- Page 1 GiGabit EthErnEt DEsktop switch usEr manual Models 524117 & 524124 Model shown: 524124 INT-524117/524124-UM-0408-01...
- Page 2 Thank you for purchasing the INTELLINET NETWORK SOLUTIONS ™ Gigabit Ethernet Desktop Switch, Model 524117 (5-port) or Model 524124 (8-port). Providing your network with the high level of performance it needs to handle quick transfer speeds to support disk mirroring, data backup,...
-
Page 3: Front Panel
front panEl The top-panel LED indicators — POWER, Link/Act — allow for more convenient monitoring and troubleshooting of the switch. The table below shows each LED function. Status Operation POWER Steady green Power on Check AC connection; turn the power on LINK/ACT Steady green Valid port connection... -
Page 4: Side Panel
siDE panEl Model 524124 Plug the female end of the power adapter firmly into the receptacle on the side panel and the other end into an electrical outlet. Confirm that the power LED is lit for a normal power status. NOTE: To ensure proper operation, use only the power adapter included with the switch. -
Page 5: Specifications
LEDs • Power • LINK/ACT for each 10/100/1000 Mbps port Power • DC input: 5 V, 2 A (Model 524117); 5 V, 2.5 A (Model 524124) • Power consumption: 10 Watts (maximum) Environmental • Plastic housing (ABS), desktop size • Dimensions: 140 (W) x 105 (L) x 25 (H) mm (5.5 x 4.1 x 1.0 in.) •...
