Summary of Contents for Gator HDDVR202
- Page 2 Product Description This product is developed with the latest technology to design a professional HD Car DVR. It can both record 1280*720P high- definition video and take 1.3 mega pixels pictures. Micro SD card is used for storage. This DVR is compact, power-saving and portable. Video files can be transferred by HDMI to a high definition LCD TV and realize picture perfect playback.
- Page 3 1 、 Power key 2 、 Card slot 3 、 OK key 4 、 AV OUT interface 5 、 Reset 6 、 HDMI 7 、 USB interface 8 、 Screen 9 、 Horn 10 、 Menu Key 11 、 Up key 12 、...
- Page 4 Battery Power Full Slightly less power Low power Battery Charging 1. Connect the DVR using the USB interface via the car charger, the DVR starts up automatically and charges. When it is shut down, it can also be charged. When charging, the indicator light is red. Once battery is full, the red light turns off.
- Page 5 Please pay attention to the insert direction of the card. If it is in the wrong side, it may damage the device and Micro SD. When you have inserted the Micro SD into the device, the device will be set as default storage equipment, the original documents inside can not be read.
- Page 6 picture/Playback, is video shooting, is taking picture, the icon will show on the upper left of the screen. How to enter the photography system set up option In the video or photographic mode, press menu button once, then press the up/down key, enter the system set up option *Resolution: 720P 1280*720/ WVGA 848*480/ VGA640*480 * Motion Detection: off/on * Audio: off/on...
- Page 7 * IR Light: off/on/auto * Format: Internal storage/SD Card Recording Video When in video recording mode, the upper left of the screen show mark , press ok key to start recording, icon flash at the upper left screen. Press the ok key again to stop recording and at the same time disappear.
- Page 8 ISO: Auto/100/200/400 EV -1/3 -2/3 -1.0 -4/3 - 5/3+0.0 +1/3 +2/3 +1.0 +4/3 +5/3 +2.0 -2.0 Anti-shake: off/on Fast reading Date stamp: off/on 1. Press Mode key to be in picture taking mode ， the upper left will show icon 2.
- Page 9 In any mode of photographing, you can press the mode button to cycle through video shooting mode, photo taking mode and playback mode. Playback mode 1. Browse file: When the device starts up completely and enters the recording mode, press the mode button to switch to playback mode, press the up or down key where you can browse pictures and video data.
- Page 10 camcorder automatically boot and enter the MTFC mode. In "My Computer", you will see a removable disk. You place the appropriate files by file type in removable disk. Remarks: 1,Operating systems: Windows 2000/XP/Vista/Windows 7, MAC OSX 10.3.6 or higher. 2, Plug out the USB cable to turn off the camera Connecting the TV playback 1.
- Page 11 language Chinese, Simplified Chinese, French, Spanish, German, Italian Video 720P （ 1280X720 ） WVGA （ 848*480 ） VGA Resolution (640*480) Video format MJPEG Photo 12M/10M/8M/5M/2M Resolution Photo Format Memory Micro SD Speaker Built-in Light 50Hz/60Hz Frequency TV out NTSC/PAL USB interface USB2.0 Power 5V 1A...
