This user guide provides detailed information for using the BrightEye™2
Analog to Digital Converter.
The information in this user guide is organized into the following sections:
• Product Overview
• Functional Description
• Applications
• Rear Connections
• Operation
• Front Panel Controls and Indicators
• Using The BrightEye Control Application
• Warranty and Factory Service
• Specifications
• Glossary
Converter

User Guide

S
BrightEye-1
Revision 5 SW v1.0.7
