Embedded Bar Codes

Certain bar codes can be printed using various ratios and character spacing options. The
following table illustrates these options. See Chapter 8 for more detailed information on
designing label formats using bar code symbols. Some bar codes do not require a CGN
value and should be omitted by entering the comma delimiter.
For Example: If a TCI of 40 is selected the CGN will be omitted by entering nothing for the
CGN and surrounding the parameter with the comma delimiter.
1,200,200,10,40,,0,0,100,1
SYMBOL
Code 39
I 2 of 5
UPC / EAN *
UPC Readable *
Code 128 & UCC / EAN 128 *
Codabar
Code 93
AS-10
Maxicode (CGN = Mode)
MSI (Modified Plessey)
