Chapter 6: Advanced Topic: SNMP/IVR
Figure 6-4 Post-paid Account - Call Flow (default language)
POSTPAID
ENABLED
CALLING
CALLED
RADIUS
TENOR
PARTY
PARTY
SERVER
VPH
SETUP
START ACCOUNTING
START ACCOUNTING ACK
"Welcome"
"Please Enter Your Account Number"
GET ACCOUNT NUMBER
"Please Enter Your Pin Number"
GET PIN NUMBER
AUTHENTICATE (ACCT, PIN)
AUTHENTICATION RESPONSE
"Please Enter The Phone Number to call"
GET DNIS
AUTHORIZATION ( DNIS )
AUTHORIZATION RESPONSE
SETUP
CONNECT
DISCONNECT
STOP ACCOUNTING
STOP ACCOUNTING ACK
P/N 480-0062-00-10
6-25
