Page 1: Basic Telephone
We give you the edge. Basic Telephone Integral TB 13 Connected to ISDN Telecommunications Systems Integral Operating Instructions... -
Page 2: Positioning The Telephone
Enamels or cleaning agents may con- tain substances which soften the base parts of your telephone, and the softened bases can leave undesirable marks on the furniture. Tenovis cannot assume liability for damages of this kind. -
Page 3: Your Telephone At A Glance
TB 13 Operating Instructions Your telephone at a glance 10 Freely assignable function keys Display You can assign various functions or des- The display helps you tinations to these keys to operate the phone Integral 5 / 3: Fixed assignment Alphanumeric 8 pre- -assigned keys... -
Page 4: All Keys At A Glance
TB 13 Operating Instructions All keys at a glance Alphanumeric keys Alphanumeric keys for dialing call numbers and entering codes. The alphanumeric labeling enables you to dial vanity numbers. PQRS WXYZ Star and Hash keys for special functions. 8 pre- -assigned function keys Speed--dial key for dialing the numbers stored in the telephone system. - Page 5 TB 13 Operating Instructions 10 freely assignable function keys You can assign various functions or destinations to the 10 freely assignable function keys. Integral 5 / 3: The function keys are pre- -assigned as follows: 1--3 Destination keys, custom speed--dial destinations 900, 901, 902 Delete Scroll Conference...
-
Page 6: The Display Helps You
TB 13 Operating Instructions The display helps you Symbols and messages in the display provide you with additional information about your connection and the current settings of the telephone. 7633 M. Miller If you are telephoning with an ISDN subscriber, the subscriber’s call number will be displayed. - Page 7 TB 13 Operating Instructions How to operate your telephone Certain functions are operated differently depending on which telephone system you are using. If you mistakenly press an incorrect key during a programming sequence, simply replace / lift the handset. You can then start the procedure over. Basic functions of your telephone Making a call (internal)
- Page 8 TB 13 Operating Instructions Cancelling call- -back Leave handset Cancel on- -hook call- -back Dialing last number again (redial) Int. 5 / 3: external Lift Initiate Conduct call only handset redial Storing a selected redial number Lift Enter Store (Integral 5 / 3) handset call number call number...
- Page 9 TB 13 Operating Instructions Special functions of the Integral 5 / 3 Dialing a e.g. speed- -dial number Lift Initiate Conduct call Enter handset speed- -dial speed- -dial number Listening to opt. a message “Message” Listen to “Delete” Replace Lift handset function key message...
- Page 10 TB 13 Operating Instructions Making an announcement to all subscribers Lift “Announcement” Announcement Replace handset code handset Making an announcement to one subscriber Lift Replace “Announcement” Announcement Enter internal handset code handset call number Picking up a call Conduct call Lift “Pick up”...
- Page 11 TB 13 Operating Instructions Special functions of the Integral 33 Programming a speed- -dial number e.g. Leave hand- Initiate Press speed- -dial Enter set on- -hook programming number call number programming Dialing a speed- -dial number e.g. Lift Dial speed- -dial Conduct call handset number...
- Page 12 TB 13 Operating Instructions Reading messages opt. opt. Leave hand- “Messages” Read Delete Dial displayed set on- -hook function key messages messages call number query Programming volume e.g. & and tone Leave hand- Initiate Enter Enter code and Enter additional (setting): see 1) set on- -hook programming...
- Page 13 TB 13 Operating Instructions Setting the 9 0 0 telephone e.g. Leave hand- Initiate Enter Enter set on- -hook programming function code: see 1) programming 1) Codes: VIP function on / off: 900 / 910 Charges display on / off: 906 / 916 Suppress call number on / off: 905 / 915 Do not disturb on / off:...
-
Page 14: Making Calls
TB 13 Operating Instructions What else you should know about the individual functions If you would like to make an external call, you first need to Making occupy an external line. How you do this depends on the tele- calls phone system you have. -
Page 15: Overview Of Codes
TB 13 Operating Instructions Integral 33: This function enables you to use another telephone Follow- -me (excluding TH 13, TM 13 and TS 13) to set up call diversion for your telephone. You must, however, first set up the diversion on your phone. - Page 16 TB 13 Operating Instructions Integral 5 / 3 codes Function Code In your system Activate function Deactivate function Divert internal calls Divert calls internally Divert calls externally Call list Announcement Pick up call Do not disturb Lock / unlock the telephone Integral 33 codes Function Code...
- Page 17 TB 13 Operating Instructions Answer calls elsewhere: prepare on your telephone Answer calls elsewhere: prepare on other telephone VIP function on / off 900 / 910 Suppress call number on / 905 / 915 Do not disturb on / off 917 / 907 Display charges on / off 906 / 916...
- Page 18 Tenovis GmbH & Co. KG Tenovis B.V., Netherlands Geschäftsbereich Neptunusstraat 71 Kommunikationstechnik, Austria NL-2132 JP Hoofddorp Hietzinger Kai 139 Telephone +31-23-5656-410 A-1131 Wien Fax +31-23-5656-411 Telephone +43-1-8-7870 www.tenovis.nl Fax +43-1-8-7870-7370 Telecomunicaciones Tenovis, S.L, www.tenovis.at Spain Tenovis N.V., Belgium Ventas Telecomunicación...
