AXM MultiPath
AXT Trunking VoIP Gateways
AXG Series Gateway
AXE Enterprise VoIP Gateway
The MultiPath version's architecture enables the Tenor AX to intelligently route calls between the
FXS, FXO, and the VoIP network to achieve the best combination of cost and quality. The Tenor AX
also routes calls over IP to reduce costs, and then transparently "hop off" to the PSTN, to reach off-
net locations. Calls can be routed in any direction between any of the ports.
Whichever configuration you choose, the high performance unit provides one 10/100 BaseT con-
nection, along with one RS-232 serial console port connection. The unit also incorporates an intelli-
gent call routing engine which regulates system resources and configuration while coordinating all
voice traffic activity in the unit.
The unit's simple plug and play embedded system architecture brings VoIP technology to your net-
work without changing your existing telephony infrastructure. Your network stays as is, and the call
type is transparent to the user. This technology boasts superior voice quality without compromising
reliability.
P/N 480-0062-00-10
Table 2-1 Tenor AX Configuration Types
Configuration
AXM0800
AXM1600
AXM2400
AXT0800
AXT1600
AXT2400
AXG0800
AXG1600
AXG2400
AXE0800
AXE1600
AXE2400
FXS Ports FXOPorts
8 8
16 16
24 24
0 8
0 16
0 24
8 0
16 0
24 0
8 2
16 2
24 2
