Page 1: Operating Instructions
MODEL 1900 FOG MACHINE Operating Instructions April, 2007 Rosco Laboratories, Inc. 52 Harbor View Avenue, Stamford, CT 06902, USA (800) ROSCONY, (203) 708-8900, Fax: (203) 708-8919 email: info@rosco.com... -
Page 2: Table Of Contents
TROUBLESHOOTING GUIDE..................22 PARTS LIST ........................23 INTRODUCTION This manual offers a detailed explanation of the operation of the ROSCO MODEL 1900 smoke machine. To assure efficient and safe operation, please take a few minutes to read this material. The ROSCO MODEL 1900 smoke machine is a thermal aerosol generator designed for very high variable fog output. -
Page 3: Important Safeguards
To do so with any high-amperage device is to assume substantial risk. Rosco strongly recommends against 5. In any facility, the smoke concentration should be controlled. The smoke should never mask emergency exits, safety signs, staircases or other safety constructions. -
Page 4: How The Machine Works
NOTE: The terms “fog” and “smoke” are used interchangeable. However the ROSCO MODEL 1900 does not produce smoke, but a mist or aerosol. -
Page 5: Operating Instructions
2. REMOTE CONTROL The remote control fits into a cavity on the rear of the machine. The Model 1900 ships with the remote control already screwed in place and can be removed. If it is not already plugged in, plug the remote control into the socket in the cavity on the back of the machine. -
Page 6: Dmx Controller
7. DAISY CHAIN (OPTIONAL) The Rosco Model 1900 has the capability to control up to 4 machines from a single controller. In this “Daisy Chain” process, the machine that controls the others is called the MASTER and the others are called SLAVES. -
Page 7: Dmx Interface Address
DMX INTERFACE ADDRESS Binary columns LED indicating DMX signal Address Switches Address for Channel 217 Address for Channel 19 1+8+16+64+128=217 1+2+16=19 = OFF = ON ROSCO MODEL 1900 Page 6 03/07 www.rosco.com... -
Page 8: Do's And Don'ts
Read the entire manual before operating the machine and pay particular attention to all CAUTIONS AND WARNINGS. Use ONLY Rosco manufactured fluids. Use an extension cord which is properly rated for voltage, current and length and which is free from nicks or other signs of wear. -
Page 9: Maintenance
MAINTENANCE 1. There are two fuses on the ROSCO MODEL 1900 smoke machine, one is located on the circuit card inside the machine and the other is located on the rear, below the mains switch. NOTE: Be sure to check the specifications when replacing any fuses. -
Page 10: Rosco Offices
ROSCO OFFICES WORLDWIDE If the machine fails and repairs are required, call or write the nearest Rosco office (listed below) or your local Rosco dealer. UNITED STATES UNITED KINGDOM World Headquarters Roscolab, Ltd. Rosco Laboratories, Inc. Blanchard Works 52 Harbor View Avenue... -
Page 11: Limited Warranty
During the warranty period, machines will be repaired or replaced at the option of ROSCO. The warranty does not extend to any parts of the ROSCO MODEL 1900 that have been subject to misuse or accident. Neither does the warranty cover any machine that has been opened, modified or repaired other than by ROSCO or its designated repair station. -
Page 12: Technical Specifications
ROSCO MODEL 1900 TECHNICAL SPECIFICATIONS POWER REQUIREMENTS REMOTE CONTROL 115 volts, 60 Hz., 15 amps Volume Control 230 volts, 50 Hz., 7 amps Sequencers On time: 2-18 seconds Off time: 2-18 seconds PARTICLE SIZE 0.25-60 microns MAX. FLUID CONSUMPTION DIMENSIONS 6 liters/hour Height: 8.5 in. -
Page 13: Parts Identification Guide
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Left View with Cover Removed Mains Switch # 23711700E001 Fuse Holder (240V) Fuse Holder (110V) ROSCO MODEL 1900 Page 12 03/07 www.rosco.com... - Page 14 ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Right View: Main PCB and XLR A. 3 Pin male XLR-Panel Mount #23711700E009 B. 3 Pin female XLR-Panel Mount #23711700E010 C. Main PCB (240v) # 23711900E240 Main PCB (110v) # 23711900E110 ROSCO MODEL 1900...
- Page 15 ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Rear View with Remote A. Mains Switch #23711700E001 B. Fuse Holder C. Remote Control #23711700R001 ROSCO MODEL 1900 Page 14 03/07 www.rosco.com...
-
Page 16: Left View: Pump And Fittings
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Left View: Pump and Fittings A Pump 240V # 23711700F240 Pump 110V # 23711700F110 Pump 100V # 23711700F100 Fluid tube to heat exchanger (part of HE assembly) Elbow 1/8 x 3/16 # 23711900F001 D Rubber connecting tube # 23711700A002 Main power connection to pump. - Page 17 ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Top View: Heat Exchanger Assembly (closed) A. Hole in heat exchanger housing to access Thermal Trip ROSCO MODEL 1900 Page 16 03/07 www.rosco.com...
- Page 18 ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Top View: Heat Exchanger Assembly (open) A. Thermocouple attached to the heat exchanger. B. Heat Exchanger Assy. 240V # 23711900H240 Heat Exchanger Assy. 110V # 23711900H110 C. Thermal Trip (240V) # 23711700E005 Thermal Trip (110V) # 23711900E006 D.
- Page 19 ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Remote Control FOG Switch POWER ON switch TIMER ON switch FOG LEVEL knob TIMER OFF knob TIMER ON knob Male XLR Connector # 23711700E002 All knobs # 23711700R002 ROSCO MODEL 1900 Page 18 03/07...
- Page 20 ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Main PCB with Heatsink Main PCB (240v) # 23711900E240 Main PCB (110v) # 23711900E110 Heatsink # 23711900E011 ROSCO MODEL 1900 Page 19 03/07 www.rosco.com...
- Page 21 ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE Main PCB: Fuse and Calibration A. Calibration potentiometer for TEMPERATURE CONTROL B. Calibration potentiometer for PUMP SPEED SETTING C. Fuse 10 amp (240v) #23711900E003 Fuse 15 amp (115v) #23711900E004 D. Positive terminal for the thermocouple.
-
Page 22: Troubleshooting
ROSCO MODEL 1900 TROUBLESHOOTING GUIDE SYMPTOM PROBLEM SOLUTION Machine does not fog Broken fog switch on Replace fog switch when READY light is on remote and fog button is pressed Defective Remote PCB Replace remote PCB Break in remote cable... -
Page 23: Troubleshooting Guide
Model 1900 (230V) Mains Cable 23711900E008 Model 1900 (120V) Mains Cable 23711700E002 Model 1700/1900 Male XLR Connector 23711700E009 Model 1700/1900 3 Pin male XLR PM 23711700E010 Model 1700/1900 3 Pin female XLR PM 23711900E003 Model 1900 Fuse (240v) (PCB and chassis) 23711900E004...
