Mechanical Parts And Disassembly - Icom IC-A22 Service Manual

SECTION 6
[CHASSIS PARTS]
REF. ORDER
NO. NO.
J3001 6510015550 Antenna Connector BNC-R117 (incl. nut)
P3001 6510007720 PI28A-02F
MP3001 8210011440 1541 rear panel
MP3002 8210013230 1541 front panel (D)
8210011560 1541 front panel (C)
8210011990 1541 front panel
8210011770 1541 front panel (A)
MP3003 8010015670 1541 chassis
MP3004 8930033430 1541 10-key
MP3005 8930033420 1541 contact base
MP3006 8930033510 1541 PTT rubber
MP3007 8930031510 1389 module shield
MP3008 8510009290 1541 module cover
MP3011 8930042252 1257 release button (A) -2
MP3012 8930030041 1452 contact spring-1
MP3013 8930029830 1452 SP rubber
MP3014 8310034120 1541 bottom plate
MP3015 8930033400 1541 DC cap
MP3016 8930033340 1541 SP holder
MP3019 8930033530 1541 DC sheet
MP3020 8810008480 Screw PH BT M2×29 ZK
MP3021 8810006610 Screw PH No. 0 M2×2.5 Nl
MP3022 8810006610 Screw PH No. 0 M2×2.5 Nl
MP3023 8810006610 Screw PH No. 0 M2×2.5 Nl
MP3024 8810008350 Screw PH No. 0 M2×6 Nl
MP3025 8810005360 Screw PH No. 0 M2×3 ZK
MP3026 8810008360 Screw PH No. 0 M2.6×3.5 Nl
MP3027 8010014982 Hole bush (B) -2
MP3029 8930033410 1541 MIC cap
MP3030 8810006610 Screw PH No. 0 M2×2.5 Nl
MP3032 8860000840 1266 lug
W3001 9015410030 24/04/40/D2/W01
W3002 9076900150 24/00/040/D02/W01
SP3001 2510000730 Speaker EAS-3P127G
[RF UNIT]
REF. ORDER
NO. NO.
MP4001 8510002640 RF-can (1) (Coil shield)
MP4002 8510002640 RF-can (1) (Coil shield)
MP4003* 8930004081 Ground spring (B) -1
W4011 8900005320 Flat cable OPC-519
[VCO BOARD]
REF. ORDER
NO. NO.
MP7001 8510009630 1551 VCO case
NOTE
* Refer to SEC9. BOARD LAYOUTS.

MECHANICAL PARTS AND DISASSEMBLY

DESCRIPTION QTY.
[IC-A22]
[IC-A22E]
[IC-A3]
[IC-A3E]
DESCRIPTION QTY.
DESCRIPTION QTY.
[MAIN UNIT]
REF. ORDER
NO. NO.
1 MP5001 8210011570
MP5002 8610009320
1 MP5003 8010013100
MP5004 8610009590
1 MP5005 8010013110
1 MP5006 8610009600
1 MP5007 8010013120
1 MP5008 8930033720
1 MP5009 8830000790
1
1
[LOGIC UNIT]
1
1
REF. ORDER
1
NO. NO.
1
DS6001 5030002100
1
5030001180
3
1
EP6002 8930045060
1
8930045060
1
1
MP6002 8930033350
1
MP6003 8210011431
4
4
[PRT UNIT]
4
1
REF. ORDER
3
NO. NO.
1
MP8002 8860000010
2
2
1
[ACCESORIES]
1
REF. ORDER
1
NO. NO.
EP1001 3310001480
1
EP1002 Optional product
1
EP1003 Optional product
1
Optional product
Optional product
EP1004 Optional product
1
MP1001 8010005710
1
MP1002 8810005730
1
MP1003 8310025060
1
W1001 Optional product
W1002 Optional product
ZP1001 Optional product
1
Screw abbreviations
BT: Self-tapping PH: Pan head BuH: Button head
NI: Nickel ZK: Black BS: Brass
6 - 1
DESCRIPTION
1541 top panel
Knob N-224 base
Knob N-194 cover
Knob N-195 base (A)
Knob N-195 cover
Knob N-196 base (A)
Knob N-196 cover
1541 top seal
VR nut (H)
DESCRIPTION
LCD TTR5680 [IC-A22/E]
LCD LD-BU4279J [IC-A3/E]
LCD contact SRCN-1541-SP-N-W [IC-A22/E]
LCD contact SRCN-1541-SP-N-W [IC-A3/E]
1541 LCD holder
1541 reflector-1
DESCRIPTION
Screw lug M2
DESCRIPTION
Antenna FA-B01AR
Battery pack CM-166
[USA[, [EUR], [AUS], [UK]
Wall charger BM-112U
Wall charger BM-112E
Wall charger BM-95V
Battery case CM-167
[IC-A22], [USA-1] only
448 belt clip
Screw BuH M3×3 ZK BS
1144 caution label (C)
Charger adapter cable OPC-507A
Headset adapter cable OPC-499
Except [USA-1], [IC-A3]
Leather case LC-122
