SECTION 6
[FRONT PARTS]
REF. ORDER
NO. NO.
DS1 5080000450 Lamp SLU2LC1EX5B-TH
EP1 6910011090 Sensor unit RMS20-250-201-P
EP2 6450001230 Snap plate HLJ0999-01-480
EP3 6450001230 Snap plate HLJ0999-01-480
EP4 6910012500 Unit board TFD50W40-A (LCD)
ME1 5510000490 Meter ME-41 (KL-293S-11)
MP1 8210021251 1876 front panel (D)-1
MP2 8010016722 1876 SUB chassis-2
MP3 8930041380 1876 window plate
MP4 8930056110 1876 power button (A)
MP5 8930050370 1876 4-key (A)
MP6 8930056090 1876 key board (B)
MP7 8930056100 1876 7-key (B)
MP8 8930050380 1876 5-key (A)
MP9 8930056080 1876 10-key (B)
MP10 8930041280 1876 2-key
MP11 8610010720 Knob N273
MP12 8610010260 Knob N252
MP13 8610010270 Knob N253
MP14 8610010650 Knob N268 assembly
MP19 8310063330 2178 B-name plate
MP20 8930041060 1876 brake plate
MP21 8930027470 1296 brake pad
MP23 8810008660 Screw PH BT M3 × 8 NI-ZU
MP24 8810008760 Screw PH BT M2 × 8 NI-ZU
Screw PH BT M2 × 8 NI-ZU
MP25 8810008760
MP26 8810009560 Screw PH BT M2 × 6 ZK
MP27 8810009560 Screw PH BT M2 × 6 ZK
MP29 8820000770 1296 screw
MP30 8810009390 Screw PH BT M3 ×18 NI-ZU
MP40 8810008760 Screw PH BT M2 × 8 NI-ZU
MP41 8810008760 Screw PH BT M2 × 8 NI-ZU
MP49 8810008200 Screw PH BT M2.6 × 6 NI-ZU
MP50 8810007300 Screw PH B0 M2.6 × 14 ZK
MP51 8610010740 Knob N273 (A)
MP52 8610010730 Knob N252 (A)
MP53 8850001250 Flat washer M2.6
MP54 8930051520 Sheet
MP60 8930057320 2178 LCD sheet
MP61 8930057340 Copper coated sheet (L)
MP62 8930057340 Copper coated sheet (L)
MP63 8930050280 Copper coated sheet (H)
MP70 8930064540 Shield sponge (AN)

[DISPLAY BOARD]

REF. ORDER
NO. NO.
R701 7210002890 Variable resistor RK161221005J/RV-308
R702 7210002890 Variable resistor RK161221005J/RV-308
MP1 8510012630 2178 shield case
MP3 8510010760 1876 DDS case
MP4 8510010770 1876 DDS cover
MP5 8510001081 Shield case (A)-1
MP6 8510001101 Shield case (A) cover (A)-1
MP7 8210013980 1876 reflector
MP8* 8930054530 2355 earth spring
MECHANICAL PARTS AND DISASSEMBLY
DESCRIPTION QTY.
DESCRIPTION QTY.

[PHONE BOARD]

REF. ORDER
NO. NO.
1 J2 6450001980
1 MP1* 8930054900
1
1
1

[KEY BOARD]

1
REF. ORDER
NO. NO.
1
J2 6450001790
1
1
MP1* 8930054530
1
1
1
1

[MIC BOARD]

1
1
REF. ORDER
1
NO. NO.
3
J1 6510000190
3
1
MP1* 8930024170
1
1
1
1

[PBT BOARD]

6
REF. ORDER
1
NO. NO.
2
R1 7210002970
6
6
S1 2250000410
1
1
2
2

[RIT BOARD]

2
1
REF. ORDER
1
NO. NO.
1
S1 2250000340
1
1
1
1
1
Note *: Refer to SECTION 8
1
1
1
1
1
1
1
1
1
1
1
6 - 1
DESCRIPTION
Connector HLJ5815-01-030
2356 earth spring
DESCRIPTION
Connector HLJ7000-01-3010
2355 earth spring
DESCRIPTION
Connector FM214-8SS (P)
Earth spring (G)
DESCRIPTION
Variable resistor RV-314
Encoder TP90D96E20-30F-2178-1
DESCRIPTION
Encoder EVQ-VCJF0324B
QTY.
1
1
QTY.
1
1
QTY.
1
1
QTY.
1
1
QTY.
1
