F-5100 Inline
Thermal Mass Flow Meter
Installation and Operation Guide
1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699
www.onicon.com • sales@onicon.com
05-13
0686-7 / 18332

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-5100 Inline and is the answer not in the manual?

Questions and answers

Related Manuals for Onicon F-5100 Inline

Summary of Contents for Onicon F-5100 Inline

  • Page 1 F-5100 Inline Thermal Mass Flow Meter Installation and Operation Guide 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 www.onicon.com • sales@onicon.com 05-13 0686-7 / 18332...

  • Page 2: Safety Information

    ONICON assumes no responsibilities for this product except as stated in the warranty. • If the customer or any third party is harmed by the use of this product, ONICON assumes no responsibility for any such harm owing to any defects in the product which were not predictable, or for any indirect damages.

  • Page 3: Table Of Contents

    CONDITIONS OF SALE ..................24 USE OF THE INSERTION DEPTH GAGE 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 3...
  • Page 4 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 4...

  • Page 5: Introduction

    This guide is the basic reference tool for all ONICON F-5100 Inline Thermal Mass Flow Meters. If you have not purchased all of the options, there will be references in this manual which are not applicable to your meter(s).

  • Page 6: Standard Features And Specifications

    STANDARD FEATURES AND SPECIFICATIONS CALIBRATION Every ONICON thermal mass flow meter is wet calibrated in a flow laboratory against standards that are directly traceable to N.I.S.T. A certificate of calibration accompanies every meter. Each meter is calibrated for use with a specific gas.

  • Page 7: Additional Hardware That May Be Required

    This serial number will also be located on the remote sensor for remote mount meters. 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332...

  • Page 8: Unpacking

    Please notify the ONICON customer service department if any of these documents are missing. Product • F-5100 Inline Thermal Mass Flow Meter 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 8...

  • Page 9: Installation

    DO NOT LOOSEN THESE FITTINGS WARRANTY VOID IF REMOVED 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 9...
  • Page 10 Available Straight Run 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 10...
  • Page 11 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332...

  • Page 12: Mechanical Installation

    9.72 9.93 10.195 10.54 10.78 11.255 11.755 12.38 13.38 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 12...

  • Page 13: Flanged Meter

    Bolt pattern for flanged meter ½” - 3” flanged meter 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 13...
  • Page 14 9 o’clock around the flange as shown in the diagrams below. Leak test all connections. Bolt Tightening Sequence 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 14...

  • Page 15: Electrical Installation

    Contact ONICON for assistance if the scaled pulse output requires reprogramming. IMPORTANT NOTICE The nominal pulse output voltage from this meter is 24 VDC. Contact ONICON if you require a pulse output with a different voltage than the supply voltage.

  • Page 16: Integral Mount Wiring

    DC Pulse + 4-20mA + +24 VDC VDC Common 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 16...

  • Page 17: Remote Mount Wiring

    To Terminal A1 to A6 shown above 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 17...

  • Page 18: Mass Flow Meters

    Flow Meters are not configured from the factory as “loop powered” devices. 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332...

  • Page 19: Start-Up & Commissioning

    Refer to troubleshooting guide when readings are inconsistent. 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332...

  • Page 20: Start-Up & Commissioning Worksheet

    Flow rate displayed by control system: _______SCFM _______SCFM _______SCFM _______SCFM 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 20...

  • Page 21: Troubleshooting Guide

    • Please contact ONICON for further assistance. 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 21...
  • Page 22 (See section 1.5.2 of this manual for details.) 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 22...
  • Page 23 RS485 connector on the F-5100. 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 23...

  • Page 24: Appendix

    CONDITIONS OF SALE USE OF THE INSERTION DEPTH GAGE 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 24...
  • Page 25 REMOTE MOUNT MECHANICAL HARDWARE 1500 North Belcher Road, Clearwater, FL 33765 • Tel (727) 447-6140 • Fax (727) 442-5699 • sales@onicon.com F-5100 Inline Thermal Mass Flow Meter Manual 05/13 - 0686-7 / 18332 Page 25...
  • Page 26 DELIVERY AND TITLE: All product shipments are F.O.B. shipping point and title passes to the Buyer at the time ONICON delivers the merchandise to the carrier. Risk of loss or damage to the product passes to the Buyer at the time ONICON delivers the product to the carrier.
