SPCH LAN
When the optional UT-102
is installed, you can select between English and
Japanese as the language.
SPCH SPD
When the optional UT-102
is installed, you can select between faster or slower
synthesizer output.
CIV ADDR
To distinguish equipment, each CI-V transceiver/
receiver has its own Icom standard address in hexa-
decimal code. The IC-R8500's address is 4AH.
When 2 or more IC-R8500's are connected to an
optional CT-17 -
ci v level converter
main dial to select a different address for each
IC-R8500 in the range 01H to 7FH.
CIV BAUD
This item sets the data transfer rate. When "AUTO"
is selected, baud rate is automatically set according
to the connected controller or other Icom CI-V radio.
CIV TRAN
Transceive operation is possible with the IC-R8500
connected to an Icom CI-V radio. When "ON" is
selected, changing the frequency, operating mode,
etc. on the IC-R8500 automatically changes those of
connected radios and vice versa.
CIV 731
When connecting the IC-R8500 to the IC-735 for
transceive operation, you must change the operating
frequency data length to 4 bytes.
• This item must be set to "ON" only when operating trans-
ceive with the IC-735.
voice synthesizer unit
voice synthesizer unit
, rotate the
ENG
Voice synthesizer functions
in English (default).
FAST
Voice synthesizer output
is faster (default).
4AH
Address set to 4AH
(default).
AUTO
Auto baud rate
(default).
ON
Transceive ON
(default).
OFF
Frequency data set to
5 bytes (default).
8
SET MODE
JPN
Voice synthesizer functions
in Japanese.
SLOW
Voice synthesizer output
is slower.
01H
Address set to 01H.
19200
19200 bps
OFF
Transceive OFF.
ON
Frequency data set to
4 bytes.
32
