Introduction Congratulations on the purchase of your GE USB 2.0 Rotating 4-port Hub! This GE Hub will allow you to receive the maximum possible bandwidth for all of your USB 2.0 and 1.1 devices! Please read this entire manual carefully before using your GE Rotating Hub.
Overview GE Hub technology gives you the best of USB 1.1 and 2.0 in one Hi-Speed USB 2.0 Hub. Connect USB 2.0 devices for data transfer rates of up to 480 Mbps. At the same time connect USB 1.1 devices for a guaranteed 12 Mbps of bandwidth per device.
III. Safety Instructions Always read the Safety Instructions carefully. Keep this user’s manual for future ➢ reference. Keep this equipment away ➢ from humidity. Do not expose to moisture. ➢ Replace if dropped and damaged. ➢ Replace if you see obvious signs ➢...
Power Mode Setting There are two power mode options for the GE Rotating USB 2.0 4-Port Hub. The first is self-power mode (recommended), which requires the use of the optional AC power adapter (Available at Jascoproducts. com). In this mode, each port is provided with 500 milliamps, allowing for additional hubs, cameras and other high-powered devices.
Hardware Installation Make sure your computer has all the nec- essary updates required to support USB. These can be found on Microsoft’s website. Position the Hub as desired. (Optional) Plug the optional AC power adapter into the Power Jack on the side of the USB 2.0 4-Port Hub.
Page 8
Hardware Installation Note: Refer to Section IV for more details on ac power adapter use. (Optional) Plug the optional AC power adapter into a standard electrical outlet or GE Surge Protector (recommended). The power LED should illuminate. Note: Refer to Section IV for more details. Plug the A-type connector of the USB 2.0 device cable into the USB port of your computer.
Software Installation Software installation is only required for Windows 98 and 98 SE users. Users of ® all other Operating Systems, including Windows NT, ME, 2000, VISTA, XP and ® any Mac OS, may skip this section. ® Connect the hub to your computer. Windows ®...
VII. Troubleshooting • Hub Not Seen Make sure you have installed all Windows updates and patches pertaining to USB. These are available on Microsoft’s website. Make sure all cables are properly connected. • Hub Not Working After Reboot Unplug the uplink cable (and the AC adapter cable if it is connected) from the hub.
VIII. Technical Specifications USB Hub: Standards: Operating Systems: Windows Data Speed: Upstream Ports: Downstream Ports: LEDs: Power: Dimension (LxWxH): 105 mm x 20 mm x 20 mm Operation Temp.: Humidity: External Power: 4 Ports USB 1.1 and 2.0 Compatible 98, 98 SE, ME, ®...
IX. FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
X. Limited Lifetime Warranty Jasco Products Co., Inc. warrants this product to be free from manufacturing defects regardless of how long you own it. This warranty is limited to the replacement of this product only and does not extend to consequential or incidental damage to other products that may be used with this unit.
Page 15
HO97844 Hub USB .0 giratorio de 4 puertos USB 2.0 Rotating MANUAL DE INSTRUCCIONES www.jascoproducts.com...
Page 16
INTRODUCCIÓN ... 3 GENERALIDADES ... 4 III. INSTRUCCIONES SOBRE SEGURIDAD ... 5 CONFIGURACIÓN DE LA ENTRADA DE CORRIENTE ... 6 INSTALACIÓN DEL HARDWARE ... 7 VI. INSTALACIÓN DEL SOFTWARE ... 9 VII. SOLUCIÓN DE PROBLEMAS ... 10 VIII. ESPECIFICACIONES TÉCNICAS ... 10 IX.
Introducción ¡Felicitaciones por su compra del Hub 2.0 giratorio de 4 puertos! ¡Este Hub de GE le permitirá recibir el mayor ancho de banda posible con todos sus aparatos 2.0 y 1.1! Antes de usar su Hub giratorio GE, lea cuidadosamente todo el manual.
II. Generalidades La tecnología del Hub GE le permite usar lo mejor del USB 1.1 y 2.0 con un sólo Hub USB 2.0 de alta velocidad. Conecte sus aparatos USB 2.0 y transfiera sus datos a velocidades de hasta 480 Mbps.
III. Instrucciones sobre seguridad Siempre lea con cuidado las instrucciones sobre seguridad. Guarde este manual para poder ➢ consultarlo en el futuro. Mantenga el equipo lejos de la humedad. ➢ No lo exponga al agua. ➢ Si el equipo se cae y se daña, ➢...
IV. Configuración de la entrada de corriente El Hub 2.0 giratorio de 4 puertos GE tiene dos tipos de entrada de corriente. En el primer modo (recomendado), autoalimentado, el Hub necesita el adaptador opcional de corriente (disponible en Jascoproducts. com). En este modo, cada puerto cuenta con 500 miliamperios, lo que permite que se puedan usar Hubs, cámaras y otros aparatos adicionales de alta potencia.
V. Instalación del Hardware Asegúrese de que su computadora tenga todas las actualizaciones necesarias para poder usar aparatos USB. Las podrá encontrar en la página web de Microsoft. Coloque el Hub donde lo desee. (Opcional) Conecte el adaptador opcional de corriente alterna a la toma de corriente que está...
Page 22
V. Instalación del Hardware 4 puertos. Nota: Para más detalles sobre cómo usar el adaptador de corriente, consulte la Sección IV. (Opcional) Conecte el adaptador opcional de corriente alterna a un enchufe estándar o al Protector de sobrecargas GE (se recomienda).
VI. Instalación del software Sólo deberá instalar el software si tiene instalado Windows 98 ó 98 SE. Si tiene otro Sistema ® Operativo como Windows XP o un Sistema Operativo para Mac ignorar esta sección. Conecte el Hub a su computadora. Windows ®...
VII. Solución de problemas • La computadora no reconoce el Hub Asegúrese de que haya instalado todas las actualizaciones y parches de Windows correspondientes a los puertos USB. Los podrá encontrar en la página web de Microsoft Asegúrese de que todos los cables estén conectados adecuadamente.
VIII. Especificaciones técni Hub USB: Estándares: Sistemas operativos: Windows Velocidad de transferencia de datos: Total: Entrada de puertos: Salidas de puertos: Luz indicadora: Fuente de poder: Tamaño (LxAxA): Temperatura operacional: 0°C ~ 40°C Humedad: Alimentación externa: CC +5V / 2.5A 4 puertos Compatible con USB 1.1 y 2.0 98, 98 SE, ME,...
IX. Declaración de conformidad de la FCC Este equipo ha sido probado y se ha encontrado que cumple con los límites para aparatos digitales Clase B, de acuerdo a la sección 15 de las Reglas de la FCC. Estos límites están diseñados para brindar una protección razonable sobre interferencias perjudiciales en instalaciones residenciales.
X. Garantía limitada de por vida Jasco Products Co. Inc. garantiza que este producto no presenta ningún defecto de fábrica independientemente del tiempo que lo haya tenido. Esta garantía está limitada sólo al reemplazo del producto y no se extiende al daño resultante o incidental de otros productos que se han usado con esta unidad.
