Summary of Contents for Clarke JS1000
- Page 1 JUMPSTART MODEL NO: JS1000, JS1010 & JS1224 PART NO: 6240040, 6240035 & 6240045 OPERATING & MAINTENANCE INSTRUCTIONS GC0514...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Jumpstart. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
-
Page 3: General Safety Rules
NOT leave it exposed to the elements. Avoid direct sunlight, direct heat, rain/moisture etc. 4. The Jumpstart JS1000 and JS1010 are designed for use with 12V systems while the JS1224 can be used with either 12 or 24V systems. 5. Do not operate the jumpstart if any of the cables are damaged. Consult your Clarke dealer for repair or replacement of the parts. -
Page 4: Environmental Recycling Policy
18. Always store the jumpstarter out of reach of children. 19. Always wear safety glasses when working with lead acid batteries. 20. If splashed by battery acid, immediately flush the area of the splash with clean water. If a burning sensation is felt or any blistering occurs, seek medical help. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS This product is provided with a 13 amp, 230 volt (50Hz), charging adaptor for connection to a standard, domestic electrical supply. This product is of double insulated design. No earth conductor is provided. If in any doubt, consult a qualified electrician. DO NOT attempt any electrical repairs yourself. -
Page 6: Component Identification
COMPONENT IDENTIFICATION The JS1000, JS1010 and JS1224 are a range of rechargable power supplies which can be used to start a car in the event of a flat battery. The units can also be used to power electrical appliances via a cigar lighter type socket using the adaptor supplied. - Page 7 1. Work Light ON/OFF switch 2. Lamp/work light 3. Red LED (charging) 4. Green LED (charged) 5. Battery condition gauge 6. 12V DC socket connection 7. Alert LED (incorrect polarity alarm) 8. Compressed air pressure gauge (JS1010 models only) or 12/24V Selector (JS1224 models only): 9.
-
Page 8: Initial Battery Charging
INITIAL BATTERY CHARGING 1. Charge your jumpstart battery before using it for the first time. 2. Recharge the jumpstart battery after every occasion of use if possible, and thereafter, at least every 30 days. 3. Always avoid leaving your jumpstart in a state of discharge. FOLLOW THE ABOVE POINTS TO ENSURE MAXIMUM LIFE FROM THE BATTERY. -
Page 9: Operation
Turn the unit on and a beep will be heard, indicating that there is power to the booster clamps. CHARGING USING THE 12V ADAPTOR 1. Plug the jack plug into the charging socket at the rear of the unit, then into the cigarette lighter socket on the vehicle and start the engine. - Page 10 1. Turn the vehicle ignition off before connecting the booster cables. 2. Take great care not to touch the red positive (+) clamp against the black negative (-) clamp. 3. Ensure the area is well ventilated. 4. Ensure the ON/OFF switch is in the OFF position. 5.
- Page 11 RECHARGING Recharge the unit following each period of use. The unit must be charged at least every 3 months but it is recommended that a ‘top-up’ charge is desirable after every 30 days. NOTE: Failure to do so will result in possible damage to the internal battery and result in poor performance from partial failure to operate due to the poor condition of the battery.
-
Page 12: Using The Air Compressor (Js1010 Only)
USING THE AIR COMPRESSOR (JS1010 ONLY) WARNING: THE AIR COMPRESSOR GAUGE ON THIS PRODUCT IS FOR GUIDANCE ONLY. IT IS IMPORTANT YOU CHECK YOUR TYRE PRESSURE ON AN APPROVED GAUGE. The outlet hose from the compressor is housed inside the storage compartment at the rear of the machine. -
Page 13: Technical Specification
NEVER attempt any repair unless your are a qualified technician. If you have a problem with the machine contact your local Clarke dealer. Your Clarke jumpstart has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems,take the unit to your local Clarke dealer. -
Page 14: Component Parts Js1000
COMPONENT PARTS JS1000 Description No Description 12V-17AH Battery Main Handle Light Indication PCB Front Housing 15A Circuit Breaker Positive Battery Lead Main Charging PCB Negative Battery Lead On/Off Switch Power Cable Adaptor Neg Electrode Handle Upright (L/F) Voltage Meter Handle Upright (R/F) -
Page 15: Component Parts Js1010
COMPONENT PARTS JS1010 Description No Description 12V-17AH Battery Front Housing Light Indication PCB Positive Battery Lead/clamp Circuit Breaker Negative Battery Lead/clamp Voltage Test Switch DC Adaptor Cable On/Off Switch Worklight Switch Adaptor Neg Electrode Pump Rocker Switch DC Voltage Meter Handle Upright (L/F) Charging Adaptor Handle Upright (R/F) -
Page 16: Component Parts Js1224
COMPONENT PARTS JS1224 Description No Description 12V-22AH Battery DC Adaptor Cable Light Indication PCB Worklight Switch Circuit Breaker Switch Cap Test Button Switch Holder On/Off Switch Upper Front Panel Cigarette Lighter Socket Main Charging PCB DC Voltage Meter On/Off Switch Cap Charging Adaptor Rear Casing Panel Rear Housing... - Page 17 Front Housing Handle Upright (R/R) Positive Battery Lead Front Cover Negative Battery Lead IMPORTANT: When requesting component parts for these products, please refer to the pre-fix GRBMZ/JS1000/01 onwards. as applicable. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 18: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 19 NOTES ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
