^A ^D COMMAND
X 63 Text Mode Control: Allows the entry of new text without the ^D2 command
and/or clears all previous text when new text is added.
0 Disable 1 and 2
1 Enable Auto-Print Mode
2 Clear all previous text upon receiving new data.
3 Enable 1 and 2
XX 64 Auto-Print String Count: The ^Axx instructs the printer how many text strings
to accept before printing.
XX 66 Clear Single FORMAT Stored in RAM: The ^Axx specifies which memory
slot to clear (1-128).
70 Clear Commands 73 through 76
71 Load MaxiCode Bar Code Data
XX 73 Load Copies Count: Instructs the printer to print a group of labels. This
command will not increment/decrement serial numbers.
X 74 Infinity Print: Continues to print copies of a format until the power is shut off.
The valid ^Ax values are "1" to enable and "0" to disable this command.
XX 75 Load Label Count: Instructs the printer to print a batch of labels using the
serial number functions if enabled.
XX 76 Load Delay Time Between Labels: The ^Axx specifies the delay time in
1/10ths of a second. Maximum value is 650.
77 Load PDF-417 Bar Code Data
X 78 Set print head number of dots.
448 203dpi 224
640 300dpi 224
640 203dpi 324M
960 300dpi 324M
832 203dpi 424
1280 300dpi 424
832 203dpi 424M
1280 300dpi 424M
832 203dpi X28
1280 300dpi X28
X 79 Set print head dots/inch (dpi). This command sets the dot density of the
print head. This command MUST be sent BEFORE the # of Dots is set with
the ^D78 command.
0 203 DPI
1 300 DPI
13-12
(448 dots)
(640 dots)
(640 dots)
(960 dots)
(832 dots)
(1280 dots)
(832 dots)
(1280 dots)
(832 dots)
(1280 dots)
428TC Operator's Manual - 880041-0141
