- Page 1 ROSCO DELTA HAZER Operation Manual Revision 2.2 July, 2008 ROSCO LABORATORIES, INC. 52 Harbor View Avenue, Stamford, CT 06902, USA (800) ROSCONY, (203) 708-8900, Fax: (203) 708-8919 info@rosco.com email: Offices: Hollywood, Toronto, London, Madrid, São Paulo, Sydney...
-
Page 2: Table Of Contents
OPERATION MANUAL Information in this document is subject to change without notice and does not represent a commitment on the part of Rosco Laboratories, Inc. © 2008 by Rosco Laboratories, Inc. Edition of April, 2008. This manual covers the following products:... -
Page 3: Introduction
DMX lighting console; or a 0-10 volt signal. The Delta Hazer is part of a system, the other basic component being Rosco Delta Haze Fluid. They should always be used together. This unique fluid formulation is safe when used according to instructions. -
Page 4: Important Safeguards
To do so with any high-amperage device is to assume substantial risk. Rosco strongly recommends against 5. In any facility, the fog concentration should be controlled. The fog should never mask emergency exits, safety signs, staircases or other safety constructions. - Page 5 10. Unauthorized repair or alteration of any safety devices can lead to improper operation and accidents. Repairs should be performed only by an authorized Service Center. WARNING: USE OF ANY FLUID OTHER THAN ROSCO DELTA HAZE FLUID OR MODIFICATION OR ATTEMPTED UNAUTHORIZED REPAIR OF THE ROSCO DELTA HAZER WILL IMMEDIATELY INVALIDATE THE WARRANTY.
-
Page 6: General Operating Instructions
Priming: If the Delta Hazer has not been used for a while, or has run out of fluid, it may be necessary to “prime” the pump. To accomplish this, turn the Fog Volume knob to full and enable the Fog switch. -
Page 7: Volume Control
FLUID. Other manufacturers’ fluids may cause spitting and serious clogging problems and could result in the production of an unhealthful aerosol. The use of other fluids, whether manufactured by Rosco or not, voids the warranty of the Rosco Delta Hazer. DIGITAL/DMX REMOTE CONTROL... - Page 8 Follow steps 1-4 above. When first powered the DIGITAL/DMX REMOTE will display a scrolling “ROSCO DELTA FOG MACHINE” message and then display the Operation Menu. The Operation Menu is the primary interface for operating the Delta Hazer. While in the Operation Menu, the LCD will give a “HEATING” message. Note: The DIGITAL/DMX REMOTE will indicate when the fluid container is low on fluid with an alternating message “LOW FLUID LEVEL”...
-
Page 9: Dmx Mode
Note that the DMX signal can pass through to another device by plugging another cable into the DMX OUT plug. Note: Like any DMX controlled device, if the Delta Hazer is the last device in the DMX line then a terminator plug must be plugged into the DMX OUT connection. -
Page 10: Operating Instructions
The ANALOG/DMX REMOTE CONTROL is an analog interface that consists of an array of switches and knobs. These allow the Delta Hazer base unit to be operated: manually; from timers; from DMX control; or from a 0-10 volt signal. The timers will allow production of fog for up to 2 minutes with intervals of up to 4 minutes between bursts. -
Page 11: Local Operation
Note that the DMX signal can pass through to another device by plugging another cable into the DMX OUT plug. Note: Like any DMX controlled device, if the Delta Hazer is the last device in the DMX line then a terminator plug must be plugged into the DMX OUT connection. -
Page 12: Timed Remote Instructions
Note: While attached to a DMX signal, the Delta Hazer can also be operated manually or with timers. Turning on the TIMER switch will supersede the DMX signal and the FOG switch will supersede the TIMER switch. TIMED REMOTE CONTROL... - Page 13 FOG VOLUME knob until the desired level is reached. To turn the timers off, push the TIMER switch and the yellow LED will turn off. Note: For more accurate timer control or longer sequences, use the DIGITAL/DMX REMOTE instead of the TIMED REMOTE CONTROL. PAGE 13 www.rosco.com...
-
Page 14: Do's And Don'ts
Read the entire manual before operating the machine and pay particular attention to all CAUTIONS AND WARNINGS. Use ONLY Rosco Delta Haze Fluid. Use an extension cord which is properly rated for voltage, current and length and which is free from nicks or other signs of wear. -
Page 15: Maintenance
2. To properly clean machine use compressed air gun set at a maximum pressure of 15 PSI. Turn on the Delta Hazer and wait until it is fully heated indicated by the green LED or “READY” message. Place the air gun at the air input port located at the rear of the machine and blow out fog for about one minute or until no fog leaves the machine. -
Page 16: Rosco Offices
ROSCO OFFICES WORLDWIDE If the machine fails and repairs are required, call or write the nearest Rosco office (listed below) or your local Rosco dealer. UNITED STATES World Headquarters Rosco Laboratories, Inc. 52 Harbor View Avenue Stamford, CT 06902 +1 (203) 708-8900 (800) 767-2669 E-mail: info@rosco.com... -
Page 17: Limited Warranty
For more information on software upgrades, please contact the nearest Rosco office. The warranty does not extend to any parts of the ROSCO DELTA HAZER or the remote controls that have been subject to misuse or accident. Neither does the warranty cover any machine that has been opened, modified or repaired other than by Rosco or its designated repair station. -
Page 18: Digital/Dmx Remote Menu Flowchart
NOTE: To navigate within a given menu or submenu window (i.e., choosing a language in the Language Menu) use the ARROW buttons. OPERATION MENU ENTER LANGUAGE ENTER SET TIMER? SET DMX? SAVE SETTINGS? PAGE 18 MENU FLOWCHART ENTER ON TIME ENTER DMX ADDRESS ENTER LEGEND MENU SUBMENU COMMAND www.rosco.com OFF TIME... -
Page 19: Technical Specifications
16 lb. (7.25 kg) MAX. FLUID CONSUMPTION 500 ml/hour MAIN FUSE 120 volt: 10A 240 volt: 5A SECONDARY FUSE .25A/250v PAGE 19 ROSCO DELTA HAZER REMOTE CONTROLS DIGITAL/DMX REMOTE: Multi-lingual Volume Control Timers DMX address ANALOG/DMX REMOTE: Volume Control Timers...
