[TEN-KEY BOARD]
REF ORDER
NO. NO.
Q1 1590002310 S.TRANSISTOR
Q2 1590002310 S.TRANSISTOR
Q3 1590002310 S.TRANSISTOR
Q4 1590002310 S.TRANSISTOR
Q5 1590002310 S.TRANSISTOR
R1 7030003540 S.RESISTOR
R2 7030003480 S.RESISTOR
R3 7030003520 S.RESISTOR
R4 7030003580 S.RESISTOR
R5 7030003540 S.RESISTOR
R6 7030003480 S.RESISTOR
R7 7030003520 S.RESISTOR
R8 7030003530 S.RESISTOR
R9 7030003530 S.RESISTOR
R10 7030003420 S.RESISTOR
R11 7030003440 S.RESISTOR
R12 7030003440 S.RESISTOR
C1 4030011600 S.CERAMIC
C2 4030011600 S.CERAMIC
J1 6510019980 S.CONNECTOR
J2 6510021560 S.CONNECTOR
DS1 5040002110 S.LED
DS2 5040002110 S.LED
DS3 5040002220 S.LED
DS4 5040002220 S.LED
DS5 5040002220 S.LED
S1 2260001890 S.SWITCH
S2 2260001890 S.SWITCH
S3 2260001890 S.SWITCH
S4 2260001890 S.SWITCH
S5 2260001890 S.SWITCH
S6 2260001890 S.SWITCH
S7 2260001890 S.SWITCH
S8 2260001890 S.SWITCH
S9 2260001890 S.SWITCH
S10 2260001890 S.SWITCH
S11 2260001890 S.SWITCH
S12 2260001890 S.SWITCH
S13 2260001890 S.SWITCH
S14 2260001890 S.SWITCH
S15 2260001890 S.SWITCH
S16 2260001890 S.SWITCH
S17 2260001890 S.SWITCH
S18 2260001890 S.SWITCH
S19 2260001890 S.SWITCH
S20 2260001890 S.SWITCH
S21 2260001890 S.SWITCH
S22 2260001890 S.SWITCH
S23 2260001890 S.SWITCH
S24 2260001890 S.SWITCH
S25 2260001890 S.SWITCH
S26 2260001890 S.SWITCH
S27 2260001890 S.SWITCH
S28 2260001890 S.SWITCH
S29 2260001890 S.SWITCH
S30 2260001890 S.SWITCH
S31 2260001890 S.SWITCH
EP1 0910052272 PCB
DESCRIPTION
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTC114EE TL
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
52808-1690
52808-2490
CL-200HR-C-TU
CL-200HR-C-TU
CL-220YG-C-TU
CL-220YG-C-TU
CL-220YG-C-TU
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
B 5403B

[RIT BOARD]

REF ORDER
NO. NO.
J1 6510019970 S.CONNECTOR
S1 2250000340 ENCODER
EP1 0910052300 PCB
[RF UNIT]
REF ORDER
NO. NO.
IC151 1110001890 S.IC
IC451 1110003970 S.IC
IC841 1110003490 S.IC
IC871 1110003870 S.IC
IC901 1130007700 S.IC
IC902 1130007570 S.IC
IC903 1160000130 S.IC
IC904 1160000130 S.IC
IC961 1110004130 S.IC
Q131 1590002310 S.TRANSISTOR
Q132 1590002310 S.TRANSISTOR
Q141 1590002710 S.TRANSISTOR
Q143 1590002310 S.TRANSISTOR
Q151 1590002710 S.TRANSISTOR
Q152 1510000510 S.TRANSISTOR
Q153 1590002310 S.TRANSISTOR
Q441 1560000720 S.FET
Q442 1560000720 S.FET
Q501 1560000720 S.FET
Q511 1560000640 S.FET
Q512 1560000640 S.FET
Q513 1560000640 S.FET
Q514 1560000640 S.FET
Q531 1530002060 S.TRANSISTOR
Q532 1540000550 S.TRANSISTOR
Q551 1560000640 S.FET
Q561 1530003150 S.TRANSISTOR
Q601 1560000720 S.FET
Q611 1560000640 S.FET
Q612 1560000640 S.FET
Q613 1560000640 S.FET
Q614 1560000640 S.FET
Q631 1530002060 S.TRANSISTOR
Q632 1540000550 S.TRANSISTOR
Q651 1560000640 S.FET
Q661 1530003150 S.TRANSISTOR
Q701 1560000560 S.FET
Q721 1580000620 S.FET
Q722 1590002480 S.TRANSISTOR
Q751 1560000560 S.FET
Q781 1530002060 S.TRANSISTOR
Q801 1530002060 S.TRANSISTOR
Q811 1560000560 S.FET
Q812 1560000560 S.FET
Q831 1560000560 S.FET
Q901 1590002710 S.TRANSISTOR
Q902 1590002710 S.TRANSISTOR
Q903 1590002480 S.TRANSISTOR
Q904 1590002480 S.TRANSISTOR
Q905 1590002480 S.TRANSISTOR
Q941 1560000640 S.FET
Q942 1560000640 S.FET
Q943 1560000640 S.FET
Q944 1560000640 S.FET
Q945 1540000550 S.TRANSISTOR
D101 1750000300 S.DIODE
D102 1750000300 S.DIODE
D131 1750000450 S.DIODE
D141 1750000450 S.DIODE
D142 1790000620 S.DIODE
D151 1790001250 S.DIODE
D152 1790001250 S.DIODE
5 - 5
DESCRIPTION
52808-1090
EVQ-VCJF0324B
B 5405
DESCRIPTION
µPC1678G-E2
µPC1658G-E1
TA31136FN (D,EL)
NJM2058M-T1
BU4094BCF-T1
BU4094BCFV-E2
TD62783AF (TP1)
TD62783AF (TP1)
µPC2708T-E3
DTC114EE TL
DTC114EE TL
UMH11NTN
DTC114EE TL
UMH11NTN
2SA1576A T106R
DTC114EE TL
2SK2171-4-TD
2SK2171-4-TD
2SK2171-4-TD
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SC4081 T107 R
2SD1664 T100Q
2SK1740-TA
2SC4673D-TD
2SK2171-4-TD
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SC4081 T107 R
2SD1664 T100Q
2SK1740-TA
2SC4673D-TD
2SK882-GR (TE85L)
3SK131-T2 MAS
UMC3N TR
2SK882-GR (TE85L)
2SC4081 T107 R
2SC4081 T107 R
2SK882-GR (TE85L)
2SK882-GR (TE85L)
2SK882-GR (TE85L)
UMH11NTN
UMH11NTN
UMC3N TR
UMC3N TR
UMC3N TR
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SD1664 T100Q
1SS302 (TE85R)
1SS302 (TE85R)
1SV265-TL
1SV265-TL
MA77 (TX)
MA2S111-(TX)
MA2S111-(TX)
S.=Surface mount
