213: Trim Tabs
Equipment Operation Trim Tabs PORT ROCKER STBD. ROCKER TRIM TAB SWITCH Trim tabs if installed are located on the lower hull on the transom. Water is deﬂ ected and redirected as the trim tabs are raised and lowered from the starboard located trim tab switch.
Page 214 CHAPTER 6 Obtaining A Trimmed Postition Your vessel will reach a planing position at a speciﬁ c speed. This speed is determined by bottom design, weight distribution, water conditions, and on board equipment. As the throttle is advanced the stern squats and the bow rises initially.
Page 215 Equipment Operation Sometimes you can watch the bow spray or stern wake and the rooster tail (mound of water produced by stern drives). In a bow up position the spray is far aft to the hull, the wake is high and the rooster tail is high.
Page 216 CHAPTER 6 Porpoising Porpoising is a running condition where the bow “bounces” up and down similar to a porpoise’s swimming motion. This condition is normally caused by the trim being too far “up” as indicated on the trim gauge. Press “bow down” in one-half second bursts and the porpoising should recede and the vessel speed should increase.
Page 217 Equipment Operation Underwater Lights As an option light bars w/ sealed LED bulbs make up the under- water lighting system. The lights are located on the transom. There is a dash switch for energizing the lights. The underwater lights circuit protection fuse is found at the helm breaker panel fuse block and is rated at 10 amps.
Page 218: Windshield
CHAPTER 6 Windshield BRACES OPENING CENTER WINDSHIELD The typical windshield features tempered marine safety glass. The unit is tinted and gasketed to deﬂ ect water. The windshield is supported by a port and starboard brace. Periodically check the brace hardware for tightness.
Page 219: Cosmetic Care & Maintenance
Cosmetic Care & Maintenance COSMETIC CARE This section covers the care and maintenance of your boat. Many cosmetic care topics including exterior hardware, upholstery, ﬁ berglass and canvas are covered along with major equipment and systems. As always, refer to the owner’s information packet and the appropriate engine manufacturer’s owner’s manuals for further detailed instructions.
Page 220: Cockpit Carpet
CHAPTER 7 Powdered abrasives, steel wool, or industrial strength cleaners are not recommended for cleaning our vinyl. Lacquer solvents will cause immediate damage. Dilute chlorine bleach before using. Do not wax the vinyl as it may cause cracking. Always wear protective gloves and make sure there is sufﬁ...
Page 221: Interior Fabrics
Cosmetic Care & Maintenance Interior Fabrics Clean ﬂ at good interior fabrics with dry cleaning ﬂ uid style cleaners ap- proved for use with soft fabrics. Allow adequate ventilation and follow the label instructions carefully. Normal interior vinyl such as used on the headliner on cruisers and head clean up with a mild soap and water solution.
Page 222 CHAPTER 7 Use a mild detergent such as dishwasher powder or liquid. Do not use automatic dishwasher detergent. Avoid any kind of alkaline cleaners such as trisodium phosphate (TSP), abrasives, bleaches and ammonia. For best results use cleaners that are recommended for ﬁ berglass. NOTICE WIRE BRUSHES, SCOURING PADS, OR OTHER ABRASIVE TYPE MATERIALS AND SOLUTIONS...
Page 223: Minor Repairs
Specify a number 25 which is a coarser compound up to a number 55 being less coarse. Various glazes and polishes are available as needed. Ask your marine professional or Regal dealer for more information. Fiberglass hulls are strong but they can be damaged.
Page 224 CHAPTER 7 For minor repairs refer to the following procedure: 1. Clean the area to be repaired and get rid of any wax or grease residues. 2. Clean out scratches, chips, and nicks. 3. Sand area to be repaired so gelcoat will bond. 4.
Page 225: Sunbrella Cleaning Instructions
Cosmetic Care & Maintenance These elements can cause serious damage if left unchecked. The boat top and other canvas supplied on your Regal boat are manufactured from top quality materials to provide you with years of trouble free service. The following information on the care, cleaning...
Page 226 CHAPTER 7 Soak the fabric in a solution that has been mixed to the following proportions.: 1/2 cup of bleach and 1/4 cup of Ivory or Lux soap (liquid or soap) per each gallon of lukewarm water. Allow the fabric to soak until the bleach has killed the mildew and the stains can be brushed out with a common kitchen scrub brush.
Page 227: Hull Bottom
Contact a marine professional or Regal dealer for more information.
Page 228 CHAPTER 7 FREQUENT STAINS/CLEAN-UP STEPS 1 Coffee, Tea, Chocolate........Permanent Marker*........Household Dirt..........Grease............... Ketchup, Tomato Products......Latex Paint............Oil Base Paint..........Mustard............. Suntan Oil............Asphalt/Road Tar........... Crayon.............. Engine Oil............Spray Paint............Chewing Gum..........Shoe Polish*............. Ballpoint Pen*..........Lipstick............. Eyeshadow............Mildew*............
Page 229: Maintenance
Cosmetic Care & Maintenance MAINTENANCE Automatic Fire Extinguisher If installed the automatic ﬁ re extinguisher system should be checked for tightness at the engine compartment monthly. At that time the unit itself should be weighed to ensure it is full. If the green dash indicator light is not on when the key is in the ignition position there is a system malfunction that must be investigated immediately.
Page 230: Battery System
CHAPTER 7 Battery System Frequently check your battery terminals for corrosion build-up. If you ﬁ nd a greenish, powdery substance, remove the cable connections and clean both the both the terminals and the connectors with a wire brush. When the cleaning is ﬁ nished recon- nect the battery cables and coat the terminal with an approved grease or petroleum jelly to help prevent further corrosion.
Page 231 Cosmetic Care & Maintenance WARNING TO PREVENT BODILY INJURY! BATTERIES CONTAIN SULFURIC ACID (POISON) WHICH ALSO CAN CAUSE BURNS. AVOID CONTACT WITH THE SKIN, EYES & CLOTHING. IF CONTACTED, FLUSH WITH WATER AT LEAST 15 MINUTES. IF SWALLOWED, DRINK LARGE AMOUNTS OF WATER OR MILK.
Page 232: Bilge Pump
CHAPTER 7 Bilge Pump A bilge pump is usually AUTOMATIC FLOAT SWITCH installed in the engine compartment just below CHECK the engine front. Check for FOR DEBRIS foreign materials stuck in the strainer area or discharge hose. BILGE Check all clamps and electrical PUMP connections for tightness.
Page 233 Cosmetic Care & Maintenance Blower Check the blower hoses to ensure they are fastened in the bilge properly and there are no holes BLOWER in them. The ventilation hose connected to the blower needs to be positioned about 3/4 of the way down in the bilge to evacuate fumes properly.
Page 234 CHAPTER 7 Fuel Tank & Fittings Periodically inspect the fuel tank components for loose clamps at the vent including charcoal canister, ﬁ ll and feed locations. Examine each hose for signs of deterioration and leakage. Check the fuel sender for loose bolts, nuts, and leaks at all areas of contact.
Page 235 Cosmetic Care & Maintenance Galvanic/Stray Current Corrosion CORROSION TABLE Gold Least Active Stainless Steel Bronze Copper Brass Steel Aluminum Zinc Most Active Magnesium Metal parts underwater can be subjected to two basic styles of electrolysis: galvanic corrosion and stray current corrosion. Both can damage the drive, propeller, underwater parts, boat and motor if not correctly monitored (testing at 2 week intervals) and avoided.
Page 236 CHAPTER 7 Typically electrons ﬂ ow from the anode (the aluminum drive unit),via the external conducting path to the cathode (stainless steel propel- ler). If there is a very large anode connected to a small cathode, the anode will corrode very slowly. If a very large cathode is connected to a small anode, the anode will corrode very quickly.
Page 237 1. Test the galvanic integrity of your vessel every 2 weeks. Raise the outdrive and inspect anodes/parts for signs of galvanic corrosion, stray cur- rent corrosion or loose fasteners. Contact your closest Regal dealer/marine professional where signs of galvanic corrosion exist.
Page 238 CHAPTER 7 7. If marina moored, contact appropriate personnel if signs of gal- vanic corrosion appear on your drive system. Ask them to check for stray electrical current which may be originating from a nearby vessel’s faulty DC wiring or from a marina pier, piling or dock carrying leaking marina ground wiring such as a dockside cord partially submerged.
Page 239 VOA meter. Refer to the engine manufacturer’s manual for exact anode location and detailed information. Stern drive or related parts damage due to galvanic or stray current corrosion is not covered under the Regal limited warranty. 7-21...
Page 240 CHAPTER 7 Propellers Out-of-balance or nicked props will effect performance or cause vibration. Damaged props should be replaced, but those that are chipped or bent can usually be reconditioned by a marine dealer or a propeller repair facility. When cruising, consider carrying a spare set of props on board because many marinas do not carry a full inventory of replacement propellers.
Page 241 Cosmetic Care & Maintenance TYPICAL VOLVO DUO PROP INSTALLATION Coat both shafts with marine grease. Place the remote control in forward position to lock shafts. Install the front propeller. Install propeller nut. Tighten to 45 ft. lbs. Make sure the chamfered edge of the prop nut is facing forward.
Page 242 CHAPTER 7 TYPICAL VOLVO DUO PROP INSTALLATION Shift remote control to reverse to lock the propeller shaft. Install the rear propeller. Install the rear propeller nut and tightenit to 50 foot pounds using a torque wrench. Shift the remote control to neutral. The propeller shoud turn freely.
Page 243 Cosmetic Care & Maintenance MERCRUISER BRAVO THREE Diagram above displays typical Bravo 3 propeller shaft parts. Refer to the MerCruiser operator’s manual for more speciﬁ c propeller system installation procedures. 7-25...
Page 244 Because of the advanced ignition and fuel injection systems used on marine engines it is best to contact your Regal dealer for more of the detailed service procedures. CAUTION...
Page 245 Refer to the Volvo engine operator’s manual for the correct oil requirements for catalyst type engines, or contact your nearest Regal or Volvo dealer for further information. For other engines not manufactured as catalyst engines refer to your engine operator’s manual for correct oil recommendations.
Page 246 Note: Refer to your Volvo engine owner’s manual for adding any oil during the break-in period since special blends are required. Note: All ﬂ uid recommendations are based on this manuals printing date. Regal is not responsible for the accuracy of the information since it can change at any time.
Page 247 Cosmetic Care & Maintenance NOTICE PREVENT ENGINE DAMAGE! DO NOT ALLOW THE CRANKCASE OIL LEVEL TO RECEDE BELOW THE ADD MARK, AND DO NOT FILL ABOVE THE FULL MARK. OVERFILLING RESULTS IN REDUCED ENGINE LIFE, HIGH OPERATING TEMPERATURES, FOAMING & LOSS OF POWER. Checking the Power Trim/Tilt Fluid Level 1.
Page 248 CHAPTER 7 Checking Typical Volvo Power Steering Fluid 1. Check the power steering ﬂ uid before each boating outing. Remove the steering reservoir and check the ﬂ uid level. If the engine has not been running use the “COLD” mark. Use the “HOT” mark for engines that have been running at normal operating temperature as indicated by the temperature gauge.
Page 249 Cosmetic Care & Maintenance Checking Typical Volvo Cooling System Your cooling system requires inspection and maintenance with each trip, with extended maintenance every 50 hours. In addition, the water pump impeller needs replacement every two years. To inspect your cooling system, all lines need to be visually inspected for cracks, melting, crimped spots, and leaks.
Page 250 For changing the engine oil & ﬁ lter see the MerCruiser maintenance schedule and operation manual or contact your Regal dealer. Note: Above are basic recommendations. Regal is not responsible for the accuracy of the information since it can change at any time. For more detailed information and procedures check your engine operators manual or call your closest Regal dealer.
Page 251 Refer to the MerCruiser engine operator’s manual for the correct oil requirements for catalyst type engines, or contact your nearest Regal or MerCruiser dealer for further information. For other engines not manufactured as catalyst engines refer to your engine operator’s manual for correct oil recommendations.
Page 252 3. Fill to line with Quicksilver Power Trim & Steering Fluid (Merc # 92-802880A1) or Dextron III automatic transmission ﬂ uid. If you can not see any ﬂ uid in the power steering reservoir contact your Regal dealer since a leak must of developed in the system.
Page 253 Use Power Trim & Steering Fluid (92- 802880A1). 3. Install the cap. Changing Power Trim Fluid 1. Power steering ﬂ uid does not require changing unless it becomes comtaminated with water or debris. Contact a Regal dealer to change the ﬂ uid. 7-35...
Page 254 2. The coolant level in the heat exchanger should be at the bottom of the ﬁ ller neck. A low coolant level means you should contact your Regal dealer. 3.Install the cap onto the heat exchanger. 4. When reinstalling the pressure cap, be sure to tighten it until it seats on the ﬁ...
Page 255 2. Fill to the “FULL” line with Extended Life Antifreeze/Coolant Mercury part # 92-877770K1. 3. Reinstall the cap onto the coolant recovery canister. Changing Engine Coolant Call your Regal dealer to change coolant in the entire system. 7-37...
Page 256 If water enters the stern drive here, have the drive inspected by a marine professional or your Regal dealer. On select outdrives the lower bellows is part of the exhaust system.
Page 257 If the oil color is milky in appearance there probably is water in the unit normally caused by a leaking seal. No metal ﬂ akes should be present in the oil. If the above conditions exist contact a Regal dealer. 7-39...
Page 258 If any water is visible at the bottom of the reservoir or there are any metal chips in the drive oil do not run the engine since component damage can result. Contact your Regal dealer for more information. Filling the Stern Drive 1.
Page 259 Cosmetic Care & Maintenance 3. Fill the reservoir so that drive oil level is in the operating range. Do not overﬁ ll reservoir. For changing the drive oil refer to the MerCruiser operation manual or contact a Regal dealer for more information. 7-41...
Page 260 CHAPTER 7 VOLVO MAINTENANCE GUIDE i l o , l i , l i t f i , d i e t t e t t o i t s t l 7-42...
Page 261 Cosmetic Care & Maintenance VOLVO MAINTENANCE GUIDE CONT. o l l & l f i t l i l l e Refer To , l i Volvo , l i Engine Operator’s e t l Manual l l e & e l t g i l &...
Page 262 CHAPTER 7 MERCRUISER MAINTENANCE GUIDE , l i , l i , l i , d i i r e t l a i l o r e t e t i e t t i t c r e l t f a t n i &...
Page 263 Cosmetic Care & Maintenance MERCRUISER MAINTENANCE GUIDE CONT. , s t n i l & o l l i r a & r e l , s t i t i , s t , r o s t l &...
Page 264: Remote Control
ﬁ ghts corrosion. At the helm end check to make sure the control box hardware is tightly secured. Contact a marine professional or Regal dealer for further assistance. Note: Volvo joystick type propulsion annd Merc DTS units do not use an actual control cable in the system.
Page 265 Cosmetic Care & Maintenance Seating Inspect all fasteners and metal for fatigue. Lubricate the slider track of the helm seat with a good quality silicone lube. Check all fasteners periodically for tightness and the effects of corrosion especially in moist environments. It is a good practice to use a small amount of silicone lube on all hinges to keep them freed up for proper operation.
Page 266 CHAPTER 7 Steering Your boat uses a rack or rotary style steering system featuring a cable that functions with assistance through the engine power steering pump. As you turn the wheel force is applied through the system to a hydraulic cylinder found at the aft end of the engine and attached through the engine power steering pump hoses.
Page 267 Cosmetic Care & Maintenance Stereo The Fusion® stereo head unit requires little maintenance. When washing the cockpit, do not discharge water directly at the stereo unit. Possible damage may result. As with any CD unit clean your CD’s to keep them from skipping. This process also aids in keeping dust out of the unit.
Page 268 CHAPTER 7 Trim Tabs Periodically check the trim tab anodes for galvanic c o r r o s i o n . T h e y a r e attached to the trim tabs located on the port and starboard transom. A good rule of thumb is to replace a sacriﬁ...
Page 269: Troubleshooting
Additional assistance is available in the engine manufacturer’s manual. Also, you can contact your closest Regal dealer or marine professional for more information. Most problems can be solved by following a logical sequence of elimination.
Page 270 CHAPTER 8 REMOTE CONTROL DIAGNOSTIC CHART PROBLEM POSSIBLE CAUSE POSSIBLE FIX Remote control Corroded cable Clean/lubricate cable stiff/inoperative Kinked cable Replace cable Broken cable Replace cable Remote control box Repair/Replace box jammed Throttle only control Worn throttle cable Replace cable inoperative (neutral) Binding Cable Follow cable routing;...
Page 271 PERFORMANCE DIAGNOSTIC CHART PROBLEM POSSIBLE CAUSE POSSIBLE FIX Material obstructing Remove material by propeller reversing engine Bent propeller shaft Call Regal dealer Excessive vibration Bent propeller blade Repair/replace propeller Propeller hub slipping Replace propeller Engine trim incorrect Adjust trim Uneven load...
Page 272 CHAPTER 8 DC ELECTRICAL DIAGNOSTIC CHART PROBLEM POSSIBLE CAUSE POSSIBLE FIX Turn selector switch to Battery switch in "off" "on" position position No 12 volt power Weak or dead battery Charge or replace battery Loose belt Tighten belt Battery not charging; Faulty alternator Repair/Replace (Engine running)
Page 273: Storage/Winterization
Use the enclosed checklists to help you identify areas of concern and maintenance. These lists cover land stored boats either inside or outside. Call a Regal dealer or marine professional for further information.
Page 274: Decomissioning Checklist
Allow time for it to circulate through the fuel system. Change all engine ﬂ uids as referenced in the engine manufacturer’s owners manual. Contact your Regal dealer. Drain cooling and exhaust system or have a marine professional “pickle” the engine. Contact your Regal dealer.
Page 275 Storage & Winterization Remove batteries. Use a trickle charger as needed. Remove all loose gear and electronics from boat. Inspect all equipment for wear and damage. Store in a clean, dry environment. Remove drain plug. Clean drain plug hole of debris as needed. Enclose drain plug in plastic bag and tie to steering wheel.
Page 276 2. With vacuum type head, pump out holding tank. Add nontoxic antifreeze to toilet and holding tank. Pump from toilet to holding tank to eliminate any water remaining in supply lines. NOTICE AVOID VESSEL AND ENGINE DAMAGE! CONTACT MARINE PROFESSIONAL FOR WINTERIZATION INSTRUCTIONS. DAMAGE IS NOT COVERED BY REGAL WARRANTY.
Page 277: Recomissioning Checklist
Storage & Winterization RECOMISSIONING CHECKLIST ENGINE/STERN DRIVE Check all components per engine manufacturer’s owners manual especially ﬂ uid levels. Run engine on “ear muffs” (ﬂ ushette) before launching. Check for fuel, exhaust, oil, and water leaks. BOAT Install hull drain plug. Install batteries and tighten all terminals.
Page 278 CHAPTER 9 Notes...
Page 279 Glossary & Index Below is a brief list of nautical terminology. For more detailed glossaries we recommend you check your local library, book retailer, marine store or internet. GLOSSARY Abeam: at right angles to the fore and aft line and off the boat Aboard: on or in the boat Above: the part of the boat on a vessel which is above the interior of the boat...
Page 280 CHAPTER 10 Cast off: to let go or release Chine: the line fore and aft formed by the intersection of the side and bottom of the boat Chock: deck ﬁ tting used to secure or guide anchor or tie lines Cleat: deck ﬁ...
Page 281 Glossary & Index Head: toilet Hull: the part of the hull from the deck down Keel: the lowest point of a boat; the backbone of the vessel Knots: a measurement of speed indicating nautical miles per hour Lee: the side opposite that from which the wind is blowing: the side sheltered from the wind Leeward: the direction toward which the wind is blowing PFD: personal ﬂ...
Page 282 CHAPTER 10 Trim: the boat’s balance when properly loaded Wake: the path of a boat left astern in the water Windward: the direction from which the wind blows; opposite of leeward 10-4...
Page 283: Glossary & Index
Glossary & Index INDEX Accidents 1-27 Canvas 6-18 Accident Reporting 1-28 Anchor Light 1-16 Carbon Monoxide 1-21 Anchoring 5-25 Yacht Certiﬁ cation Plate Int-14 Anchor Windlass Cardiopulmonary Resuscitation 5-29 Audible Alarms 3-13 Cockpit Carpet 6-25 Automatic Fire Extinguisher 3-11 Cockpit Table 6-26 Cockpit Refreshment Center 6-27...
Page 284: Index
CHAPTER 10 Fenders 5-10 Ignition Switch 3-14 Fiberglass Maintenance Index 11-5 Fire Extinguishers 1-10 Interior Fabrics International Distress Signals 1-14 7-11 First Aid 5-30 Float Plan Int-9 Knots 5-28 Fresh Water System 4-14 6-25 Fuel 4-10 Labels 7-16 Ladder 6-46 Law of Salvage 5-27 Lighting-All Around/Stern...
Page 285 Glossary & Index Navigation Aids Recommissioning Navigation Lights 1-15 Registration Information Int-19 1-19 Remote Control 3-15 Navigation Rules Neutral Safety Switch 3-15 7-46 New Boat Delivery Checklist Int-17 Night Running Right-Of-Way Rules Of The Road Oil Pressure Gauge Oil Spills 1-17 Safety Overloading...
Page 286 CHAPTER 10 Stern Drive 5-14 Ventilation 7-38 Visibility Int-14 5-23 Sunbrella Cleaning Visual Distress Signals 1-12 Swim Platform 6-71 Volt Meter Switches (DC) Volvo 7-27 Tachometer Wake 1-33 Table/Cockpit 6-21 Warning Labels Technical 12-1 Washdowns 6-108 Temperature Gauge Warranty Int-18 Toilet 4-15 Water Skiing...
Page 287: Technical Information
For more information contact your nearest authorized Regal dealer. For the location of your nearest authorized dealer call 407-851-4360. or visit the web-site at www.RegalBoats.com. Your Regal dealer has received special factory training on the entire product line and his services should be employed to solve technical problems.
Page 288 3200 TYPICAL DOMESTIC FUEL SYSTEM EPA COMPLIANT FUEL TANK SHOWN BELOW FUEL TANK CARBON FUEL FILL CANISTER HOSE FUEL SENDER FUEL FEED FUEL/ VENT HOSE DECK FILL ANTI-SIPHON VALVE BLOWERS ENGINE 11-2...
Page 289: Specifications
Technical Information 3200 SPECIFICATIONS LENGTH OVERALL W/ PLATFORM 32’ 9.75 M BEAM 10’ 4 1/2” 3.16 M DEADRISE 21 DEGREES APPROXIMATE DRY WEIGHT W/ TWVOLVO 350 CATALYST 9300 LBS. 4218.4 KG W/DP STERN DRIVE APPROXIMATE BRIDGE CLEARANCE TO TOP OF POWER 9’...
Page 290 TYPICAL LABEL & PLACARD LOCATION PowerTower 11-4...
Page 291 SCALE: SHEET: PROPRIETARY AND CONFIDENTIAL 9-5-12 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE DWG. NO.: PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF C.W. MNC24C...
Page 292 3200 BOW RIDER DECK HARDWARE 1 0F 2...
Page 293 SCALE: SHEET: DATE: PROPRIETARY AND CONFIDENTIAL 9-24-12 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: DWG. NO.: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF C.W.
Page 294 DATE: SCALE: SHEET: PROPRIETARY AND CONFIDENTIAL 9-13-12 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: DWG. NO.: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF C.W.
Page 295 SCALE: SHEET: PROPRIETARY AND CONFIDENTIAL 9-14-12 Half THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: DWG. NO.: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF MNC24A C.W.
Page 296 SCALE: SHEET: PROPRIETARY AND CONFIDENTIAL 9-25-12 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE DWG. NO.: PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF C.W. MNC23A...
Page 297 3200 BOW RIDER TYPICAL EPA COMPLIANT FUEL TANK INSTALLATION...
Page 298 SCALE: SHEET: DATE: PROPRIETARY AND CONFIDENTIAL 9-17-12 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: DWG. NO.: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF C.W.
Page 299 3200 BOW RIDER COLD WATER SYSTEM RUNS...
Page 300 3200 BOW RIDER ELECTRIC TOILET W/ OVERBOARD DISCHARGE...
Page 301 3200 BOW RIDER ELECTRIC TOILET W/ DECK PUMP OUT...
Page 302 SCALE: SHEET: PROPRIETARY AND CONFIDENTIAL 9-19-12 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE DWG. NO.: PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF C.W. MNC22A...
Page 303 PROPRIETARY AND CONFIDENTIAL Main Ground Bus THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF REGAL MARINE INDUSTRIES IS PROHIBITED From Battery Management...
Page 304 SCALE: SHEET: PROPRIETARY AND CONFIDENTIAL 9-19-12 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE DWG. NO.: PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF C.W. MNC22B...
Page 305 SCALE: SHEET: PROPRIETARY AND CONFIDENTIAL 9-24-12 None THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION DRAWN BY: APPROVED BY: DWG. NO.: IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF MNC22C C.W.
Page 306 3200 BOW RIDER DC HEAD PANEL...
Page 307 3200 BOW RIDER HELM SWITCH PANEL...
Page 308 3200 BOW RIDER HELM BREAKER PANEL...
Page 309 3200 BOW RIDER VOLVO IGN/MERC ANALOG & EVC...
Page 310 3200 BOW RIDER IPA VOLVO & MERC ANALOG...
Page 311 3200 BOW RIDER IPA VOLVO & MERC ANALOG W/ GARMIN...
Page 312 3200 BOW RIDER BATTERY MANAGEMENT PANEL...
Page 313 3200 BOW RIDER AFT SWITCH PANEL...
Page 314 3200 BOW RIDER WINDLASS PANEL...
Page 315 3.15.12) 3200 BOW RIDER HEIGHT DIMENSIONS...
Page 316 3200 BOW RIDER STANDARD SEATING POSITIONS...

Regal 3200 Bowrider Owner's Manual

Introduction

Engines

Equipment Operation

Cosmetic Care & Maintenance

Troubleshooting

Storage/Winterization

Glossary & Index Index

Glossary & Index

Technical Information

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Regal 3200 Bowrider

Summary of Contents for Regal 3200 Bowrider

Table of Contents
