  • Page 1 INFRA-RED FLAME DETECTION FlameVision FV300 SERIES IR ARRAY FLAME DETECTORS USER MANUAL...

  • Page 2: Table Of Contents

    FV300 USER MANUAL INDEX PAGE INTRODUCION PRINCIPLES OF OPERATION APPLICATION SYSTEM DESIGN INFORMATION OPERATION INSTALLATION COMMISSIONING MAINTENANCE ORDERING INFORMATION ANNEX A - MODBUS OVERVIEW ANNEX B - CCTV DETAILS...

  • Page 3: Introducion

    INTRODUCTION INTRODUCTION The FV300 FlameVision range is a new family of advanced, high technology infra-red array flame detectors with reliable wide area flame detection and excellent false alarm immunity. The FV300 FlameVision detectors offer a major improvement in both flame detection capability and immunity to false alarm sources over triple IR detectors.
  • Page 4 CONDUITS WITHIN 18" 1180 IP66/67 TYCO TW16 5DB UK Fig. 1 FV300 Series Detector - General View Summary of features: Advanced array based detector Powerful signal processing on DSP with algorithms to give reliable flame detection Detection range: Over 50m for 0.1m...

  • Page 5: Principles Of Operation

    PRINCIPLES OF OPERATION PRINCIPLES OF OPERATION GENERAL In order to optimise the detection of flames from hydrocarbon, the FV300 detectors analyse radiant infrared energy at the peak carbon dioxide emission wavelength around 4.5µm. In a separate guard channel, the detectors also sense additional wavelengths between 4.8 and 5.8µm to determine whether the spectral content received possesses the signature of a real flame.
  • Page 6 PRINCIPLES OF OPERATION Fig. 3 Another advantage of array-based detection is that non-flame interferences, eg, black body or light sources, can be uniquely identified to within an area of the field of view. This ability to separately analyse signals from flame and non-flame sources enables array based flame detectors to not be desensitised in the presence of non-flame interferences, unless such sources are physically coincidental.
  • Page 7 PRINCIPLES OF OPERATION To ensure that flames from all potential fuels are detected whilst minimising the risk of nuisance alarms, an optimum spectral signature of a flame, defined by its ratio at the two measuring wavebands (A/B in Fig. 4) has been established experimentally by lighting characteristic fuels at different distances.
  • Page 8 PRINCIPLES OF OPERATION 2.3.3 IMMUNITY TO SOLAR RADIATION Modulated radiation from direct or reflected sunlight as well as modulated radiation from strong sources of artificial lighting can produce an unwanted response from infrared flame detectors. To counter this possibility, the FV300 detector looks for the flame in a very narrow waveband where most of the sun radiation is absorbed by CO gases in the atmosphere.

  • Page 9: Application

    APPLICATION APPLICATION GENERAL The FV300 FlameVision detectors are intended for the protection of high-risk areas in which accidental fires are likely to result in flaming combustion with the production of carbon dioxide. Typical materials in this type of risk are: a) Flammable liquids, including petroleum products, alcohol and glycol, etc.
  • Page 10 APPLICATION Summary of FV300 FlameVision features and benefits: Detection: The FV300 provides high sensitivity flame detection with high false alarm immunity, undiminished throughout a wide field of view. An infra-red array combined with 2 other optical sensors provides 3 sensitive optical channels.
  • Page 11 The FV300 FlameVision series are a whole new range of flame detectors developed from the knowledge and experience built up from previous detectors such as the S100 and S200 series. However, the FV300 series is not a complete replacement for the existing detectors and the following should be considered: The FV300 will only be available in Flameproof versions.

  • Page 12: System Design Information

    SYSTEM DESIGN INFORMATION SYSTEM DESIGN INFORMATION The electrical, mechanical, environmental characteristics and the performance of the FV300 FlameVision series detectors must be taken into account when designing a system which uses these detectors. This information is given in this section, together with guidance on detector siting. Fig. 6 shows the interfaces available on the detectors.
  • Page 13 SYSTEM DESIGN INFORMATION ELECTRICAL CHARACTERISTICS 4.1.1 GENERAL Supply voltage: 20V to 30V dc Power: up to 10W (depending on model) Quiescent current: - no camera fitted: 158mA at 24V - with camera: 196mA at 24V Alarm current: - no camera fitted: 166mA at 24V - with camera: 205mA at 24V...
  • Page 14 SYSTEM DESIGN INFORMATION 4.1.4 MODBUS NETWORK INTERFACE The FV300 can be a slave RTU device on a MODBUS network using a standard RS485 electrical interface. 4.1.4.1 MODBUS COMMUNICATIONS PARAMETERS Baud rate: 9,600 or 19,200 selectable. Maximum number of units: Protocol: To MODBUS Application Protocol Specification V1.1 - See ‘Annex A for register definitions Mode:...
  • Page 15 SYSTEM DESIGN INFORMATION A 24V supply is required - it must be isolated from detector supply if the RS485 interface option is used. Leave the balun ground connection O/C. From (º To(º C) Text Video Video output overlay camera No video signal Overlay with blue background Camera or blue background with overlay...
  • Page 16 SYSTEM DESIGN INFORMATION 4.1.8 REMOTE LED An external LED indicator can be connected to the detector. The output follows the indications of the alarm LED. The connection is as follows: +12V REMOTE ALARM LED OUTPUT 140R DETECTOR * OPTIONAL CURRENT LIMITING RESISTOR Fig.
  • Page 17 Tested to IP66 and IP67* * Cable gland entries must be suitably sealed to achieve the required IP rating (see Section 6.3.3). FV311 RANGE : 2 x 20mm GLAND HOLES FV312 RANGE : PRECABLED WITH CONDUIT COUPLING Fig. 11 FV300 Series - Overall Dimensions...
  • Page 18 SYSTEM DESIGN INFORMATION 122.4 THE BRACKET BE MOUNTED IN THIS ORIENTATION 94.4 Fig. 12 Adjustable Mounting Bracket and Surface Mounting Dimensions GENERAL CONSTRUCTION Fig. 13 shows a general view of a complete detector with its mounting bracket. The detector is of robust construction to allow its use in harsh environments. The detector comprises a two-part stainless steel ‘spigot-type’...
  • Page 19 - 40 WITHIN 18" C to + 70 1180 IP66/67 TYCO TW16 5DB UK Fig. 13 FV300 Detector - General View TAGGING LOOP CONNECTION POINT EARTH BONDING CONNECTION Fig. 14 Earthing and Label Fixing Points A hanging cord enables the two halves of the enclosure to remain attached when opening the detector during maintenance work.
  • Page 20 SYSTEM DESIGN INFORMATION Fig. 15 FV311/FV312 Top Section Fig. 16 FV312 Bottom Section...
  • Page 21 SYSTEM DESIGN INFORMATION Fig. 17 FV311 Bottom Section The front section of the enclosure is fitted with a window guard plate to protect the two detector viewing windows. A locally formed section of this plate acts as a mirror for the Optical Path Monitoring test.
  • Page 22 Fig. 18 FV300 Detector With Weather Hood Fitted ENVIRONMENTAL CHARACTERISTICS 4.4.1 GENERAL The design and construction of the FV300 series detectors are such that they may be used over a wide range of environmental conditions. Relevant limits are given in Para 4.2. 4.4.2 TEMPERATURE AND HUMIDITY...

  • Page 23: Electromagnetic Compatibility

    SYSTEM DESIGN INFORMATION 4.4.3 VIBRATION AND SHOCK The FV300 detectors have been designed and tested for vibration and shock and comply with the requirements of: EN 54-10, European standard for point flame detectors, Lloyd’s Register of Shipping (LRS) Test Specification Number 1 (2002), Det Norske Veritas (DNV) Certification Notes No 2.4 (April 2001) Class A, Germanischer Lloyd (GL) Rules for Classification and Construction, Test Requirements for Electrical, Electronic Equipment, Computers and Peripherals (April 2001),...
  • Page 24 SYSTEM DESIGN INFORMATION 4.4.5 IONISATION RADIATION The FV300 detector, like other infrared detectors, is insensitive to X-rays and gamma radiation as used in non-destructive testing. The detector will operate normally and will not false alarm when exposed to this type of radiation. However, long-term exposure to high radiation levels may lead to permanent damage.
  • Page 25 SYSTEM DESIGN INFORMATION FIRE DETECTION CHARACTERISTICS 4.5.1 GENERAL A large number of fire tests have been carried during the development phase of the FV300 FlameVision detector to determine the response limits. The results of these tests are summarised below. 4.5.2 FIRE DETECTION RANGE AND RESPONSE TIME The following table shows the detection range and field of view for the FV300 detectors for a selection of typical fuels.
  • Page 26 SYSTEM DESIGN INFORMATION DIRECTIONAL SENSITIVITY The FV300 FlameVision detector has been designed to achieve constant sensitivity across the field of view. The relative variation of range with angle of incidence (polar diagrams) is shown in Figs. 19 and 20 for open-air tests using 0.1m pan petrol fires.
  • Page 27 SYSTEM DESIGN INFORMATION FALSE ALARM IMMUNITY The FV300 has been subjected to the following stimuli that might be considered potential sources of false alarms. Unless otherwise specified, tests were performed at a minimum distance between source and detector. Steady state sources were chopped at both regular and random frequencies in the range 0 - 10Hz.
  • Page 28 SYSTEM DESIGN INFORMATION 4.8.2 USE OF FIRE TEST DATA It has been explained in Sections 4.5 and 4.6 that the sensitivity of the detector is most easily specified in terms of its response to well-defined test fires. Tests are conveniently carried out using a 0.1m pan.
  • Page 29 SYSTEM DESIGN INFORMATION These detectors are designed and manufactured to protect against other hazards as defined in paragraph 1.2.7 of Annex I1 of the ATEX directive 94/9/EC. The one special condition of the certification is that, when using the fitted cable from the FV312 series detectors, this cable must be suitably terminated and protected from impact.
  • Page 30 C to + 70 CONDUITS WITHIN 18" 1180 IP66/67 TYCO TW16 5DB UK Fig. 21 View of Detector Label with Regulatory Markings 4.10.1 PATENTS The FV300 design and manufacture is covered by the following patents licensed from InfraRed Integrated Systems Limited:...

  • Page 31: Operation

    OPERATION OPERATION INDICATORS The FV300 FlameVision detector has a red LED for reporting alarms and a yellow LED for reporting faults. Both LEDs are located in the camera window, see Fig. 22. The alarm LED turns on to report an alarm. The fault LED turns on to report hardware faults or is flashed to show an OPM ‘dirty window’...
  • Page 32 OPERATION ALARM SIGNALLING The FV300 detector has a number of external interfaces. An alarm condition is signalled on all of these interfaces as follows: Alarm relay: The alarm relay will close. 4-20mA: The current (source or sink) becomes 17mA Modbus: The alarm bit is set in the status register and is available at the next read of the unit.
  • Page 33 OPERATION FAULT AND OPM SIGNALLING The FV300 detector has a number of external interfaces. A fault condition is signalled on these interfaces as follows: Fault relay: The fault relay will open. (Hardware, window and OPM faults) 4-20mA: The current (source or sink) become 0mA for hardware and window faults or 2mA for OPM faults.
  • Page 34 OPERATION 5.10 RESETTING ALARM AND FAULT CONDITIONS In latching mode, alarms and faults will continue to be indicated and signalled, even if the original cause has been removed. The detector needs to be reset to clear the condition. The detector can be reset by activating the wired input or remotely using the walk-test trigger tool.
  • Page 35 OPERATION 5.13 WALK-TEST (ALARM TEST) WARNING: THE DETECTOR OUTPUTS WILL BE ACTIVATED DURING A WALK-TEST. DISCONNECT ALL EXTINGUISHING SYSTEMS OR EXTERNAL DEVICES THAT SHOULD NOT BE ACTIVATED DURING A TEST. The FV300 detector has a built in alarm test facility. The lamps used for the OPM test are flashed in a pattern to simulate a flame.

  • Page 36: Installation

    INSTALLATION INSTALLATION GENERAL The FV300 Series detectors may be surface mounted or may use the FV300 adjustable mounting bracket. On the FV311 series, all electrical connections are made via terminal blocks inside the detector rear housing. Two 20mm cable entries are provided. On the FV312 series, electrical connections are made through the FlameVision Exe junction box, selecting the appropriate circuits required.
  • Page 37 M6 studs with nuts and locking washers provided. The FV300 Series may be operated in any position but the mounting point must obviously be chosen to allow sufficient clearance for adjustment of the angle and must also allow space for the cable assembly.

  • Page 38: Detector Wiring

    INSTALLATION 6.2.3 MOUNTING THE FV312 SERIES DETECTOR WIRING In addition to the installation recommendations given in 6.2, the following applies when installing FV312 series detector: a) The detector in-built cable should interface with the field cable via an EExe junction box with EExe cable entry glands suitable for the size of cable used. The FlameVision EExe has been designed to provide a ready-made solution to interfacing with any of the inputs/outputs of the FV300 detector.
  • Page 39 INSTALLATION 6.3.2 RECOMMENDED CABLE TYPE 6.3.2.1 CONVENTIONAL CIRCUITS The cable selected for interconnection to the control equipment should meet the requirements of any national codes (eg, BS5839) or relevant approval bodies. Cables should not normally have a cross sectional area of less than 1mm for solid conductors or 0.5mm for stranded conductors.
  • Page 40 INSTALLATION The use of stopping plugs with a mushroom head and integral ‘O’ ring is recommended. The glands/stopping plugs should be hand-tightened with the addition of, at least, a further turn applied by spanner or other suitable tool. Where it is not practicable to use a nylon gland washer or where an anti-seizing union is required, the following alternative methods may be used: a) The thread of cable glands/stopping plugs may be sealed using PTFE tape or other jointing putty or mastic.
  • Page 41 INSTALLATION 6.3.4 FLAMEPROOF WIRING Cabling and conduit systems must comply with BS EN 60079-14 : 1997. Fig. 24 Relay Wiring Diagram...
  • Page 42 INSTALLATION Fig. 25 4-20mA Output Wiring Diagram...
  • Page 43 INSTALLATION Fig. 26 Field Network Wiring Diagram...
  • Page 44 INSTALLATION INITIAL WIRING CHECK After installing the wiring as detailed above and before connecting any detectors or end-of-line devices, the following tests should be carried out. 6.4.1 CONTINUITY TESTS To check continuity proceed as follows: a) Short-circuit + to + and - to - at each detector terminal block. b) Short-circuit the pair at the end furthest from the control equipment.

  • Page 45: Commissioning

    COMMISSIONING COMMISSIONING SYSTEM CHECKS Before connecting the zone wiring to the control equipment or to the detectors, a general inspection of the system should be carried out. In particular, the positions of the detectors should be checked to ensure that the requirements given in the System Design and Installation sections are met. When the system wiring has been successfully tested and the control equipment commissioned, the detector electronic assemblies may be fitted.
  • Page 46 COMMISSIONING Action Switch Function Off (Default) Ignore DIP switch settings Use DIP switch settings Remote Configuration(*) (Use programmed settings) Alarm Delay Refer to Table 3 Delay Options Reserved Set in Off position Alarm Latching Latching Non-Latching Fault Latching Non-Latching Latching Window Heater OPM Man/Auto Automatic...
  • Page 47 COMMISSIONING 7.2.4 RELAY CONTACT HEADER SETTINGS The fire and fault relays can be used as either normally closed or normally open contacts. The contacts are selected by fitting links to CON3 and CON4 on the terminal board, see Fig. 29. The links must be fitted for the output to operate.
  • Page 48 COMMISSIONING 7.2.5 ADVANCED CONFIGURATION OPTIONS The advanced configuration options are set using the PC configuration tool which connects to the detector using an RS485 link via an interface unit. The following options can be set using the tool: • Primary options: Options available on DIP switches can alternatively be set by configuration tool (need to set a DIP switch to select this option).
  • Page 49 COMMISSIONING TERMINAL BOARD CONNECTIONS Fig. 30 Simplified Wiring Diagram...
  • Page 50 COMMISSIONING SEALED BACKBOX FLYING LEAD CONNECTIONS Wire Identification Pair Colour Signal +24V White Grey Walk Test Input White Green Remote Alarm LED White Blue Configuration RS485+ White Configuration RS485- Brown Camera Video Out+ White Camera Video Out- Yellow Field Network RS485+ White Field Network RS485- Orange...
  • Page 51 Adjust the angle of the detector for the required field of view and then tighten the fixing nuts and bolts. Then complete the routing of the cable to the detector using cable ties or clips as necessary. TYCO TW16 5DB UK Fig. 31 Safety Chain Connection The safety chain secures the top case to the bracket.
  • Page 52 COMMISSIONING 7.5.3 INITIAL FUNCTIONAL TESTS When the detector has settled, the built-in window and alarm tests can be used to check the detector. Initiate a window test using the walk-test input or walk-test tool and confirm a fault is not reported. This shows that the window is clean.
  • Page 53 8.1.2 DETECTOR CLEANING The FV300 series detectors are relatively tolerant of accumulations of dirt on the sensor window or optical monitoring reflector (see Fig. 22). However, thick deposits of dirt and oil will cause a loss of sensitivity and a subsequent fault indication.

  • Page 54: Maintenance

    MAINTENANCE 8.1.3 FAULT FINDING If the detector reports a fault, then the indicators along with the 4-20mA, video or network interfaces can be used to diagnose the cause. Refer to Section 5 ‘Operation’ for more details and Appendix B for information on video overlay messages. The most likely fault is a dirty or obscured window.
  • Page 55 ORDERING INFORMATION ORDERING INFORMATION FV311S: 516.300.006 FV311SC-N: 516.300.007 FV311SC: 516.300.008 FV312S: 516.300.055 FV312SC-N: 516.300.056 FV312SC: 516.300.057 FlameVision MB300 Mounting Bracket: 517.300.001 FlameVision WH300 Weather Hood: 517.300.002 FlameVision JB300 Exe Junction Box: 517.300.005 FlameVision MK300 Field Spares Kit: 517.300.006 FlameVisionWT300 Walk Test Controller: 517.300.021 FlameVision CTI300 Off-line Configuration Tool Kit:...

  • Page 56: Ordering Information

    ANNEX A - MODBUS OVERVIEW A 1. INTRODUCTION The FV300 can connect to a MODBUS network as a slave device conforming to V1.1 protocol specification. The detector provides a bank of 16 bit registers to provide comprehensive information on the status of the detector. A status register is available so that a MODBUS controller can request the alarm and fault status from the detector.

  • Page 57: Annex A - Modbus Overview

    ANNEX A - MODBUS OVERVIEW The Modbus parameters are configured on the Network tab of the PC300 configuration tool. Note: When Modbus is enabled or disabled or if the network parameters are changed then the detector needs to be powered down and up or restarted from the configuration tool to activate the new settings.
  • Page 58 ANNEX A - MODBUS OVERVIEW The cluster state (CS) reports the current status as follows: Inactive Active Pre-alarm Alarm The field of view is considered to be a 256 x 256 square space with the origin in the top right hand corner as you look out from the detector.
  • Page 59 ANNEX A - MODBUS OVERVIEW A 1.5Command Transfer from PLC to FV300 1) The PLC will examine the Command Done bit in the FV300 overall status regis- ter and wait until it is cleared by the FV300. 2) The PLC will set the Command Code in the Command Register. 3) The PLC will set the Command Request bit in the Command Register.
  • Page 60 ANNEX B - CCTV DETAILS B 1. VIDEO TEXT OVERLAY DETAILS The FV300 FlameVision detectors can be supplied with a built in colour video camera which looks out over the same field of view as seen by the IR array and other flame sensors. The camera provides a balanced output video signal on twisted pair connections suitable to feed into a CCTV system.

  • Page 61: Annex B - Cctv Details

    ANNEX B - CCTV DETAILS B 1.1QUIESCENT STATE In quiescent, normal, operation, the text overlay displays basic identity, location and status information. The default layout of the overlay is shown below. 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 l a m e i s i o n <...
  • Page 62 ANNEX B - CCTV DETAILS The top left hand corner of the overlay gives status information about configurable options and the delay settings as follows: Overlay Field Description This field shows the selected alarm delay setting: S – Short delay M –...
  • Page 63 ANNEX B - CCTV DETAILS B 1.3 OPM AND ALARM TEST INFORMATION The OPM test and alarm test (AT) have their own sections of the text overlay to report status. The OPMMODE (<O>) field shows the current OPM operating mode, automatic or manual. 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 <...
  • Page 64 ANNEX B - CCTV DETAILS The OPM condition field reports the result of the test whether initiated manually or automatically. This is in addition to the fault being indicated on the fault LED and signalled on the outputs as described in Section 5. OPM Condition Messages Description and How to fix it The sensing window is dirty and must be...
  • Page 65 ANNEX B - CCTV DETAILS Fault Message Description and How to fix it A fault has been detected on the circuit from Wiring fault the detector. Check wiring. The detector has an internal fault. Record the Detector fault model and serial number and contact your supplier.
  • Page 66 ANNEX B - CCTV DETAILS Message Description Field “SETTLE” is displayed in this field whilst the detector is settling after power up. Once SETTLE the detector has settled this field will be blank. SERVICE “OUT OF SERVICE” is displayed in this field when the detector is in service mode for STATE configuration or diagnostics.
  • Page 67 DETECTOR INFORMATION tyco FlameVision Detector Serial No.: ..........Detector Location: ............................................Dip Switch Settings (see Tables 2 and 3 Page 43): Switch Function Configured Remote Configuration* Alarm Delay Reserved Set in Off position Alarm Latching Fault Latching Window Heater...
  • Page 68 However, should any errors be detected, Thorn Security would greatly appreciate being informed of them. The above not withstanding, Thorn Security can assume no responsibility for any errors in this manual or their consequences. Tyco Safety Products Dunhams Lane Letchworth Hertfordshire...
