AxD PUMP ExPLODED vIEW PARTS LIST
ITEM PART NO.
DESCRIPTION
56
89-3410.030.00 Injector Body Kit Mx 1.5
89-3410.0303.00 Injector Body Kit 3/8 NPT
57
89-180.0197.00 Spring
58
89-409.0086.00 Check Valve
59
89-110.0397.00 O-Ring
60
89-409.0091.00 Check Valve Kit
61
89-0009.019.00 Ring
6
89-0009.030.00 Ring
63
89-141.0055.00 Piston Seal 150 Bar (50G,
300G, 35G)
89-141.0056.00 Piston Seal 180 Bar
(305G)
64
89-300.0017.00 Plug 1/8 x 8
65
89-300.0007.00 Plug 3/8 Gas OT58
66
89-803.0435.00 Injector Kit
67
89-003.045.00 Hose Barb Fitting
68
89-81.0067.00 O-Ring
69
89-3003.006.00 Ball
70
89-180.0180.00 Spring
71
89-318.099.00 Pump Valve Chamber
7
89-300.0017.00 Plug 1/8 x 8
77
89-800.0081.00 Garden Hose Tail
kit A 89-505.0014.00
kit b 89-5019.0077.00
89-5019.0078.00
kit C 89-409.009.00
kit D 89-5019.0079.00
kit E 89-506.014.00
89-506.0143.00
kit f 89-506.0144.00
kIT qTy
E
E
E-F
B
B
B
Complete Valve Kit
Piston Seal Kit, 150 Bar
Piston Seal Kit, 180 Bar
Piston Kit
Seal Kit
Overhaul Kit, M x 1.5
Overhaul Kit, 3/8" NPT
Maintenance Kit
9.800-088.0 • REV. 0/08
