SECTION 5 PARTS LIST

[FRONT UNIT]

REF ORDER
NO. NO.
DS1 5080000450 LAMP
ME1 5510000480 METER
W1 8900009230 CABLE
W2 8900009660 CABLE
W3 8900009230 CABLE
W4 8900009240 CABLE
W5 8900009240 CABLE
W6 8900009260 CABLE
W7 8900009260 CABLE
W8 8900009400 CABLE
EP1 6910011090 SENSOR UNIT
EP2 6450001230 E.OTHER
EP3 6450001230 E.OTHER
EP4 6910012500 UNIT BOARD
[DISPLAY BOARD]
REF ORDER
NO. NO.
IC101 1130002660 S.IC
IC102 1130008650 S.IC
IC401 1140003670 S.IC
IC411 1130009640 S.IC
IC431 1130009490 S.IC
IC490 1130009110 S.IC
IC492 1130003760 S.IC
IC501 1180001920 S.IC
IC511 1110003780 S.IC
IC542 1120002740 S.IC
IC821 1110002350 S.IC
IC841 1110004200 S.IC
IC861 1180001070 S.IC
IC881 1180001920 S.IC
IC1401 1120002580 S.IC
IC1521 1110003750 S.IC
Q321 1590002310 S.TRANSISTOR
Q511 1590002310 S.TRANSISTOR
Q512 1520000460 S.TRANSISTOR
Q513 1590002310 S.TRANSISTOR
Q514 1520000460 S.TRANSISTOR
Q515 1590002310 S.TRANSISTOR
Q622 1590002310 S.TRANSISTOR
Q623 1590002310 S.TRANSISTOR
Q624 1590002310 S.TRANSISTOR
Q625 1590002310 S.TRANSISTOR
Q701 1590002310 S.TRANSISTOR
Q801 1530002060 S.TRANSISTOR
Q802 1520000650 S.TRANSISTOR
Q803 1530003300 S.TRANSISTOR
Q804 1530003300 S.TRANSISTOR
Q805 1590002310 S.TRANSISTOR
Q821 1530002060 S.TRANSISTOR
Q841 1520000580 S.TRANSISTOR
Q901 1590002310 S.TRANSISTOR
Q902 1590002310 S.TRANSISTOR
Q903 1590002310 S.TRANSISTOR
Q904 1530002060 S.TRANSISTOR
Q905 1520000650 S.TRANSISTOR
Q1201 1510000510 S.TRANSISTOR
Q1211 1510000510 S.TRANSISTOR
Q1221 1510000510 S.TRANSISTOR
Q1301 1530002060 S.TRANSISTOR
Q1551 1530002060 S.TRANSISTOR
Q1552 1510000510 S.TRANSISTOR
DESCRIPTION
SLU2LC1EX5B-TH
ME-40 (KL-293S-10)
OPC-908
OPC-964
OPC-908
OPC-909
OPC-909
OPC-911
OPC-911
OPC-926
RMS20-250-201-P
HLJ0999-01-480
HLJ0999-01-480
TFD50W40-A
DESCRIPTION
µPD4030BG-T1
MC14071BF-EL
HD6473834H (Z-TAT)
BU4051BCFV-E2
TC74HC4050AF (EL)
S-80942ANMP-DD6-T2
TC4S81F (TE85R)
TA79L08F (TE12L)
NJM2902V-TE1
TK16105MTL
BA6161F
NJM2360M-TE3
TA7805F (TE16L)
TA79L08F (TE12L)
M52338FP
M5218AFP 600C
DTC114EE TL
DTC114EE TL
2SB1132 T100 R
DTC114EE TL
2SB1132 T100 R
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTC114EE TL
2SC4081 T107 R
2SB1201-S-TL
2SC3647S-TD
2SC3647S-TD
DTC114EE TL
2SC4081 T107 R
2SB1124S-TD
DTC114EE TL
DTC114EE TL
DTC114EE TL
2SC4081 T107 R
2SB1201-S-TL
2SA1576A T106R
2SA1576A T106R
2SA1576A T106R
2SC4081 T107 R
2SC4081 T107 R
2SA1576A T106R
[DISPLAY BOARD]
REF ORDER
NO. NO.
Q1553 1510000510 S.TRANSISTOR
Q1554 1530002060 S.TRANSISTOR
D421 1750000520 S.DIODE
D422 1750000520 S.DIODE
D423 1750000520 S.DIODE
D424 1750000520 S.DIODE
D425 1750000520 S.DIODE
D431 1750000520 S.DIODE
D432 1750000520 S.DIODE
D501 1750000190 S.DIODE
D509 1750000190 S.DIODE
D511 1730002260 S.ZENER
D512 1730000410 S.ZENER
D531 1730002260 S.ZENER
D701 1750000520 S.DIODE
D801 1730002260 S.ZENER
D821 1750000190 S.DIODE
D822 1730001050 S.ZENER
D841 1750000560 S.DIODE
D901 1730000410 S.ZENER
D1201 1730002260 S.ZENER
D1211 1730002260 S.ZENER
D1221 1730002260 S.ZENER
X401 6050009870 S.XTAL
L321 6200003950 S.COIL
L322 6200003950 S.COIL
L323 6200003950 S.COIL
L401 6200003950 S.COIL
L801 6180000990 COIL
L802 6190001190 S.COIL
L803 6190001180 S.COIL
L821 6200003950 S.COIL
L822 6200009190 S.COIL
L823 6200003520 S.COIL
L841 6190001190 S.COIL
L842 6180003250 S.COIL
L843 6190001190 S.COIL
R101 7030003320 S.RESISTOR
R102 7030003580 S.RESISTOR
R103 7030003580 S.RESISTOR
R104 7030003640 S.RESISTOR
R105 7030003320 S.RESISTOR
R106 7030003720 S.RESISTOR
R107 7030003720 S.RESISTOR
R121 7030003680 S.RESISTOR
R122 7030003720 S.RESISTOR
R123 7030003680 S.RESISTOR
R124 7030003800 S.RESISTOR
R125 7030003680 S.RESISTOR
R126 7030003720 S.RESISTOR
R127 7030003680 S.RESISTOR
R128 7030003800 S.RESISTOR
R201 7030003440 S.RESISTOR
R202 7030003440 S.RESISTOR
R203 7030003440 S.RESISTOR
R204 7030003440 S.RESISTOR
R205 7030003440 S.RESISTOR
R206 7030003440 S.RESISTOR
R207 7030003440 S.RESISTOR
R208 7030003440 S.RESISTOR
R209 7030003440 S.RESISTOR
R210 7030003440 S.RESISTOR
R211 7030003440 S.RESISTOR
R212 7030003640 S.RESISTOR
R213 7030003640 S.RESISTOR
R214 7030003640 S.RESISTOR
R215 7030003640 S.RESISTOR
R221 7030003440 S.RESISTOR
5 - 1
DESCRIPTION
2SA1576A T106R
2SC4081 T107 R
DAN222TL
DAN222TL
DAN222TL
DAN222TL
DAN222TL
DAN222TL
DAN222TL
1SS322 (TE85R)
1SS322 (TE85R)
MA8030-H (TX)
RD5.1M-T2B2
MA8030-H (TX)
DAN222TL
MA8030-H (TX)
1SS322 (TE85R)
RD20M-T2B1
RB050L-40 TE-25
RD5.1M-T2B2
MA8030-H (TX)
MA8030-H (TX)
MA8030-H (TX)
CR-567 (9.8304 MHz)
HF50ACC 322513-T
HF50ACC 322513-T
HF50ACC 322513-T
HF50ACC 322513-T
LAL 04NA 101K
D10F-A814AY-101K=P3
BLC13H-D818HN-1107
HF50ACC 322513-T
NLFC565050T-472K
ELJFB 102K-F
D10F-A814AY-101K=P3
SLF12565T-680M2R0
D10F-A814AY-101K=P3
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
S.=Surface mount
