Icom IC-A22 Service Manual page 19

• IC-A3/E
[RF UNIT]
REF ORDER
NO. NO.
IC4001 1130007610 S.IC µPD3140GS-E1 (DS8)
IC4002 1110003680 IC M68721/SC1303
Q4001 1580000650 S.FET 3SK230-T2 U1B
Q4002 1580000400 S.FET 3SK151-Y (TE85L)
Q4003 1530002600 S.TR 2SC4215-O (TE85R)
Q4004 1530002560 S.TR 2SC4403-3-TL
Q4005 1530002560 S.TR 2SC4403-3-TL
Q4006 1530002560 S.TR 2SC4403-3-TL
Q4007 1530003340 S.TR 2SC3357-T1 RF
Q4010 1590001160 S.TR XP1401-(TX) .AB
Q4011 1590001140 S.TR UN9210 (TX)
Q4011 1590003270 S.TR UNR9210J-(TX)
Q4012 1530003280 S.TR 2SC4211-6-TL
Q4013 1520000460 S.TR 2SB1132 T100 R
Q4014 1530003280 S.TR 2SC4211-6-TL
Q4015 1530002560 S.TR 2SC4403-3-TL
Q4016 1590001140 S.TR UN9210 (TX)
Q4016 1590003270 S.TR UNR9210J-(TX)
Q4017 1590001130 S.TR UN9110 (TX)
Q4017 1590003410 S.TR UNR9110J-(TX)
Q4018 1590001650 S.TR XP4601 (TX)
Q4019 1590001140 S.TR UN9210 (TX)
Q4019 1590003270 S.TR UNR9210J-(TX)
Q4020 1590001650 S.TR XP4601 (TX)
Q4021 1530002850 S.TR 2SC4116-BL (TE85R)
D4001 1790000620 S.DIO MA77 (TX)
D4002 1790000620 S.DIO MA77 (TX)
D4003 1790000620 S.DIO MA77 (TX)
D4004 1790000660 S.DIO MA728 (TX)
D4005 1790000660 S.DIO MA728 (TX)
D4006 1790001290 S.VCP MA304 (TX)
D4007 1790001290 S.VCP MA304 (TX)
D4008 1790001290 S.VCP MA304 (TX)
D4009 1790001290 S.VCP MA304 (TX)
D4010 1790000620 S.DIO MA77 (TX)
D4012 1750000460 S.DIO 1SV246-TL
D4013 1750000460 S.DIO 1SV246-TL
D4016 1790001280 S.DIO MA111 (TX)
D4017 1730002300 S.ZEN MA8082-M (TX)
D4018 1790000850 S.DIO MA132WK (TX)
D4019 1790000860 S.DIO MA133 (TX)
D4020 1790001030 S.DIO SB30-03P-TD
D4021 1790000620 S.DIO MA77 (TX)
D4022 1790001330 S.ZEN MA8036-L (TX)
D4025 1790001030 S.DIO SB30-03P-TD
FI4001 2010001640 FIL FL-203
X4001 6050008730 XTL CR-456
L4001 6200002820 S.COL LQW31HN47NJ01L (LQN 1A 47NJ04)
L4002 6200002390 S.COL LQW31HN64NJ01L (LQN 1A 64NJ04)
L4003 6200002390 S.COL LQW31HN64NJ01L (LQN 1A 64NJ04)
L4004 6200002380 S.COL LQW31HN56NJ01L (LQN 1A 56NJ04)
L4005 6200002820 S.COL LQW31HN47NJ01L (LQN 1A 47NJ04)
L4006 6200002380 S.COL LQW31HN56NJ01L (LQN 1A 56NJ04)
L4007 6200001520 S.COL MLF2012D R82K-T
L4008 6130001740 COL LB-170
L4009 6130001750 COL LB-172
L4010 6130002850 COL LB-326
L4011 6130001750 COL LB-172
L4012 6150004390 S.COL LS-492
L4014 6200001920 S.COL ELJNC R15K-F
L4015 6200001920 S.COL ELJNC R15K-F
L4016 6200001630 S.COL ELJNC R10K-F
L4017 6200002390 S.COL LQW31HN64NJ01L (LQN 1A 64NJ04)
L4025 6200002190 S.COL MLF2012A 4R7K-T
L4027 6200002190 S.COL MLF2012A 4R7K-T
L4028 6200003550 S.COL MLF1608A 4R7K-T
7030003320 S.RES ERJ3GEYJ 101 V (100 Ω)
R4001
7030003370 S.RES ERJ3GEYJ 271 V (270 Ω)
R4004
7030003370 S.RES ERJ3GEYJ 271 V (270 Ω)
R4005
R4006 7030003620 S.RES ERJ3GEYJ 333 V (33 kΩ)
R4007 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
R4008 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
R4009 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
R4010 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R4011 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
DESCRIPTION
[RF UNIT]
REF ORDER
NO. NO.
7030003280 S.RES ERJ3GEYJ 470 V (47 Ω)
R4012
7030003280 S.RES ERJ3GEYJ 470 V (47 Ω)
R4013
R4014 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
R4015 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
R4016 7030003760 S.RES ERJ3GEYJ 474 V (470 kΩ)
7030003780 S.RES ERJ3GEYJ 684 V (680 kΩ)
R4017 7030003660 S.RES ERJ3GEYJ 683 V (68 kΩ)
7030003670 S.RES ERJ3GEYJ 823 V (82 kΩ)
7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R4018 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
7030003200 S.RES ERJ3GEYJ 100 V (10 Ω)
R4019
R4020 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
7030003320 S.RES ERJ3GEYJ 101 V (100 Ω)
R4021
7030003390 S.RES ERJ3GEYJ 391 V (390 Ω)
R4022
R4023 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ) [IC-A3], [EUR], [EUR-1]
7030003770 S.RES ERJ3GEYJ 564 V (560 kΩ)
R4024 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R4025 7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
7030003220 S.RES ERJ3GEYJ 150 V (15 Ω)
R4027
7030003220 S.RES ERJ3GEYJ 150 V (15 Ω)
R4028
R4029 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
R4030 7030003610 S.RES ERJ3GEYJ 273 V (27 kΩ)
7030003340 S.RES ERJ3GEYJ 151 V (150 Ω)
R4031
R4032 7030003610 S.RES ERJ3GEYJ 273 V (27 kΩ)
7030003340 S.RES ERJ3GEYJ 151 V (150 Ω)
R4033
R4034 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R4035 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R4036 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R4037 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R4039 7030003620 S.RES ERJ3GEYJ 333 V (33 kΩ)
R4040 7030003580 S.RES ERJ3GEYJ 153 V (15 kΩ)
7030003360 S.RES ERJ3GEYJ 221 V (220 Ω)
R4041
R4042 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R4043 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R4044 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R4045 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
7030003290 S.RES ERJ3GEYJ 560 V (56 Ω)
R4047
R4054 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R4056 7030003660 S.RES ERJ3GEYJ 683 V (68 kΩ)
R4057 7310003600 S.TRI
7310004660 S.TRI
R4058 7030003600 S.RES ERJ3GEYJ 223 V (22 kΩ)
R4059 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R4060 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R4061 7030003650 S.RES ERJ3GEYJ 563 V (56 kΩ)
R4064 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R4065 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R4066 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R4067 7310003610 S.TRI
7310004530 S.TRI
R4068 7310003610 S.TRI
7310004530 S.TRI
R4069 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
7030003420 S.RES ERJ3GEYJ 681 V (680 Ω)
R4070
R4071 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R4072 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
7030003360 S.RES ERJ3GEYJ 221 V (220 Ω)
R4073
R4079 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
R4080 7030003760 S.RES ERJ3GEYJ 474 V (470 kΩ)
7030003400 S.RES ERJ3GEYJ 471 V (470 Ω)
R4084
7030003400 S.RES ERJ3GEYJ 471 V (470 Ω)
R4086
7030003330 S.RES ERJ3GEYJ 121 V (120 Ω)
R4087
7030003330 S.RES ERJ3GEYJ 121 V (120 Ω)
R4088
7030003290 S.RES ERJ3GEYJ 560 V (56 Ω)
R4089
7030003320 S.RES ERJ3GEYJ 101 V (100 Ω)
R4090
7030003320 S.RES ERJ3GEYJ 101 V (100 Ω)
R4091
7030003430 S.RES ERJ3GEYJ 821 V (820 Ω)
R4092
7030003300 S.RES ERJ3GEYJ 680 V (68 Ω)
R4093
7030003310 S.RES ERJ3GEYJ 820 V (82 Ω)
7030003300 S.RES ERJ3GEYJ 680 V (68 Ω)
R4094
7030003310 S.RES ERJ3GEYJ 820 V (82 Ω)
7030003330 S.RES ERJ3GEYJ 121 V (120 Ω)
R4095
7030003360 S.RES ERJ3GEYJ 221 V (220 Ω)
R4096 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R4097 7030003770 S.RES ERJ3GEYJ 564 V (560 kΩ)
R4098 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R4099 7030003620 S.RES ERJ3GEYJ 333 V (33 kΩ)
7030003280 S.RES ERJ3GEYJ 470 V (47 Ω)
R4100
7030003400 S.RES ERJ3GEYJ 471 V (470 Ω)
R4101
R4102 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R4103 7030003800 S.RES ERJ3GEYJ 105 V (1 MΩ)
7030003830 S.RES ERJ3GEYJ 185 V (1.8 MΩ)
C4001 4030007050 S.CER C1608 CH 1H 220J-T
5 - 6
DESCRIPTION
[EUR], [EUR-1]
[EUR], [EUR-1]
[IC-A3], [EUR], [EUR-1]
EVM-1XSX50 B54 (503) [IC-A3], [EUR], [UK]
EVM-2WSX80 B54 (503) [EUR-1], [AUS]
EVM-1XSX50 B14 (103) [IC-A3], [EUR], [UK]
EVM-2WSX80 B14 (103) [EUR-1], [AUS]
EVM-1XSX50 B14 (103) [IC-A3], [EUR], [UK]
EVM-2WSX80 B14 (103) [EUR-1], [AUS]
[EUR], [EUR-1]
[IC-A3], [AUS], [UK]
[IC-A3], [EUR], [EUR-1]
[IC-A3], [EUR], [EUR-1]
[IC-A3], [EUR], [EUR-1]
[EUR], [EUR-1]
S.=Surface mount
[AUS], [UK]
[IC-A3]
[AUS], [UK]
[AUS], [UK]
[AUS], [UK]
[AUS], [UK]
[AUS], [UK]
[AUS], [UK]
[AUS], [UK]
