Summary of Contents for Rosco 1750
-
Page 1: Rosco Model
ROSCO MODEL 1750 Operation Manual Revision 2.0 August, 2006 ROSCO LABORATORIES, INC. 52 Harbor View Avenue, Stamford, CT 06902, USA (800) ROSCONY, (203) 708-8900, Fax: (203) 708-8919 email: info@rosco.com Offices: Hollywood, Toronto, London, Madrid, São Paulo, Sydney... -
Page 2: Table Of Contents
The ROSCO MODEL 1750 fog machine is a thermal aerosol generator designed for variable fog output. It is part of a system, the other basic component being the full line of Rosco fog fluids, and they should always be used together. These unique fluid formulations are safe when used according to instructions. -
Page 3: Important Safeguards
To do so with any high-amperage device is to assume substantial risk. Rosco strongly recommends against 5. In any facility, the fog concentration should be controlled. The fog should never mask emergency exits, safety signs, staircases or other safety constructions. -
Page 4: How The Machine Works
NOTE: The terms “fog” and “smoke” are used interchangeable. However the ROSCO MODEL 1750 does not produce smoke, but a mist or aerosol. -
Page 5: Operating Instructions
Place either the 2.5-liter or the 4-liter size bottles of any Rosco fluid in the cavity located at the rear of the machine. Place the end of the tube coming out of the top of the machine into the bottle. - Page 6 The Rosco Model 1750 has the capability to control up to 4 machines from a single controller. In this “Daisy Chain” process, the machine that controls the others is called the MASTER and the others are called SLAVES. Make sure that a remote control is attached to the MASTER machine as outlined in Step 2 and all remote controls are removed from all the SLAVE machines.
-
Page 7: Dmx Interface Address
DMX INTERFACE ADDRESS Binary columns LED indicating DMX signal DATA Address Switches Address for Channel 217 Address for Channel 19 1+8+16+64+128=217 1+2+16=19 = OFF = ON ROSCO MODEL 1750 Page 6 01/06 www.rosco.com... -
Page 8: Do's And Don'ts
Test first for dry smoke.Turn the FOG switch on. Place a piece of cardboard or paper 18 inches in front of the machine. If the surface is at all wet return the machine to A Rosco Service Center for service.. Ensure that the machine is adequately ventilated. -
Page 9: Maintenance
MAINTENANCE 1. The main fuse of the ROSCO MODEL 1750 smoke machine is located on the circuit card inside the machine. NOTE: Be sure to check the specifications when replacing any fuses. WARNING: DISCONNECT THE ROSCO MODEL 1750 FROM POWER BEFORE CHECKING OR REPLACING THE FUSE. -
Page 10: Rosco Offices
ROSCO OFFICES WORLDWIDE If the machine fails and repairs are required, call or write the nearest Rosco office (listed below) or your local Rosco dealer. UNITED STATES World Headquarters Rosco Laboratories, Inc. 52 Harbor View Avenue Stamford, CT 06902 (203) 708-8900 (800) 767-2669 E-mail: info@rosco.com... -
Page 11: Limited Warranty
During the warranty period, machines will be repaired or replaced at the option of ROSCO. The warranty does not extend to any parts of the ROSCO MODEL 1750 that have been subject to misuse or accident. Neither does the warranty cover any machine that has been opened, modified or repaired other than by ROSCO or its designated repair station. -
Page 12: Technical Specifications
Dimensions: 4 in. (10.2 cm) x 6.75 in. (17.14 cm) DUCTING HOSE Flexible, plastic hose, connects to hose adaptor for ducting of fog Dimensions: 4 in. (10.2 cm) x 25 ft. (7.62 m) ROSCO MODEL 1750 ROSCO MODEL 1750 TECHNICAL SPECIFICATIONS REMOTE CONTROL...
