Chapter 2 Preparations
5.
Install the optical disk drive to the tray.
6.
Secure the bracket to optical disk drive
with a screw you have removed in Step 3.
7.
Insert the optical disk drive and secure the
drive tray with two screws you have
removed in Step 2.
8.
Connect the optical disk drive cable.
1.15.2 Removal
To remove an optical disk drive, reverse the installation procedure above.
Screw
Express5800/R120e-1M User's Guide
1. Installing Internal Optional Devices
Screw holes
Hooks
97
