- Page 1 5 IN 1 JUMP START MODEL NO: JS5IN1 PART NO: 6240005 OPERATION & MAINTENANCE INSTRUCTIONS LS0212...
-
Page 2: Environmental Protection
INTRODUCTION Thank you for purchasing this CLARKE product. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Safety Rules
Do not operate the jumpstart if any of the cables are damaged. Consult your Clarke dealer for repair or replacement of the parts. Do not operate the unit if the case is damaged. Consult your Clarke dealer or a qualified person for inspection and repair. -
Page 4: Electrical Connections
14. If battery acid comes into contact with the eyes, flush the eyes with clean water continuously and seek medical help. 15. Always ensure that there is air circulating around the unit when in use. 16. Never allow the negative and positive leads on this unit, to touch each other or to touch the same metal object. -
Page 5: Safety Symbols
SAFETY SYMBOLS Class II appliance Always read instructions before use Electrical Hazard due to exposed live terminals Chemical Hazard from battery acid USB Port Live centre pin Suitable for indoor use only (refers to mains adaptor only) Subject to Waste Electrical & Electronic Equipment Directive Parts &... - Page 6 OVERVIEW DESCRIPTION NO DESCRIPTION 12V Cigarette Plug Socket Charging Indicators Pressure Gauge USB Sockets 5V DC Outlet Air Compressor On/Off Switch Air Compressor Hose Compartment Worklight Charging Jack Socket Polarity Indicator Light Inverter Power Indicator Light Worklight On/Off Switch Inverter On/off Switch Voltage Test Button Inverter Status Lights Voltage Meter...
-
Page 7: Charging The Battery
CHARGING THE BATTERY Two means of charging the battery are provided. 1. Via a 230V supply, using the 230V charger with cable and DC plug provided, shown as ‘A’. 2. Via a 12V vehicle supply using the cigar lighter adapter with cable and plug provided, shown as ‘B’. -
Page 8: Using The 12V Adaptor
USING THE 12V ADAPTOR WARNING: BEFORE USING THE DC POWER SOURCE FROM THE CAR CIGARETTE SOCKET CHECK THAT ITS FUSE RATING IS RATED AT 15A OR HIGHER. 1. Ensure the vehicle is not running. 2. One end of the twelve volt lighter plug lead should be plugged into one of the two cigarette lighter sockets. -
Page 9: Operation
OPERATION USING THE USB POWER SUPPLY 1. Insert the USB cable into one of the USB sockets on the side of the unit. 2. Press the USB side of the INVERTER/ USB switch as shown. • This will supply a maximum 5V at 500mA. -
Page 10: Jump Starting
JUMP STARTING WARNING: IT IS POSSIBLE THAT SOME ELECTRONIC EQUIPMENT COULD BE DAMAGED BY JUMP STARTING. ALWAYS CHECK WITH THE CAR MANUFACTURER’S HANDBOOK TO DETERMINE WHAT PRECAUTIONS IF ANY SHOULD BE TAKEN. ALWAYS carry out the following preliminary checks: • Switch off the vehicle ignition and ALL ancillary equipment - lighting, radio etc. -
Page 11: Using The Air Compressor
USING THE AIR COMPRESSOR 1. Open the compartment door on the side of the unit to reveal the air hose. 2. Extend the air hose fully. 3. Attach the air hose to the tyre by pushing the connector down firmly on the tyre adapter and locking in place by turning the connector locking lever through 90 degrees. -
Page 12: Using The 12 Volt Power Supply
AN OUTPUT OF APPROX.13.5V. CONSULT THE APPLIANCE HANDBOOK TO ENSURE IT IS SAFE TO OPERATE FROM A 12V BATTERY. USING THE INVERTER WARNING: WHEN USING THE INVERTER FUNCTION THE JS5IN1 AND WHATEVER YOU ARE POWERING MUST BE INSIDE AWAY FROM ANY RAIN OR MOISTURE. -
Page 13: Maintenance
10.2 kg Please note that the details and specifications contained herein, are correct at the time of going to print. CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 15 NOTES Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
