UCR401

Specifications and Features

Operating Frequencies (MHz):
Block 21:
Block 22:
Block 23:
Block 24:
Block 25:
Block 26:
Block 27:
Block 28:
Block 29:
Block 944:
Frequency Adjustment Range:
Channel Seperation:
Receiver Type:
Frequency Stability:
Front end bandwidth:
Sensitivity
20 dB Sinad:
60 dB Quieting:
Squelch quieting:
AM rejection:
Modulation acceptance:
Image and spurious rejection:
Third order intercept:
Diversity method:
FM Detector:
Antenna inputs:
Audio outputs
Rear Panel XLR:
Front Panel Controls and Indicators:
LCD control panel Main window:
Frequency window:
Transmitter switch setting
Audio output level adjustment:
Battery level tracking:
Scanning mode:
Audio test tone:
Transmitter battery type selection:
Phase invert:
SmartNR (noise reduction):
Audio Performance (overall system):
Frequency Response:
THD:
26
537.600 - 563.100
563.200 - 588.700
588.800 - 607.900 and
614.100 - 614.300
614.400 - 639.900
640.000 - 665.500
665.600 - 691.100
691.200 - 716.700
716.800 - 742.300
742.400 - 767.900
944.100 - 951.900
25.5 MHz in 100kHz steps
100 kHz
Triple conversion,
superheterodyne, 244 MHz,
10.7 MHz and 300 kHz
±0.001 %
30 MHz @ -3 dB
1 uV (-107 dBm), A weighted
1.5 uV (-104 dBm), A weighted
Greater than 100 dB
Greater than 60 dB, 2 uV to 1 Volt
(Undetectable after processing)
85 kHz
85 dB
+0 dBm
SmartDiversity TM phased antenna combining
Digital Pulse Counting Detector operating
at 300 kHz
Two, fixed whip
Adjustable from -50dBu to +5dBu
in 1 dB steps. Calibrated into a
typical 10 k Ohm balanced load.
Can drive 600 Ohm load.
Pilot tone; antenna phase, receiver battery
level; transmitter battery status; audio level,
RF level
Frequency, TV channel;
-50 dBu to +5 dBu
Receiver (AA battery) in 1/10th volt
steps, accuracy +/- 0.2V.
Transmitter (AA battery) x.xxV
format, accuracy +/- 0.1V.
Timer option available when NiMH used.
Coarse and fine modes for RF spectrum
site scanning
1 kHz, -50 dBu to +5 dBu output, 1% THD
9V alkaline, 9V lithium, AA alkaline,
AA lithium, NiMH
Audio output phase normal or inverted
OFF, NORMAL, FULL modes
(available in 400 Series mode only)
(These specs apply to 400 Series mode only.)
32 Hz to 20 kHz (+/- 1dB)
0.2% (typical)
Signal to Noise Ratio (dB):
(overall system, 400 Series mode)
Note: The dual envelope "soft"
limiter provides exceptionally good
handling of transients using variable
attack and release time constants. Once activated, the limiter compresses 30+ dB of transmitter
input range into 4.5 dB of receiver output range, thus reducing the measured figure for SNR
without limiting by 4.5 dB
Total Harmonic Distortion:
Input Dynamic Range:
Rear Panel Controls and features:
Power Options:
Ext DC:
Int Batt:
Battery Life:
AA alkaline
AA NiMH 8 hours (2500 mAH)
AA lithium
Weight:
Dimensions: 2.83" wide x 1.25" high x 4.64" deep
Specifications subject to change without notice
SmartNR No Limiting w/Limiting
OFF 103.5 108.0
NORMAL 107.0 111.5
FULL 108.5 113.0
0.2% typical (400 Series mode)
125 dB (with full Tx limiting)
XLR audio output jack;
External DC input;
Battery compartment access
Minimum 6 Volts to maximum 18 Volts DC;
1.6 W, 180 mA at 12 VDC
Two AA 1.5 Volt alkaline, lithium or
NiMH (270 mA @ 3V)
4 hours continuous
Up to 21 hours (continuous and
intermittent usage are the same)
13 oz. with batteries
(2.83 mm x 32 mm x 118 mm)
