- Page 1 Ultra Micro FPV Vapor ® Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
-
Page 2: Safety Precautions And Warnings
Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. -
Page 3: Specifications
Box Contents Includes Includes Installed Motor: 6mm Brushed Receiver: 3-Ch Rx/ESC DSMX (PKZU1152) Ultra Micro FPV camera: wide angle lens, Integrated Recommended Transmitter: CP antenna, Compatible ™ ® ® Spektrum DSM2 /DSMX full with 5.8GHz Fat Shark range (DX4e and up) systems Li-Po BATTERY PACK 7.4V 760mAh... -
Page 4: Preflight Checklist
Prefl ight Checklist 1. Charge flight battery. 7. Adjust center of gravity. 2. Install flight battery in aircraft (once it 8. Perform a radio system Range Check. has been fully charged). 9. Find a safe and open area. 3. -
Page 5: Transmitter And Receiver Binding
Flight Battery Charger Warnings The battery charger (EFLC1008) included with your • Always inspect the battery before charging. aircraft has been designed to safely charge the • Always disconnect the battery after charging, and Li-Po battery. let the charger cool between charges. •... -
Page 6: The Transmitter
The Transmitter Installing the Transmitter Batteries ® Your ParkZone 4-channel DSM2/DSMX RTF transmitter comes pre-bound to the aircraft. Transmitter Control Mode 2 Mode 1 Transmitter Type Mode 2 Mode 1 Elevator/ Throttle/ Throttle/ Elevator/ Rudder Rudder Aileron Aileron Aileron Aileron Rudder Rudder Trim... -
Page 7: Flight Battery Installation And Esc Arming
Flight Battery Installation and ESC Arming Arming the ESC also occurs after binding as previously described, but subsequent connection Lower throttle and of a fl ight battery requires the following steps. throttle trim to lowest settings. It is normal for linear servos to make noise. Noise is not an indication of a faulty servo. -
Page 8: Control Direction Test
Control Direction Test Bind your aircraft and transmitter before doing these tests. Move the controls on the transmitter to make sure aircraft control surfaces move correctly. Always keep throttle at the low position during testing. Down Elevator Elevator Left Rudder Right Rudder... -
Page 9: First Person View (Fpv) System Instructions
First Person View (FPV) System instructions Headset Charger Warnings The battery charger included with your product has • Always inspect the battery before charging. been designed to safely charge the Li-Po battery. • Always disconnect the battery after charging, and let the charger cool between charges. -
Page 10: Setting Up The Headset
First Person View (FPV) System instructions (continued) Setting up the headset CAUTION: Do not power the headset or downlink kit without the antenna attached. Doing so will damage the transmitter and receiver amplifi ers. Amplifi er damage is not covered by warranty. -
Page 11: Caring For The Video Transmitter Antenna
First Person View (FPV) System instructions (continued) Using the Ultra Micro FPV System NOTICE: We do not recommend using the ultra micro FPV system in low light. Consult local laws and ordinances before operating FPV equipment. In some areas, FPV operation may be limited or prohibited. -
Page 12: Flying Tips And Repairs
Flying Tips and Repairs We recommend flying your aircraft inside a large Low Voltage Cutoff (LVC) gymnasium or outdoors in calm or light winds. The Low Voltage Cutoff (LVC) pulses the power to the aircraft is extremely light and can be easily blown motor when the voltage gets low. -
Page 13: Power Components Service
Power Components Service CAUTION: DO NOT handle propeller parts while the fl ight battery is connected. Personal injury could result. Disassembly 1. Disconnect the battery from the ESC/receiver. 2. Hold the spur gear and turn the propeller counterclockwise (looking from the front of the model) to remove. -
Page 14: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Aircraft will not respond Throttle stick and/or throttle trim too high Reset controls with throttle stick and throttle to throttle but responds trim at lowest setting to other controls Throttle channel is reversed Reverse throttle channel on transmitter Motor disconnected from receiver Make sure motor is properly connected to the receiver... -
Page 15: Limited Warranty
HORIZON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the liability Horizon Hobby, LLC. (“Horizon”) warrants to the original of Horizon exceed the individual price of the Product on purchaser that the product purchased (the “Product”) will which liability is asserted. -
Page 16: Warranty And Service Information
+44 (0) 1279 641 097 Horizon Hobby Limited CM18 7NS, United Kingdom Horizon Technischer Service service@horizonhobby.de Christian-Junge-Straße 1 Germany 25337 Elmshorn, Germany Sales: Horizon Hobby GmbH +49 (0) 4121 2655 100 infofrance@horizonhobby.com Service/Parts/Sales: 11 Rue Georges Charpak France Horizon Hobby SAS 77127 Lieusaint, France +33 (0) 1 60 18 34 90 info@horizonhobby.com.cn... -
Page 17: Icc Information
EN55022:2010 + AC:2011 EN55024:2010 EN 62479:2010 Signed for and on behalf of: EN 60950-1:2006+A11:2009+A1:2010+A12: 2011 Mike Dunne Horizon Hobby, LLC Executive Vice President Champaign, IL USA Product Divisions October 2, 2014 Horizon Hobby, LLC Signed for and on behalf of:... - Page 18 Istruzioni per lo smaltimento di WEEE da parte di utenti dell’Unione Europea Non smaltire questo prodotto assieme ai rifi uti domestici. È responsabilità dell’utente lo smaltimento di tali rifi uti, che devono essere portati in un centro di raccolta predisposto per il riciclaggio di rifi...
-
Page 19: Optional Parts And Accessories
Part # • Nummer Description Beschreibung Description Descrizione Numéro • Codice Fuselage with Parkzone Rumpf mit Fuselage avec Fusoliera con PKZU1161 Electronics: Night Elektronik: Night Vapor électronique: Vapor/ elettronica: Vapor/ Vapor Night Vapor Night Vapor Bare Fuselage: Parkzone Rumpf: Night Fuselage nu: Vapor/ Solo fusoliera: Vapor/ PKZU1167... - Page 20 © 2014 Horizon Hobby, LLC. E-fl ite, ParkZone, Vapor, DSM, DSM2, DSMX, ModelMatch, Bind-N-Fly, the Bind-N-Fly logo and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
