- Page 1 ™ P-47 Thunderbolt Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
-
Page 2: Safety Precautions And Warnings
Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. -
Page 3: Table Of Contents
Table of Contents Transmitter and Receiver Binding ......4 Post Flight Checklist ..........9 Low Voltage Cutoff (LVC) ........4 Power Components Service .........10 ESC/Receiver Arming, Battery Installation Troubleshooting Guide .........11 and Center of Gravity ..........5 Limited Warranty ..........12 Control Direction Test ..........6 Warranty and Service Information ......14 AS3X Control Direction Test ........6 IC Information ............14... -
Page 4: Transmitter And Receiver Binding
Transmitter and Receiver Binding Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifi er) ™ code of a single specifi c transmitter. You need to ‘bind’ your chosen Spektrum DSM2/DSMX technology equipped aircraft transmitter to the receiver for proper operation. Any full range Spektrum DSM2/DSMX transmitter can bind to the DSM2/DSMX receiver. -
Page 5: Esc/Receiver Arming, Battery Installation And Center Of Gravity
ESC/Receiver Arming, Battery Installation and Center of Gravity CAUTION: Always keep hands away from the propeller. When armed, the motor will turn the propeller in response to any throttle movement. Arming the ESC/receiver occurs after binding, but subsequent connection of a fl ight battery requires the following steps. -
Page 6: Control Direction Test
Control Direction Test Move the controls on the transmitter to make sure the aircraft control surfaces move correctly and in the proper direction. Make sure the tail linkages move freely and that paint or decals are not adhered to them. ®... -
Page 7: Control Centering
Control Centering Before the fi rst fl ight, or in the event of an accident, make sure the fl ight control surfaces are centered. Adjust the linkages mechanically if the control surfaces are not centered. Use of the transmitter sub-trims may not correctly center the aircraft control surfaces due to the mechanical limits of linear servos. -
Page 8: Landing Gear Removal
Landing Gear Removal Main Gear 1. Carefully rotate each strut until it snaps away from the gear plate. NOTICE: DO NOT damage the leading edge of the wing when removing the landing gear. 2. Pull the landing gear strut out of the mounting plate hole. -
Page 9: Flying Tips And Repairs
Flying Tips and Repairs We recommend fl ying your aircraft outside in calm Failure to lower the throttle conditions. Always avoid fl ying near houses, trees, stick and trim to the lowest CAUTION: wires and buildings. You should also be careful to possible positions during a Always decrease avoid fl... -
Page 10: Power Components Service
Power Components Service Disassembly CAUTION: DO NOT handle the propeller while the fl ight battery is connected to the ESC. Personal injury could result. Propeller 1. Remove the spinner (A) from the propeller. Since the propeller and spinner are glued together, glue residue will need to be cleaned from the spinner or propeller when these parts are used again. -
Page 11: Troubleshooting Guide
Troubleshooting Guide AS3X Problem Possible Cause Solution Control surfaces not at Control surfaces may not have been Center control surfaces mechanically by neutral position when mechanically centered from factory adjusting the U-bends on control linkages transmitter controls are Aircraft was not kept immobile for 5 Keep the aircraft immobile for 5 seconds after at neutral seconds after battery was plugged in... -
Page 12: Limited Warranty
Zero and adjust linkages mechanically Limited Warranty What this Warranty Covers Horizon Hobby, LLC, (Horizon) warrants to the OTHER THAN THE EXPRESS WARRANTY ABOVE, original purchaser that the product purchased (the HORIZON MAKES NO OTHER WARRANTY OR “Product”) will be free from defects in materials and REPRESENTATION, AND HEREBY DISCLAIMS ANY workmanship at the date of purchase. - Page 13 Horizon reserves the right to inspect any and all without additional protection. Ship via a carrier Product(s) involved in a warranty claim. Service or that provides tracking and insurance for lost or replacement decisions are at the sole discretion damaged parcels, as Horizon is not responsible for of Horizon.
-
Page 14: Warranty And Service Information
European Union EFL UMX P47 BNF Basic (EFLU3250) This product must not be disposed EU Compliance Statement: Horizon Hobby, LLC of with other waste. Instead, it is the hereby declares that this product is in compliance user’s responsibility to dispose of their... -
Page 15: Replacement Parts
Replacement Parts – Ersatzteile – – Pièces de rechange – Recapiti per i ricambi – Part # • Nummer Description Beschreibung Description Descrizione Numéro • Codice Pushrod Set: UMX UMX P47 BL: UMX P-47 BL - Set de Set aste comandi: EFLU3246 P-47 BL UMX P-47 BL... -
Page 16: Optional Parts And Accessories
– Optional Parts and Accessories – – Optionale Bauteile und Zubehörteile – – Pièces optionnelles et accessoires – – Parti opzionali e accessori – Part # • Nummer Description Beschreibung Description Descrizione Numéro • Codice 5.75 x 2.50 Electric Klettband (5): Ultra Bande auto- Set fascette fi... - Page 17 © 2015 Horizon Hobby, LLC. E-fl ite, AS3X, UMX, DSM, DSM2, DSMX, ModelMatch, Bind-N-Fly, Celectra and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
