Icom IC-756PRO Service Manual page 54

[PLL UNIT]
REF ORDER
NO. NO.
P851 6510003240 CONNECTOR
P901 6510003240 CONNECTOR
W1 7030003860 S.JUMPER
W2 7030003860 S.JUMPER
W6 7030003860 S.JUMPER
W10 7030003860 S.JUMPER
W25 7030003860 S.JUMPER
W28 7030003860 S.JUMPER
W29 7030003860 S.JUMPER
W32 7030003860 S.JUMPER
W33 7030003860 S.JUMPER
W51 7030003860 S.JUMPER
W92 7030003860 S.JUMPER
W121 7030003860 S.JUMPER
W122 7030003860 S.JUMPER
W151 7030008240 S.JUMPER
W155 7030003860 S.JUMPER
W181 7030003860 S.JUMPER
W201 7030003970 S.JUMPER
W202 7030008240 S.JUMPER
W221 7030000010 S.JUMPER
W222 7030008240 S.JUMPER
W251 7030000010 S.JUMPER
W252 7030008240 S.JUMPER
W392 7030003860 S.JUMPER
W422 7030003860 S.JUMPER
W452 7030008240 S.JUMPER
W455 7030003860 S.JUMPER
W481 7030003860 S.JUMPER
W521 7030000010 S.JUMPER
W522 7030008240 S.JUMPER
W551 7030000010 S.JUMPER
W552 7030008240 S.JUMPER
W571 7030003970 S.JUMPER
W572 7030008240 S.JUMPER
W692 7030003860 S.JUMPER
W821 7030003860 S.JUMPER
W951 7030000010 S.JUMPER
W952 7030000010 S.JUMPER
W962 7030003860 S.JUMPER
W963 7030003860 S.JUMPER
W964 7030003860 S.JUMPER
W965 7030003860 S.JUMPER
W966 7030003860 S.JUMPER
EP1 0910051794 PCB
EP151 6910012350 S.BEAD
EP321 6910012350 S.BEAD
EP451 6910012350 S.BEAD
EP621 6910012350 S.BEAD
[FILTER UNIT]
REF ORDER
NO. NO.
L1 6140002570 COIL
L2 6140002580 COIL
L3 6140001240 COIL
L4 6140001130 COIL
L5 6140001800 COIL
L6 6140001800 COIL
L8 6140002270 COIL
L9 6110002920 COIL
L10 6110002910 COIL
L13 6200003260 S.COIL
L15 6200003260 S.COIL
L17 6200003260 S.COIL
L19 6200003260 S.COIL
L21 6200001830 S.COIL
L23 6200001830 S.COIL
L24 6140003450 COIL
L25 6140003460 COIL
L26 6140003460 COIL
L28 6140002280 COIL
L29 6110003540 COIL
DESCRIPTION
TMP-P01X-A1
TMP-P01X-A1
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ12YJ0R00H
ERJ3GE JPW V
ERJ3GE JPW V
MCR18EZHJ JPW (000)
ERJ12YJ0R00H
MCR10EZHJ JPW (000)
ERJ12YJ0R00H
MCR10EZHJ JPW (000)
ERJ12YJ0R00H
ERJ3GE JPW V
ERJ3GE JPW V
ERJ12YJ0R00H
ERJ3GE JPW V
ERJ3GE JPW V
MCR10EZHJ JPW (000)
ERJ12YJ0R00H
MCR10EZHJ JPW (000)
ERJ12YJ0R00H
MCR18EZHJ JPW (000)
ERJ12YJ0R00H
ERJ3GE JPW V
ERJ3GE JPW V
MCR10EZHJ JPW (000)
MCR10EZHJ JPW (000)
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
B 5241D
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
DESCRIPTION
LR-294
LR-295
LR-149
LR-138
LR-216
LR-216
LR-240
LA-481
LA-480
NL 322522T-101J
NL 322522T-101J
NL 322522T-101J
NL 322522T-101J
NL 322522T-100J
NL 322522T-100J
LR-387
LR-388
LR-388
LR-241
LA-548
[FILTER UNIT]
REF ORDER
NO. NO.
L30 6110003570 COIL
L31 6110003550 COIL
L32 6200001830 S.COIL
L41 6200001830 S.COIL
L45 6140003560 COIL
L46 6140001820 COIL
L501 6140003440 COIL
L502 6140003440 COIL
C2 4010008260 CERAMIC
C3 4010008200 CERAMIC
C5 4030012480 S.CERAMIC
C7 4010005360 CERAMIC
C8 4010005360 CERAMIC
C10 4010005360 CERAMIC
C12 4030011730 S.CERAMIC
C14 4010005360 CERAMIC
C15 4010008300 CERAMIC
C16 4010005860 CERAMIC
C17 4010008270 CERAMIC
C18 4030011730 S.CERAMIC
C20 4010005360 CERAMIC
C21 4010005360 CERAMIC
C22 4030011180 S.CERAMIC
C23 4010008200 CERAMIC
C24 4010008200 CERAMIC
C25 4010008200 CERAMIC
C28 4030011730 S.CERAMIC
C30 4030011170 S.CERAMIC
C31 4030011730 S.CERAMIC
C32 4030012480 S.CERAMIC
C33 4030011170 S.CERAMIC
C34 4030012480 S.CERAMIC
C35 4030011230 S.CERAMIC
C36 4030011730 S.CERAMIC
C37 4030011190 S.CERAMIC
C38 4030011730 S.CERAMIC
C39 4030011190 S.CERAMIC
C40 4030011550 S.CERAMIC
C41 4030011090 S.CERAMIC
C42 4030006880 S.CERAMIC
C43 4030006880 S.CERAMIC
C44 4030006880 S.CERAMIC
C45 4030006880 S.CERAMIC
C46 4030006880 S.CERAMIC
C47 4030006880 S.CERAMIC
C48 4030006880 S.CERAMIC
C49 4030006880 S.CERAMIC
C50 4030006880 S.CERAMIC
C51 4030006880 S.CERAMIC
C52 4030006880 S.CERAMIC
C53 4030006880 S.CERAMIC
C62 4030011730 S.CERAMIC
C63 4030011240 S.CERAMIC
C65 4030011730 S.CERAMIC
C66 4010005360 CERAMIC
C67 4010005360 CERAMIC
C68 4010005360 CERAMIC
C69 4010005360 CERAMIC
C72 4010008280 CERAMIC
C73 4010005390 CERAMIC
C74 4010005390 CERAMIC
C75 4010005390 CERAMIC
C77 4030011210 S.CERAMIC
C78 4030011240 S.CERAMIC
C79 4030011240 S.CERAMIC
C80 4030011240 S.CERAMIC
C81 4030011240 S.CERAMIC
C82 4030011230 S.CERAMIC
C83 4030011080 S.CERAMIC
C85 4030011160 S.CERAMIC
C86 4030011180 S.CERAMIC
C87 4030006880 S.CERAMIC
C88 4030006880 S.CERAMIC
C97 4010005390 CERAMIC
C98 4010005390 CERAMIC
C99 4010005390 CERAMIC
C100 4010005390 CERAMIC
C102 4030011730 S.CERAMIC
C103 4030012480 S.CERAMIC
C104 4030012480 S.CERAMIC
5 - 27
DESCRIPTION
LA-550
LA-547
NL 322522T-100J
NL 322522T-100J
LR-394
LR-218
LR-386
LR-386
HM74TJ SL 151J 500V
HM11TJ SL 331J 500V
GRM42-6 CH 121J 500PT
HM11SJ SL 301J 500V
HM11SJ SL 301J 500V
HM11SJ SL 301J 500V
GRM42-6 CH 101J 500PT
HM11SJ SL 301J 500V
HM11TJ SL 391J 500V
HM95SJ SL 201J 500V
HM95TJ SL 181J 500V
GRM42-6 CH 101J 500PT
HM11SJ SL 301J 500V
HM11SJ SL 301J 500V
GRM42-6 CH 220J 500PT
HM11TJ SL 331J 500V
HM11TJ SL 331J 500V
HM11TJ SL 331J 500V
GRM42-6 CH 101J 500PT
GRM42-6 CH 180J 500PT
GRM42-6 CH 101J 500PT
GRM42-6 CH 121J 500PT
GRM42-6 CH 180J 500PT
GRM42-6 CH 121J 500PT
GRM42-6 CH 390J 500PT
GRM42-6 CH 101J 500PT
GRM42-6 CH 270J 500PT
GRM42-6 CH 101J 500PT
GRM42-6 CH 270J 500PT
GRM42-6 CH 680J 500PT
GRM42-6 CH 070D 500PT
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
GRM42-6 CH 101J 500PT
GRM42-6 CH 470J 500PT
GRM42-6 CH 101J 500PT
HM11SJ SL 301J 500V
HM11SJ SL 301J 500V
HM11SJ SL 301J 500V
HM11SJ SL 301J 500V
HM95TJ SL 221J 500V
HM15SJ SL 621J 500V
HM15SJ SL 621J 500V
HM15SJ SL 621J 500V
GRM42-6 CH 330J 500PT
GRM42-6 CH 470J 500PT
GRM42-6 CH 470J 500PT
GRM42-6 CH 470J 500PT
GRM42-6 CH 470J 500PT
GRM42-6 CH 390J 500PT
GRM42-6 CH 060D 500PT
GRM42-6 CH 150J 500PT
GRM42-6 CH 220J 500PT
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HM15SJ SL 621J 500V
HM15SJ SL 621J 500V
HM15SJ SL 621J 500V
HM15SJ SL 621J 500V
GRM42-6 CH 101J 500PT
GRM42-6 CH 121J 500PT
GRM42-6 CH 121J 500PT
S.=Surface mount
