HDDVR302 Instruction Manual
Thank you for purchasing our Gator DVR. In order to help you
operate it correctly, please read this instruction carefully before using.

Product picture and function

1 2.0 inch LCD display
2 Lens
3 LED light
4 Speaker
5 Bracket hole
6 Photo resistance (infrared auto-detection)
7 USB Slot
8 AV output interface
9 Working indicator (Blue)/ Charging indicator (Red)
10.11 Up/ Down button
12 MENU button
13 Battery cover
14 Microphone
15 MicroSD card Slot
16 RESET button
17 OK button(record / camera)
18 Power/Mode switching button

OPERATION

A Built-in battery
Connect car charger: Whilst charging the red indicator lamp is bright.
When charge is complete, the display window will show the battery
icon as full.
B. Connected with Car Charger
After the car starts, the DVR will automatically enter video recording
mode, charging at the same time. When the car has been shut down, the
product will continue working for 15 seconds before automatically
shutting down and saving the previous recorded files.
Note: This machine can be used only with the car charger with output
5V!
Features
DVR with record / camera / playback functions

A) Recording mode

Press the power button 18 , then press the OK button 17 to open or
connect car charger into the video mode and start recording (note:
please insert MicroSD card before use), then the time at the bottom
right will turn red from white, recorded files are stored into the card,
press the OK button
17
to stop recording, then red digital time
becomes white.

B) Camera mode

Power on and press MODE button 18 to enter the camera mode, press
OK button to take pictures.

C) Preview mode

Power on and press MODE button
18
mode
Press Up/Down button
10.11
to select the folder preview, press the
OK button into menu, and then press OK button to play/pause.

Delete function

Under the preview mode, press the MENU button
interface, and then press OK button
17
"interface (use up / down buttons to select the listed settings), finally
press OK button to confirm, you can also choose "Thumbnail Display"
and "preview playback volume" feature, and finally press OK button to
confirm.
twice to enter the preview
12
to enter delete
into "single/ all / selection
