Icom IC-756PRO Service Manual page 58

[CTRL UNIT]
REF ORDER
NO. NO.
C57 4030006880 S.CERAMIC
C58 4030006880 S.CERAMIC
C59 4030006880 S.CERAMIC
C60 4030006880 S.CERAMIC
C62 4030006880 S.CERAMIC
C63 4030007090 S.CERAMIC
C64 4030007030 S.CERAMIC
C65 4030007120 S.CERAMIC
C66 4030007070 S.CERAMIC
C69 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C70 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C71 4030006880 S.CERAMIC
C72 4510006260 S.ELECTROLYTIC ECEV1AA471UP
C73 4030006880 S.CERAMIC
C74 4030006880 S.CERAMIC
C75 4030006880 S.CERAMIC
C76 4030006880 S.CERAMIC
C77 4030006880 S.CERAMIC
C78 4030006880 S.CERAMIC
C79 4030006880 S.CERAMIC
C80 4030006880 S.CERAMIC
C81 4030006880 S.CERAMIC
C82 4030006880 S.CERAMIC
C83 4030006880 S.CERAMIC
C84 4030006880 S.CERAMIC
C85 4030006880 S.CERAMIC
C86 4030006880 S.CERAMIC
C87 4030006880 S.CERAMIC
C88 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C89 4030006880 S.CERAMIC
C90 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C91 4030006880 S.CERAMIC
C92 4030006880 S.CERAMIC
C93 4030006880 S.CERAMIC
C94 4030006880 S.CERAMIC
C95 4030006880 S.CERAMIC
C96 4030006880 S.CERAMIC
C97 4030006880 S.CERAMIC
C98 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C100 4030007130 S.CERAMIC
C101 4030006880 S.CERAMIC
C102 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C105 4030011540 S.CERAMIC
C107 4010005580 CERAMIC
C108 4010005560 CERAMIC
C109 4030011600 S.CERAMIC
C200 4030007090 S.CERAMIC
C201 4030007090 S.CERAMIC
C202 4030007090 S.CERAMIC
C209 4030006900 S.CERAMIC
C210 4030006900 S.CERAMIC
C211 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C212 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C213 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C214 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C215 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C216 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C217 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C218 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C220 4030006880 S.CERAMIC
C221 4030007090 S.CERAMIC
C222 4030007090 S.CERAMIC
C223 4030007090 S.CERAMIC
C224 4030006880 S.CERAMIC
C225 4030006880 S.CERAMIC
C226 4030006880 S.CERAMIC
C227 4030006880 S.CERAMIC
RL1 6330001450 RELAY
RL2 6330001450 RELAY
RL3 6330000800 RELAY
RL4 6330000470 RELAY
J1 6510007900 CONNECTOR
J2 6510007900 CONNECTOR
J3 6510017150 CONNECTOR
J4 6510017150 CONNECTOR
J7 6510019990 S.CONNECTOR
J8 6510019990 S.CONNECTOR
J10 6510003410 CONNECTOR
DESCRIPTION
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 150J-T-A
C1608 CH 1H 820J-T-A
C1608 CH 1H 330J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 101J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 750J-T-A
HM60SJ SL 070D 500V
HM60SJ SL 050C 500V
C1608 JB 1C 104KT-N
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
FXE-12G
FXE-12G
G5A-237P DC12V
NR-HD (12V) AE5343
TBP-P01X-A1 (B1)
TBP-P01X-A1 (B1)
TMP-S01X-C1
TMP-S01X-C1
52808-2290
52808-2290
B05B-EH-S
[CTRL UNIT]
REF ORDER
NO. NO.
J11 6510003410 CONNECTOR
J12 6910001040 CONNECTOR
J13 6510019970 S.CONNECTOR
J14 6910001040 CONNECTOR
P1 6510003240 CONNECTOR
P2 6510003240 CONNECTOR
W1 7120000490 JUMPER
W2 7120000490 JUMPER
W3 7120000490 JUMPER
W4 7030003860 S.JUMPER
EP1 0910051822 PCB
[PA UNIT]
REF ORDER
NO. NO.
IC1 1180001070 S.IC
IC2 1110002020 IC
IC3 1180001980 IC
Q1 1530000790 TRANSISTOR
Q2 1530000800 TRANSISTOR
Q3 1530000800 TRANSISTOR
Q4 1530003740 TRANSISTOR
Q5 1530003740 TRANSISTOR
Q8 1540000500 TRANSISTOR
Q9 1590001150 S.TRANSISTOR
Q10 1530002060 S.TRANSISTOR
Q11 1530002060 S.TRANSISTOR
Q12 1520000650 S.TRANSISTOR
Q13 1520000650 S.TRANSISTOR
D1 1790000710 VARISTOR
D2 1790000710 VARISTOR
D3 1790000710 VARISTOR
D4 1790000700 DIODE
D5 1790000700 DIODE
D7 1160000140 S.DIODE
D8 1790000700 DIODE
D9 1160000140 S.DIODE
D10 1710000970 DIODE
L1 6140003240 S.COIL
L2 2040000490 COIL
L3 2040000490 COIL
L4 6140001180 COIL
L5 2040000490 COIL
L6 6140003510 COIL
L7 6140000610 COIL
L8 6140002030 COIL
L9 2040000490 COIL
L10 2040000490 COIL
L12 2040000490 COIL
L14 6140003230 S.COIL
L21 6110001730 COIL
L22 2040000490 COIL
R1 7030003380 S.RESISTOR
R2 7030003230 S.RESISTOR
R3 7030003380 S.RESISTOR
R4 7030003360 S.RESISTOR
R5 7030003390 S.RESISTOR
R6 7030003360 S.RESISTOR
R7 7030006210 S.RESISTOR
R8 7030008230 S.RESISTOR
R9 7030008230 S.RESISTOR
R10 7030003420 S.RESISTOR
R11 7310003750 TRIMMER
5 - 31
DESCRIPTION
B05B-EH-S
IPS-1136
52808-1090
IPS-1136
TMP-P01X-A1
TMP-P01X-A1
ERD25T0
ERD25T0
ERD25T0
ERJ3GE JPW V
B 5300B
DESCRIPTION
TA7805F (TE16L)
TA7805S
MC78T08CT
2SC1971
2SC1972
2SC1972
2SC5125
2SC5125
2SD1585K
UN9211 (TX)
2SC4081 T107 R
2SC4081 T107 R
2SB1201-S-TL
2SB1201-S-TL
MA29B
MA29B
MA29B
DSA3A1
DSA3A1
DAP222 TL
DSA3A1
DAP222 TL
MA185
LR-361
EXC-ELDR25C
EXC-ELDR25C
LR-143
EXC-ELDR25C
LR-393
LR-83
LR-230
EXC-ELDR25C
EXC-ELDR25C
EXC-ELDR25C
LR-360
LA-262
EXC-ELDR25C
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 180 V (18 Ω)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ12YJ4R7H (4.7 Ω)
ERJ1WYJ1R0H (1 Ω)
ERJ1WYJ1R0H (1 Ω)
ERJ3GEYJ 681 V (680 Ω)
EVN-2ACA00 B52 (501)
S.=Surface mount
