Summary of Contents for Clarke JS1224LIN
- Page 1 12/24V JUMPSTARTER MODEL NO: JS1224LIN PART NO: 6238905 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL0723...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Jumpstarter. The JS1224LiN is a rechargable power pack which can be used to start a car in the event of a flat battery. The unit can also be used to power electrical appliances via a cigarette lighter type socket using the adaptor supplied. The unit also incorporates a built-in lamp and may be used as a stand alone light source.
-
Page 3: General Safety Rules
Consult your CLARKE dealer for repair or replacement. 5. DO NOT operate the jumpstarter if the case is damaged, NEVER attempt any repairs yourself. Consult your CLARKE dealer or a qualified person for inspection and repair. 6. Ensure the vehicle battery posts and battery clamps are perfectly clean before use. -
Page 4: Environmental Recycling Policy
ENVIRONMENTAL RECYCLING POLICY Through purchase of this product, the customer is taking on the obligation to deal with the WEEE in accordance with the WEEE regulations in relation to the treatment, recycling & recovery and environmentally sound disposal of the WEEE. -
Page 5: Component Identification
COMPONENT IDENTIFICATION 1 LED Work Light 24V Stage Indicator 2 Temperature Indicator 12V Stage Indicator 3 On/Off Button 10 12V to 24V Manual Shift Button 4 Starting/Connection Indicator 11 Black Negative (-) Cable & Clamp 5 Battery Status Indicator 12 Red Positive (+) Cable & Clamp 6 USB Indicator 13 Input Charging Adaptor 7 USB Charging Port... - Page 6 CHARGING JUMPSTARTER CAUTIONS 1. ALWAYS use the original charger for charging. Unqualified chargers will shorten the life of the product and may even be dangerous. 2. ALWAYS charge the unit before using for the first time (see below). 3. DO NOT charge for long periods of time unattended. 4.
- Page 7 • When fully charged the battery status indicator light will show a constant stable green light and charging will automatically shut off. NOTE: After charging is completed and the charger is not disconnected from the power source, the charging mode will automatically restart if the battery voltage drops to 12 volts.
- Page 8 starting stage and the 12V LED indicator will be stable green and the starting/connection indicator will flash green. When the vehicle battery voltage is detected between 15.5V and 30V, the jumpstarter will automatically set to the 24V starting stage and the 24V LED indicator will be a stable green and the starting/connection indicator will flash green.
- Page 9 TEMPERATURE INDICTOR CHART Sound Description Normal Temperature, enabled for jumpstarting Over Temperature, DO NOT USE for jumpstarting OVERRIDE JUMPSTARTING A battery with some charge must be connected to the vehicle circuit in order for the jumpstarter to select a start voltage. If the terminals are bad/loose fit on the battery, or the battery is so low as not to register a voltage then the jumpstarter will not select or provide a voltage.
-
Page 10: Running/Charging Usb Devices
8. If ignition waiting time exceeds 3 minutes, the jumpstarter will automatically turn itself off. Push the On/Off button or reconnect the clamps for the next jumpstart. RUNNING/CHARGING USB DEVICES 1. Connect a USB cable to the jumpstarters USB charging port 2. -
Page 11: Daily Care
Always turn the jumpstarter OFF during storage and store in an upright position, away from direct sunlight, moisture or sources of extreme heat or cold. NEVER attempt any repair unless your are a qualified technician. Your CLARKE jumpstarter has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. - Page 12 How many times can I Between 2 - 6 times, depending on the capacity and charge my mobile size of the device. device? How long can I leave There should be no problem storing for 6 - 12 months, the jumpstarter once but in order to prolong the service life, it is charged? recommended to fully charge the starter once every...
-
Page 13: Spare Parts
SPARE PARTS Spare Parts List Front Housing 11 Battery Pad - 2B Light Cover Bracket 12 Back Housing USB Protective Cover 13 Clamps Board (Black) Booster Cable with Clamp (Red) 14 Booster Cable with Clamp (Black) PCBA for BMS (Serial Connected) 15 Battery Pad - 3C PCBA for Voltage Selection &... - Page 14 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 15: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
