Kärcher Shark ZE2-11026D Service Manual

Hide thumbs

Table Of Contents

Quick Links

SERVICE MANUAL

ZE2-11026D

ZE2-14024D (

HOME DEPOT

ZEF2-14024D

ET-201409Dx2

HE-201406D

HE-201006D

HE-201407D+

HD 1.8/14Ed

HD 2.0/10Ed

HD 2.0/14Ed +

ET-301109D

)

1.106-023.0

1.106-024.0

1.107-090.0

1.107-089.0

1.106-066.0

1.106-065.0

1.106-067.0

1.575-401.0

1.575-400.0

1.107-088.0

1.106-107.0

9.800-417.0

Table of Contents

Need help?

Do you have a question about the Shark ZE2-11026D and is the answer not in the manual?

Questions and answers

Summary of Contents for Kärcher Shark ZE2-11026D

Page 1 SERVICE MANUAL ® ZE2-11026D 1.106-023.0 ZE2-14024D ( 1.106-024.0 HOME DEPOT ZEF2-14024D 1.107-090.0 ET-201409Dx2 1.107-089.0 HE-201406D 1.106-066.0 HE-201006D 1.106-065.0 HE-201407D+ 1.106-067.0 HD 1.8/14Ed 1.575-401.0 HD 2.0/10Ed 1.575-400.0 HD 2.0/14Ed + 1.107-088.0 ET-301109D 1.106-107.0 9.800-417.0...
Page 3: Table Of Contents
CONTENTS Exploded View and Parts List, Standard Models ........4-5 Exploded View and Parts List, ZEF, X2, Plus, and Home Depot ..6-7 Control Panel, ZEF, X2, Plus, and Home Depot ........8 Exploded View and Parts List, ET-301109D ........9-10 Control Panel, ET-301109D ..............11 Hose &...
Page 4 EXPLODED VIEW — STANDARD MODELS Models 401.0 & 066.0 120V 15 Amp Model 9.800-417.0 • Rev. 12/17A...
Page 5: Exploded View And Parts List, Standard Models
EXPLODED VIEW PARTS LIST — STANDARD MODELS ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 9.802-432.0 GFCI, 120V 15 Amp w/36' 8.930-123.0 Label, For Indoor Use 12-3 Cord (023.0, 400.0, 065.0) 9.800-034.0 Label, Clear Lexan, 9.802-431.0 GFCI, 120V 20 Amp w/36' 2-1/4"...
Page 6 EXPLODED VIEW — ZEF, x2, +, MODELS & HOME DEPOT 22, 35 Detail See Control Panel Illus. 9.800-417.0 • Rev. 12/17A...
Page 7 PARTS LIST — ZEF, X2, PLUS MODELS & HOME DEPOT ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION 9.802-431.0 GFCI, 120V 20 Amp 8.754-784.0 Apron Sticker Landa 9.802-259.0 Hose, 1/2" Push-On 15" 8.706-984.0 Adapter, 1/2" FPT x 1/2" MPT, Brass 8.754-709.0 Motor, 2 HP 1Ph, 115V, 1750 Rpm, 56C ODP...
Page 8 CONTROL PANEL — ZEF, x2, +, MODELS & HOME DEPOT 18,19 Unloader Switch GFCI Motor Conduit PARTS LIST — ZEF, X2, PLUS MODELS & HOME DEPOT ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 9.802-481.0 Box Front, Plastic, No Holes 9.800-040.0 Label, Ground 8.900-304.0...
Page 9 EXPLODED VIEW —ET-301109D Detail See Control Panel Illus. 9.800-417.0 • Rev. 12/17A...
Page 10 PARTS LIST — ET-301109D ITEM PART # DESCRIPTION 9.802-431.0 GFCI, 120V 20 Amp 8.754-709.0 Motor, 2 HP 1Ph, 115V, 1750 Rpm, 56C ODP 8.900-305.0 Label, Warning 9.802-170.0 Coupler, 3/8"Plug, Female, Steel/Zinc 9.802-873.0 Handle Assy, Black 9.802-064.0 Grommet, Rubber, Nozzle Holder 8.754-696.0 Unloader, VBT Banjo 1/2M 3/8M, 3000PSI (Spare)
Page 11: Control Panel, Et-301109D
CONTROL PANEL — ET-301109D PARTS LIST — ZEF, X2, PLUS MODELS & HOME DEPOT ITEM PART NO. DESCRIPTION 9.802-477.0 P. Box, Plastic, Carlon E9801 w/o Lid 8.912-227.0 Plate, Switch Remote 8.716-547.0 Connector,1/2 L/T Black 9.802-518.0 Strain Relief, Lt, Str, 3/4 Npt .49-.71D 8.716-053.0 Swicht, Toggle, 40A/230V...
Page 12: Hose & Spray Gun
HOSE & SPRAY GUN ASSEMBLY 9.800-417.0 • Rev. 12/17A...
Page 13 HOSE & SPRAY GUN ASSEMBLY PARTS LIST ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 9.802-166.0 Coupler, 3/8" Female 8.712-346.0 Nozzle, SAQCMEG 1504, 9.802-100.0 ▲ Quick Coupler O-Ring Yellow (024.0) 8.712-333.0 Nozzle, SAQCMEG 1503, 8.925-137.0 Hose, 3/8" X 25' 1W Yellow (401.0, 066.0, 090.0, 4000PSI SW/SO/CPL 088.0, 067.0, 089.0)
Page 14: Axd Pump Exploded View And Parts List
AXD PUMP EXPLODED VIEW AXD PUMP EXPLODED VIEW PARTS LIST ITEM PART # DESCRIPTION KIT QTY ITEM PART # DESCRIPTION KIT QTY Cap, 1/8” O-Ring Screw M8x55 O-Ring 8.721-936.0 Valve Kit Ring 8.721-920.0 O-Ring, 1.78 x 12.42 A-D O-Ring Valve Seat Ring SUC/DEL Valve 8.721-956.0...
Page 15 AXD PUMP EXPLODED VIEW PARTS LIST ITEM PART NO. DESCRIPTION KIT QTY Injector Body Kit M22x 1.5 8.721-974.0 Injector Body Kit 3/8 NPT Spring Check Valve O-Ring 8.721-948.0 Check Valve Kit 8.739-570.0 Ring 8.739-571.0 Ring 8.739-574.0 Piston Seal 150 Bar (2520G, 3020G, 3522G) Piston Seal 180 Bar (3025G)
Page 16 LF SERIES PUMP EXPLODED VIEW TORQUE SPECS Item # Ft.-lbs LF SERIES PUMP PARTS LIST ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 8.754-841.0 Crankcase 8.754-850.0 Washer, Lock 8.754-846.0 O-ring Ø1.78 X 72.75 9.803-198.0 Washer, Copper G3/8 See Kits Below Plunger Oil Seal 8.707-262.0 Plug, Brass G3/8 See Kits Below O-ring Ø1.78 X 26.7...
Page 17 LF SERIES PUMP PARTS LIST ITEM PART NO. DESCRIPTION 8.754-855.0 Bolt, Plunger 8.754-092.0 Spacer, Copper 8.754-848.0 Plunger, 16mm 9.803-962.0 Spacer, Copper 8.754-827.0 Plunger Rod 9.803-965.0 Connecting Rod Pin 9.803-966.0 Connecting Rod 8.933-020.0 Screw, Connecting Rod 8.754-847.0 O-ring Ø2.62 X 111.62 8.754-842.0 Cover, Crankcase 9.803-906.0...
Page 18 HF SERIES PUMP EXPLODED VIEW 8.923-779.0 HF2830S.1 TORQUE SPECS Item # Ft.-lbs HF SERIES PUMP EXPLODED VIEW PARTS LIST ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 23* See Kits Below Valve Plate 8.754-841.0 Crankcase 24* See Kits Below Valve Spring 8.754-846.0 O-ring Ø1.78 X 72.75 25* See Kits Below Valve Cage...
Page 19 HF SERIES PUMP EXPLODED VIEW PARTS LIST ITEM PART NO. DESCRIPTION 8.754-848.0 Plunger, 16mm (2030S, 2830S) 8.754-849.0 Plunger, 14mm (2030F, 2830F, 3530F) 9.803-962.0 Spacer, Copper 8.754-827.0 Plunger Rod 9.803-965.0 Connecting Rod Pin 9.803-966.0 Connecting Rod 8.933-020.0 Screw, Connecting Rod 8.754-847.0 O-ring Ø2.62 X 111.62 8.754-842.0 Cover, Crankcase...
Page 20: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION PUMP RUNNING Check water supply and possibility of air seep- Pump sucking air NORMALLY BUT age. PRESSURE LOW ON Check valves sticking Check and clean or replace if necessary. INSTALLATION Unloader valve seat faulty Check and replace if necessary. Nozzle incorrectly sized Check and replace if necessary.
Page 21: Electric Diagram
ELECTRIC DIAGRAM 9.800-417.0 • Rev. 12/17A...
Page 22: Et-301109D Electric Diagram
ET-301109D ELECTRIC DIAGRAM 9.800-417.0 • Rev. 12/17A...
Page 23 Form #9.800-417.0 • Revised 12/17A • Printed in U.S.A. or México...

This manual is also suitable for:

Shark et-201409dx2 Shark ze2-14024d Shark zef2-14024d Shark he-201406d Shark he-201006d Shark hd 1.8/14ed ... Show all
