Main Unit - Icom IC-756PRO Service Manual

[RF UNIT]
REF ORDER
NO. NO.
J831 6510007020 CONNECTOR
J841 6510007020 CONNECTOR
J901 6510007020 CONNECTOR
J951 6510019990 S.CONNECTOR
P741 6510003240 CONNECTOR
DS111 5080000370 LAMP
W392 7030003860 S.JUMPER
W562 7030003860 S.JUMPER
W662 7030003860 S.JUMPER
W941 7030003860 S.JUMPER
EP1 0910051154 PCB

[MAIN UNIT]

REF ORDER
NO. NO.
IC101 1110000960 S.IC
IC151 1110004840 S.IC
IC201 1110001900 S.IC
IC215 1180000990 S.IC
IC221 1110004840 S.IC
IC301 1130006220 S.IC
IC311 1110003300 S.IC
IC321 1110000960 S.IC
IC331 1130006220 S.IC
IC332 1110003090 IC
IC361 1130006220 S.IC
IC362 1130006220 S.IC
IC371 1110003300 S.IC
IC372 1110003670 S.IC
IC451 1140005280 S.IC
IC551 1110003870 S.IC
IC571 1110000960 S.IC
IC801 1180002000 REG
IC802 1180001070 S.IC
IC803 1180001070 S.IC
IC805 1180000720 S.IC
IC3001 1190001000 S.IC
IC3002 1130008230 S.IC
IC3003 1110003300 S.IC
IC3004 1110000960 S.IC
IC3005 1130008230 S.IC
IC3501 1140008590 S.IC
IC3502 1130009110 S.IC
IC3503 1140005880 S.IC
IC3504 1130007450 S.IC
IC3551 1190000950 S.IC
IC3552 1130007180 S.IC
IC3553 1130009360 S.IC
IC3631 1130008230 S.IC
IC3651 1120002770 S.IC
IC3652 1120002780 S.IC
IC3653 1120002790 S.IC
IC3654 1120002790 S.IC
IC3655 1120002440 S.IC
IC3656 1120002760 S.IC
IC3751 1110004310 S.IC
IC3752 1130007510 S.IC
IC3753 1130007510 S.IC
IC3771 1130007110 S.IC
Q141 1590002710 S.TRANSISTOR
Q142 1590002310 S.TRANSISTOR
Q241 1560000560 S.FET
Q261 1560000560 S.FET
Q271 1560000560 S.FET
Q272 1560000560 S.FET
Q273 1560000560 S.FET
Q274 1530002060 S.TRANSISTOR
Q275 1510000510 S.TRANSISTOR
DESCRIPTION
TMP-J01X-V6
TMP-J01X-V6
TMP-J01X-V6
52808-2290
TMP-P01X-A1
HRS-4160A
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
B 5238D
DESCRIPTION
NJM4558M-T1
NJM1496V-TE1
µPC4570G2-T1
AN78L08M-(E1)
NJM1496V-TE1
TC4W53FU (TE12L)
M5282FP 70CD
NJM4558M-T1
TC4W53FU (TE12L)
LA4425A
TC4W53FU (TE12L)
TC4W53FU (TE12L)
M5282FP 70CD
BA3308F-T1
µPC5023GS-077-E1
NJM2058M-T1
NJM4558M-T1
BA033T
TA7805F (TE16L)
TA7805F (TE16L)
AN79L05M-(E1)
ISD33120S
BU4053BCFV-E2
M5282FP 70CD
NJM4558M-T1
BU4053BCFV-E2
HD64F2357F20
S-80942ANMP-DD6-T2
X25320S8I-2.7T6
RTC-4553A
SED1354F0A (QFP15-128PIN)
TC7WU04FU (TE12L)
LH61665AS-60A
BU4053BCFV-E2
TC74AC244FT (EL)
TC74AC245FT (EL)
TC74AC574FT (EL)
TC74AC574FT (EL)
TC74AC08FS (EL)
TC74AC32FT (EL)
M62352GP 75EC
BU4094BCFV-E1
BU4094BCFV-E1
TC7W04FU (TE12L)
UMH11NTN
DTC114EE TL
2SK882-GR (TE85L)
2SK882-GR (TE85L)
2SK882-GR (TE85L)
2SK882-GR (TE85L)
2SK882-GR (TE85L)
2SC4081 T107 R
2SA1576A T106R
[MAIN UNIT]
REF ORDER
NO. NO.
Q276 1530002060 S.TRANSISTOR
Q277 1590002710 S.TRANSISTOR
Q278 1590002530 S.TRANSISTOR
Q331 1540000470 S.TRANSISTOR
Q333 1590002770 S.FET
Q334 1590002310 S.TRANSISTOR
Q351 1590002310 S.TRANSISTOR
Q471 1530002060 S.TRANSISTOR
Q501 1590002710 S.TRANSISTOR
Q502 1590002710 S.TRANSISTOR
Q503 1530002060 S.TRANSISTOR
Q504 1530002060 S.TRANSISTOR
Q505 1510000510 S.TRANSISTOR
Q506 1590002310 S.TRANSISTOR
Q507 1590001870 S.TRANSISTOR
Q521 1510000510 S.TRANSISTOR
Q601 1540000440 S.TRANSISTOR
Q602 1530002060 S.TRANSISTOR
Q611 1540000440 S.TRANSISTOR
Q612 1530002060 S.TRANSISTOR
Q621 1510000920 S.TRANSISTOR
Q622 1590002710 S.TRANSISTOR
Q631 1530002060 S.TRANSISTOR
Q632 1530002060 S.TRANSISTOR
Q651 1590001870 S.TRANSISTOR
Q652 1540000440 S.TRANSISTOR
Q653 1590002310 S.TRANSISTOR
Q691 1590002310 S.TRANSISTOR
Q801 1530002060 S.TRANSISTOR
Q803 1590002430 S.TRANSISTOR
Q804 1540000470 S.TRANSISTOR
Q805 1520000510 TRANSISTOR
Q3002 1590001870 S.TRANSISTOR
Q3504 1510000500 S.TRANSISTOR
Q3505 1590001940 S.TRANSISTOR
Q3551 1590001870 S.TRANSISTOR
Q3701 1590002310 S.TRANSISTOR
Q3771 1510000510 S.TRANSISTOR
Q3772 1530002060 S.TRANSISTOR
Q3773 1590002310 S.TRANSISTOR
D111 1790001620 S.DIODE
D112 1790001620 S.DIODE
D113 1790000450 S.DIODE
D114 1790000450 S.DIODE
D115 1790001620 S.DIODE
D116 1790001620 S.DIODE
D215 1790001250 S.DIODE
D216 1790001250 S.DIODE
D251 1750000520 S.DIODE
D252 1750000520 S.DIODE
D271 1790001210 S.DIODE
D273 1790001250 S.DIODE
D351 1750000520 S.DIODE
D501 1790001040 S.ZENER
D502 1790001250 S.DIODE
D504 1790001240 S.DIODE
D505 1790001040 S.ZENER
D531 1790001250 S.DIODE
D532 1790001250 S.DIODE
D533 1790001250 S.DIODE
D541 1790001250 S.DIODE
D542 1790001250 S.DIODE
D561 1790001250 S.DIODE
D571 1790001250 S.DIODE
D601 1750000370 S.DIODE
D611 1750000370 S.DIODE
D631 1790001250 S.DIODE
D632 1790001250 S.DIODE
D691 1750000520 S.DIODE
D801 1790001250 S.DIODE
D3001 1750000370 S.DIODE
D3504 1790001250 S.DIODE
D3505 1790001250 S.DIODE
D3506 1790001250 S.DIODE
D3507 1750000370 S.DIODE
D3508 1790001560 S.DIODE
D3509 1790001560 S.DIODE
D3601 1790001250 S.DIODE
D3602 1790001560 S.DIODE
D3701 1750000520 S.DIODE
5 - 11
DESCRIPTION
2SC4081 T107 R
UMH11NTN
UN911H (TX)
2SD1801S-TL
CPH3404-TL
DTC114EE TL
DTC114EE TL
2SC4081 T107 R
UMH11NTN
UMH11NTN
2SC4081 T107 R
2SC4081 T107 R
2SA1576A T106R
DTC114EE TL
DTA114EE TL
2SA1576A T106R
2SD1619-T-TD
2SC4081 T107 R
2SD1619-T-TD
2SC4081 T107 R
2SA1577 T107 Q
UMH11NTN
2SC4081 T107 R
2SC4081 T107 R
DTA114EE TL
2SD1619-T-TD
DTC114EE TL
DTC114EE TL
2SC4081 T107 R
DTA144EE TL
2SD1801S-TL
2SB1133 R
DTA114EE TL
2SA1162-GR (TE85R)
DTC144EE TL
DTA114EE TL
DTC114EE TL
2SA1576A T106R
2SC4081 T107 R
DTC114EE TL
1SV308 (TPL3)
1SV308 (TPL3)
MA862 (TX)
MA862 (TX)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S111-(TX)
MA2S111-(TX)
DAN222TL
DAN222TL
1SS375-TL
MA2S111-(TX)
DAN222TL
MA8033-L (TX)
MA2S111-(TX)
MA2S728-(TX)
MA8033-L (TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
DA221 TL
DA221 TL
MA2S111-(TX)
MA2S111-(TX)
DAN222TL
MA2S111-(TX)
DA221 TL
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
DA221 TL
1SS372 (TE85R)
1SS372 (TE85R)
MA2S111-(TX)
1SS372 (TE85R)
DAN222TL
S.=Surface mount
